ASROCK Rack 1U8S4E-GENOA/2T Quick Installation Manual

*15G065281000AR*
P/N: 15G065281000AR V1.0
Quick Installation Guide
1U8S4E-GENOA/2T
The User's Manual is available for download from the ASRock Rack's official website at http://
www.asrockrack.com.
Take note of the following precautions before installing the components or change any settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the components due to static electricity, NEVER place the components
directly on the carpet or the like. Also remember to use a grounded wrist strap or touch a safety
grounded object before installation.
3. Hold components by the edges and do not touch the ICs.
4. Whenever uninstalling any components, place them on a grounded anti-static pad or in the bag
that comes with the components.
5. When placing screws into the screw holes to secure any components to the barebone, please
do not over-tighten the screws! Doing so may damage both components and barebone.
2 Top View
1
4 5 6
12
5 Front Panel
1
No. Description
1 1 Type-A (USB3.2 Gen1)
2 8 x Hot-swap 2.5" SATA drive bays
3 4 x Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays
4 Control Panel (depends on the specification of the server board)
2
3
7 8 9
10
11
2 3
1 Replace Server Board
Carefully unplug all cables and release
1
thumbscrews on the ser ver board to
remove them from the barebone.
Align the replaced server board with the
2
mounting holes
A f f i x t he screws clock w ise into t he
3
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
No. From
Add-in card x16
1
(for PCIE slot on the server board)
2 Server Board
3 2 x Power Supply Units (PSU)
4 System Fan 1
5 System Fan 2
6 System Fan 3
7 System Fan 4
8 System Fan 5
9 System Fan 6
10 2.5" Drive Backplane Board
11 12 x 2.5" Hot-Swap Drive Trays
12 1 Type-A (USB3.2 Gen1)
13 Front Control Panel Buttons
I/O Panel
4
2
1
3
13
No. Description
1 UID Switch (UID1)
2 IPMI LAN Header (IPMI_LAN1)*
3 USB 3.2 Gen1 Ports (USB3_1_2)
6 Rear Panel
1
4
No. Description
1 2 x Power Supply Units (PSU)
2 Rear Vent
3 I/O Shield (depends on the specification of the server board)
4 1 x Add-in card x16 (for PCIE slot on the server board)
www.asrockrack.com
Control Panel
3
2 1
RST NMI
3
5
L1
7
No. Description
1 System Reset Button
NMI (Nonmaskable Interrupt)
2
Button
3 Power Button and LED
4 ID Button and LED
5 Hard Drive Status LED
6 System Status LED
7 LAN1 Activity LED
8 LAN2 Activity LED
4
5
No. Description
4 10G LAN RJ-45 Port (LAN_1)**
5 10G LAN RJ-45 Port (LAN_2)**
6 VGA Port (VGA1)
2 3
2 2
ID
4
6
L2
8
4
