- Page 1 E-mail: SUNNY MINI Address: No. 43, Yunfeng Road, Xiuquan Street, Huadu District, Guangzhou, China...
-
Page 2: Table Of Contents
Contents 1. Safety information......................2 2. Technical information....................4 Attachment and body size..................5 4. Installation and connecting..................6 5. Control panel......................9 6. Menu setting.......................10 7. Channel function......................12 8. Circuit connecting diagram..................21 9. Cleaning and maintenances..................22 10.Troubeshooting......................23 11.Duty exonerative and copyright protection............24 Congratulations on choosing our company product! We thank you for your custom. ◆Please note that this product, as all the others in the rich my company range, has been designed and made with total quality to ensure excellent performance and best meet your expectations and requirements. -
Page 3: Safety Information
SAFETY INFORMATION ■This lighting fixture is for professional use only - it is not for household use. Make sure all parts for fixing the projector are in a good state of repair. Make sure the point of anchorage is stable before positioning the projector. Enhanced care has to be considered during the installation. - Page 4 80℃ The maximun temperature that can be reached on the external surface of the fitting, in a thermally steady state,is 80℃。 Avoid contact bypersons and materials. Allow the fixture to cool for at least 5 minutes before handling. ■The light source The light source in this xture shall be replaced by the manufacturer or its service agent or similar qualication.
-
Page 5: Technical Information
TECHNICAL INFORMATION ● Power supplies available： 100-240V ~，50/60 Hz ● Rated power 507W ： PF : 0.96 ● DMX Connector ： IP66 waterproof signal line. ● Power Connector IP66 waterproof Power input line. ： ● Light source ：LUMILEDS 36×15W RGBL（Red、Green、Blue、Lime） LED ●... - Page 6 IPL3615 Distance,spot diameter and illumination diagram 14°Lux(fc) R 2600(242) 648(60.3) 293(27.2) 165(15.3) 75(7) 43(4) 32(3) 4000(378) 1005(93.4) 460(42.8) 255(23.7) 110(10.2) 65(6) 42(3.9) 583(54) 148(13.8) 68(6.3) 38(3.5) 17.3(1.6) 9.8(0.9) 6.3(0.6) 5530(514) 1340(125) 625(58.1) 319(29.7) 152(14.1) 88.5(8.2) 58(5.4) 12470(1159) 3150(293) 1450(135) 765(71.1) 352(32.8) 200(18.6) 127(11.8)
-
Page 7: Attachment And Body Size
ATTACHMENT AND BODY SIZE power cord... - Page 8 N(White/Blue) L(Black/Brown) (Green/Yellow Green) POWER IN Wire color-coding and power connections： Wire Color Wire Color Conductor Symbol (EU models) (US models) black live brown neutral blue white green ground(earth) yellow-green connection to the eiectricty mains must be carried out by a qualified electrical ●...
- Page 9 DMX IN DMX - output DMX-input 1 - Shield - Shield 2 - Signal (-) - Signal (-) - Signal (+) - Signal (+) - Not connected - Not connected - Not connected - Not connected PIN3 PIN2...
-
Page 10: Control Panel
CONTROL PANEL ENTER Up arrowhead : page up Down arrowhead : page down Left arrowhead : reduce RIGHT LEFT Right arrowhead : increase Enter : OK function Exit : in the choice screen DOWN... -
Page 11: Menu Setting
V1.00A... Clr Fixture Time Yes/No Information DMX Info Strobe.Dimmer... Box Info Box Temp= Humidity = RDM UID = xxxxxxxxxxxx; MANU..LABEL = LIGHTSKY RDM Set DEVICE LABEL = SUNNY MINI 08CH （Default） 24CH 20CH Personal 16CH Channel Mode 01CH 03CH 04CH1... - Page 12 Main menu Ⅰ menu Ⅱ menu Ⅲ menu ⅠV menu 04CH2 05CH Channel Mode 07CH Standby Key Lock On/Off （Default：Off） Select 24K Hz （Default） Select 12K Hz Personal SelectDimmer Hz Select 6K Hz Select 3K Hz Linear （Default） Square DimmerCurve I-Square SCurve Manual...
