Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
IPC-HFW3441E-SA
Network Camera Web 3.0
Operation Manual
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
o cerca il tuo prodotto tra le
migliori offerte di Videosorveglianza
Dahua WizSense
V2.0.8

Advertisement

loading
Need help?

Need help?

Do you have a question about the WizSense IPC-HFW3441E-SA and is the answer not in the manual?

Questions and answers

Related Manuals for Dahua Technology WizSense IPC-HFW3441E-SA

Summary of Contents for Dahua Technology WizSense IPC-HFW3441E-SA

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua WizSense IPC-HFW3441E-SA o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza Network Camera Web 3.0 Operation Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V2.0.8...
  • Page 2 Operation Manual Foreword General This manual introduces the functions, configuration, general operation, and system maintenance of network camera. Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury.
  • Page 3 Operation Manual Version Revision Content Release Date ● Updated "4.5.1.1.8 Illuminator". June 2020 ● Updated "4.7.3.2 Local". V2.0.5 ● Added "5.19.6 Setting Disarming". ● Updated "4.5.1.4 Splicing". ● Updated "5.14 Setting Vehicle May 2020 V2.0.4 Density". ● Updated "5.12 Setting People Counting".
  • Page 4 Operation Manual updates might cause some differences between the actual product and the manual. Please contact the customer service for the latest program and supplementary documentation. ● There still might be deviation in technical data, functions and operations description, or errors in print.
  • Page 5 Operation Manual Important Safeguards and Warnings Electrical Safety ● All installation and operation shall conform to your local electrical safety codes. ● The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
  • Page 6 Operation Manual ● You can clean the device body with soft dry cloth, and for stubborn stains, use the cloth with mild detergent. To avoid possible damage on device body coating which could cause performance decrease, do not use volatile solvent such as alcohol, benzene, diluent and so on to clean the device body, nor can strong, abrasive detergent be used.
  • Page 7 Operation Manual Table of Contents Foreword ........................................I Important Safeguards and Warnings ............................IV 1 Overview ........................................1 1.1 Introduction ....................................1 1.2 Network Connection ................................1 1.3 Function ......................................1 1.3.1 Basic Function .................................. 1 1.3.2 Intelligent Function ............................... 2 2 Configuration Flow ....................................
  • Page 8 Operation Manual 4.3.3 Calling PTZ ..................................32 4.3.3.1 PTZ Control ................................32 4.3.3.2 PTZ Function ................................ 34 4.4 Playback ....................................... 34 4.4.1 Playback Interface ................................ 35 4.4.2 Playing back Video or Picture ..........................37 4.4.3 Clipping Video ................................40 4.4.4 Downloading Video or Picture ..........................41 4.4.4.1 Downloading A Single File ..........................
  • Page 9 Operation Manual 4.5.2.3.6 Configure Picture Overlay ........................66 4.5.2.3.7 Configure Custom Overlay ......................... 67 4.5.2.3.8 Configuring OSD Info ..........................68 4.5.2.3.9 Configuring Counting ........................... 69 4.5.2.3.10 Configuring Structured Statistics ....................69 4.5.2.3.11 Configuring GDP Position ........................ 70 4.5.2.3.12 Configuring Ranging .......................... 70 4.5.2.3.13 Configuring ANPR ..........................
  • Page 10 Operation Manual 4.7.3.1 Path ................................... 98 4.7.3.2 Local ..................................99 4.7.3.3 FTP ..................................100 4.7.3.4 NAS ..................................102 4.8 System ......................................103 4.8.1 General .................................... 103 4.8.2 Date & Time ................................... 104 4.8.3 Splicing ................................... 105 4.8.4 Account ................................... 106 4.8.4.1 Adding a User ..............................
  • Page 11 Operation Manual 5.1.2.1 About Alarm Types ............................134 5.1.2.2 Subscribing Alarm Information ....................... 135 5.2 Setting Smart Track ................................135 5.2.1 Setting Calibration Parameters for Smart Track ..................136 5.2.2 Enabling Alarm Track ............................... 138 5.3 Setting Panoramic Calibration ............................139 5.4 Setting Video Detection ..............................
