RF control kit for STM32W108xx microcontrollers
Introduction
The STM32W-RFCKIT low-cost RF control kit is an easy-to-use tool for STM32W108xx RF
microcontrollers. This family of microcontrollers integrates a 32-bit ARM® Cortex™-M3
microprocessor and a 2.4 GHz, IEEE 802.15.4-compliant transceiver. The kit demonstrates
plug and play 2.4 GHz RF point-to-point communications targeting general-purpose
wireless control systems.
The STM32W-RFCKIT RF control kit provides demonstration applications and
documentation which serve as a reference for creating your own applications and re-
programming the STM32W108xx microcontroller.
You can run the STM32W-RFCKIT RF control kit in several ways using the dedicated
software libraries (Simplified MAC, ZigBee RF4CE and ZigBee PRO). This kit provides
access to a set of straightforward HAL APIs enabling application engineers to easily develop
RF control capabilities such as LEDs, serial communication channels (virtual COM through
USB), MEM enabled pointers, etc. Moreover, thanks to the flexibility of STM32W
microcontrollers, developers will also be able to use the kit with other available protocol
network libraries: MAC based, RF4CE, ZigBee PRO or 6LowPan.
This manual provides information about:
■
STM32W-RFCKIT RF control kit components
■
How to install the related hardware, software and documentation trees
■
How to run the preprogrammed demonstration applications
For more information, visit the STM32W 32-bit RF microcontroller webpages at
www.st.com/stm32w_rfcontrol
These webpages provide full access to all STM32W108xx resources (kits, software
packages and documents).
Doc ID 18433 Rev 2
UM1050
User manual
STM32W-RFCKIT
1/17
www.st.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ST STM32W-RFCKIT
Summary of Contents for ST STM32W-RFCKIT
-
Page 1: Introduction
STM32W108xx microcontroller. You can run the STM32W-RFCKIT RF control kit in several ways using the dedicated software libraries (Simplified MAC, ZigBee RF4CE and ZigBee PRO). This kit provides... -
Page 2: Table Of Contents
Setting up the application serial communication channel ... . 8 Running the STM32W-RFCKIT RF control kit ..... 9 Installing the STM32W-RFCKIT RF control kit software tree . - Page 3 UM1050 Contents List of acronyms ......... . . 12 Appendix A Available board schematics .
-
Page 4: Getting Started
Getting started UM1050 Getting started This section provides a complete description of the STM32W-RFCKIT RF control kit's hardware and software. Kit description 2.1.1 Hardware The STM32W-RFCKIT RF control kit's package contains the following hardware components: ● One STM32W108xx MB950 remote application board ●... -
Page 5: Mb950 Connectors
UM1050 Getting started Table 1. MB950 resources Rev. A Type Label Part STM32W108 pin Button RST1 nRST Button Button Button Button Button Infrared led (not fitted) Mems LIS302 PA1, PA2 Temperature Sensor STLM20 2.2.2 MB950 connectors The following table lists the connectors available in the MB950 board and their functionalities. -
Page 6: Mb950 Pc Interface Chip
Getting started UM1050 2.2.5 MB950 PC interface chip The following table lists the PC interface chip available in the MB950 board to allow I/O interface to the STM32W108. Table 4. MB950 PC interface chip Type Part PC I/O interface STM32F103TBU6 2.2.6 MB950 battery holder Table 5. -
Page 7: Mb951 Pc Interface Chip
Software The STM32W-RFCKIT RF control kit does not contain any CD-ROMs. Documentation The STM32W-RFCKIT RF control kit contains a welcome letter which briefly describes its components and targeted applications. Software libraries and demonstration applications The following installer files are available on the STM32W 32-bit RF microcontroller webpages: ●... -
Page 8: Kit Setup
To power on the MB951 USB dongle, simply plug it into a PC USB port. 2.7.2 Installing the ST Virtual COM port driver USB drive To use the serial communication channel on the kit application boards, a Virtual COM port driver for STM32F103xx must be installed. -
Page 9: Running The Stm32W-Rfckit Rf Control Kit
Running the STM32W-RFCKIT RF control kit Running the STM32W-RFCKIT RF control kit In the STM32W-RFCKIT RF control kit, the Simple MAC talk application is preprogrammed on both kit boards. The Simple MAC talk demonstration application is a simple application that demonstrates point-to-point IEEE 802.15.4 wireless communications using the STM32W108xx MCU. -
Page 10: Basic Rf Communication Using The Talk Demonstration Application
Running the STM32W-RFCKIT RF control kit UM1050 3.1.2 Basic RF communication using the talk demonstration application Once the talk application has been loaded on the kit's board, different RF communication scenarios can be targeted as described in the table below. -
Page 11: Stm32W-Rfckit Utilities And Software Tools
STM32W-RFCKIT utilities and software tools stm32w_flasher utility The stm32w_flasher utility allows you to download a binary file into the STM32W-RFCKIT RF control kit's boards. This utility comes with the Simple MAC software installer file. To download a binary image, follow these steps: Connect the kit board to a PC USB port. - Page 12 List of acronyms UM1050 List of acronyms Table 9. List of acronyms Term Meaning Application programming interfaces CERC Consumer electronic remote control General availability Hardware abstraction layer Integrated development tool Media access control Remote control Radio frequency communication Universal serial bus 12/17 Doc ID 18433 Rev 2 Downloaded from...
- Page 13 Appendix A Available board schematics Figure 4. MB953 module Downloaded from Elcodis.com electronic components distributor...
- Page 14 Figure 5. MB950 Rev.A Downloaded from Elcodis.com electronic components distributor...
- Page 15 Figure 6. MB951 Rev.A Downloaded from Elcodis.com electronic components distributor...
- Page 16 Revision history UM1050 Revision history Table 10. Document revision history Date Revision Changes 14-Feb-2011 Initial release Added Section 2.2: MB950 hardware description 21-Jun-2011 Added Section 2.3: MB951 hardware description Added Section Appendix A: Available board schematics 16/17 Doc ID 18433 Rev 2 Downloaded from Elcodis.com electronic components distributor...
- Page 17 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
