Section 2 General Information and Setup
4
5
6
7
9
10
8 11
Generator Components
1 Frame
2 Fuel Gauge
3 Roll Over Valve
4 Fuel Cap
5 Fuel Pump (if equipped)
6 Handle
7 Air Filter
8 Fuel Selector Dial
9 Recoil Starter
10 Foot
11 LPG / NG Regulator Inlet - QUICK DIS-
CONNECT
12 Oil Drain
13 Oil Fill / Dipstick
14 Wheel
15 Battery
16 Fuel Tank
17 Grounding Lug
18 Muffler
19 Carbon Canister (if equipped)
20 Cylinder Head
21 Spark Plug
6
3 1
2
15
13
12
Figure 2-1. Features and Controls
14
16
019911
17
22 Engine Switch
23 Hour Meter
24 Circuit Breakers (AC)
25 AC Receptacle
26 COsense RED (Hazard)
27 COsense YELLOW (Fault)
26
27
Figure 2-2. Control Panel (Electric Start) (if
Owner's Manual for Portable Generator
19
18
22 23
25
equipped)
21
20
019912
24
019913
