APS iRunning IB14RIE2 Installation Instruction

Part#:IB14RIE2
Application: For 2005-2012 Nissan Pathfinder
Item Part Name
1 STEP BOARD( Driver+Passenger)
2 Mounting Bracket
3 M6X1-20mm Square Hex Bolt
Installation Procedure
Step
Remove contents from box and check for damage. Verify all parts are present. Read instructions completely
1
before beginning. It is strongly recommended to install the Sure Grip Gap Strip for these vehicle applications.
2 Attach mounting brackets as shown SEE FIGURE1.
3 Insert square head bolts as shown (3 per slot,6 per board).SEEFIGURE 2.
Attach board to brackets as shown . Make sure board and brackets are properly aligned and tighten
4
fasteners. SEE FIGURE 3
INSTALLATION IS COMPLETE! SEEFIGURE 4.
5
FINISH PROTECTION
To protect your investment, wax this product after installing. Regular waxing is recommended to add a protective
layer over the finish. Do not use any type of polish or wax that may contain abrasives that could damage the finish.
For Polished Finishes: Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild soap
may be used also to clean the Running Board.
For black finishes: Mild soap may be used to clean the Running Board.
The instruction here is for your reference only. We strongly recommend the
professional installer for best result. We are not responsible for any damage
caused by the installation. Thank you for choosing our product!
iRunning Board Installation Instruction
Mounting Bracket
QTY Item
2 4 M6 Flat Washers
6 5 M6 Nylon Lock Nuts
12 6 M8 Flange Nut
Description
Page 1 of 2
REV: 20180301
Part Name QTY
12
12
12