-
Page 13: Channel Function
CHANNEL FUNCTION Standard channel（ 8CH） Channel Value Percentage Function Note Shutter 0..9 No function 10..255 Strobe effect slow to fast Dimmer 0..255 Dimmer 0%...100% 0..255 0-100% Red dimmer from dark to bright Green 0..255 0-100% Green dimmer from dark to bright Blue 0..255 0-100% Blue dimmer from dark to bright... - Page 14 channel（ 24CH） Channel Value Percentage Function Note Shutter 0..9 No function 10..255 Strobe effect slow to fast Dimmer 0..255 Dimmer 0%...100% 0..255 0-100% Red dimmer from dark to bright Green 0..255 0-100% Green dimmer from dark to bright Blue 0..255 0-100% Blue dimmer from dark to bright Lime 0..255...
- Page 15 Channel Value Percentage Function Note Red in pixel 2 0..255 Red in pixel 2 saturation control(0-100%) Green in pixel 2 0..255 Green in pixel 2 saturation control(0-100%) Blue in pixel 2 0..255 Blue in pixel 2 saturation control(0-100%) Lime in pixel 2 0..255 Lime in pixel 2 saturation control(0-100%) Red in Pixel 3...
- Page 16 channel（ 20CH） Channel Value Percentage Function Note Shutter 0..9 No function 10..255 Strobe effect slow to fast Dimmer 0..255 Dimmer 0%...100% Pixel Macro 0..4 No function 5..28 Marcro 1 29..55 Marcro 2 53..76 Marcro 3 77..100 Marcro 4 101..124 Marcro 5 125..148 Marcro 6 149..172...
- Page 17 Channel Value Percentage Function Note Red in Pixel 3 0..255 Red in pixel 3 saturation control (0-100%) Green in pixel 3 0..255 Green in pixel 3 saturation control(0-100% Blue in pixel 3 0..255 Blue in pixel 3 saturation control(0-100%) Lime in pixel 3 0..255 Lime in pixel 3 saturation control(0-100%) Red in Pixel 4...
- Page 18 channel（ 16CH） Channel Value Percentage Function Note Red in Pixel 1 0..255 Red in pixel 1 saturation control (0-100%) Green in Pixel 1 0..255 Green in pixel 1 saturation control (0-100%) Blue in Pixel 1 0..255 Blue in pixel 1 saturation control(0-100%) Lime in pixel 1 0..255 Lime in pixel 1 saturation control(0-100%)
- Page 19 channel（ 1CH） Channel Value Percentage Function Note ALL Dimmer 0..255 Dimmer 0%...100% Control all LED channel（ 3CH） Function Channel Value Percentage Note 0-100% Red dimmer from dark to bright 0..255 Green 0-100% Green dimmer from dark to bright 0..255 Blue 0-100% Blue dimmer from dark to bright 0..255 channel（...
- Page 20 channel（ 4CH 2） Channel Value Percentage Function Note 0..255 0-100% Red dimmer from dark to bright Green 0..255 0-100% Green dimmer from dark to bright Blue 0..255 0-100% Blue dimmer from dark to bright Lime 0..255 0-100% Lime dimmer from dark to bright channel（...
- Page 21 channel（ 7CH） Channel Value Percentage Function Note Shutter 0..9 No function 10..255 Strobe effect slow to fast Dimmer 0..255 Dimmer 0%...100% 0..255 0-100% Red dimmer from dark to bright Green 0..255 0-100% Green dimmer from dark to bright Blue 0..255 0-100% Blue dimmer from dark to bright Lime 0..255...
-
Page 22: Circuit Connecting Diagram
CIRCUIT CONNECTING DIAGRAM... -
Page 23: Cleaning And Maintenances
CLEANING AND MAINTENANCES ■1.In order to ensure the projector could work normally. It should be kept clean always . The lens should also be regularly cleaned to maintain an optimum light output. Do not use any type of solvent on lens. It will damage the projector. ■2.Suggestion: The continue usage of the light don't exceed 4 hours. -
Page 24: Troubeshooting
TROUBESHOOTING It is recommended some solution for some normal trouble shooting. Any inextricability problems should always be handling by the professional person. Disconnect the power supply before maintenance the light. ■ LED off / LED： 1.Please check if install the suitable voltage. 2.Please check whether the led will reach the end of their life can explode;...