  • Page 12 Operation Manual 5.12.2 Calibration Configuration ........................... 180 5.12.3 Queuing ..................................181 5.12.4 Viewing People Counting Diagram ........................ 183 5.12.5 Viewing People Counting Report ........................185 5.13 Setting Heat Map ................................186 5.13.1 Heat Map ..................................186 5.13.2 Viewing Heat Map Report ........................... 187 5.14 Setting Vehicle Density ..............................
  • Page 13 Operation Manual 6.6 Information ....................................217 6.6.1 Version .................................... 217 6.6.2 Log ..................................... 217 6.6.3 Remote Log ................................... 218 6.6.4 Online User ..................................219 Appendix 1 Cybersecurity Recommendations ........................220...
  • Page 14 Operation Manual 1 Overview 1.1 Introduction IP camera (Internet Protocol camera), is a type of digital video camera that receives control data and sends image data through internet. They are commonly used for surveillance, requiring no local recording device, but only a local area network. IP camera is divided into single-channel camera and multi-channel camera according to the channel quantity.
  • Page 15 Operation Manual ● Snapshot and triple snapshot abnormality of the monitoring image for subsequent view and processing. ● Record abnormality of monitoring image for subsequent view and processing. ● Configure coding parameters, and adjust live view image. Record ● Auto record as schedule. ●...
  • Page 16 Operation Manual ● When an alarm is triggered, the system performs linkages such as recording, alarm output, sending email, and snapshot. Crowd Map ● View crowd distribution in real time for the timely arm to avoid accidents like stampede. ● When an alarm is triggered, the system performs linkages such as recording, alarm output, sending email, PTZ operation, and snapshot.
  • Page 17 Operation Manual Video Metadata ● Snap people, non-motor vehicle and vehicle, and display the related information on the live interface. ● When an alarm is triggered, the system links alarm output. Alarm Setting ● The alarm is triggered when an external alarm input device inputs alarm. ●...
  • Page 18 Operation Manual 2 Configuration Flow For the device configuration flow, see Figure 2-1. For details, see Table 2-1. Configure the device according to the actual situation. Figure 2-1 Configuration flow Table 2-1 Description of flow Configuration Description Reference Open IE browser and enter IP address to log in to the web Login "4.1 Login"...
  • Page 19 Operation Manual 3 Device Initialization Device initialization is required for the first use. This manual is based on the operation on the web interface. You can also initialize device through ConfigTool, NVR, or platform devices. ● To ensure the device safety, keep the password properly after initialization and change the password regularly.
  • Page 20 Operation Manual Figure 3-2 End-user license agreement Step 4 Select the I have read and agree to all terms check box, and then click Next. Figure 3-3 Easy4ip Step 5 You can register the camera to Easy4ip, select the check box as needed, and then click Next.
  • Page 21 Operation Manual Figure 3-4 Online upgrade Step 6 Select the upgrading method as needed. If you select Auto-check for updates, the system checks new version once a day automatically. There will be system notice on Upgrade interface and Version interface if any new version is available.
  • Page 22 Operation Manual 4 Basic Configuration The chapter introduces the basic configuration, including login, live view, PTZ operation, playback operation, camera configuration, network configuration, storage configuration and system configuration. 4.1 Login This section introduces how to log in to and log out of the web interface. This section takes IE Explorer 9 as an example.
  • Page 23 Operation Manual ● Alarm: Click Alarm, and you can subscribe and view alarm information. ● Logout: Click Logout to go to login interface. ● The system will sleep automatically after idling for a period of time. Figure 4-2 Live 4.2 Live This section introduces the layout of the interface and function configuration.
  • Page 24 Operation Manual The functions and interfaces of different models might vary, and the actual product shall prevail. Figure 4-3 Live Table 4-1 Description of function bar Function Description Encode bar Sets stream type and protocol. Live view Displays the real-time monitoring image. Live view function bar Functions and operations in live viewing.
  • Page 25 Operation Manual Table 4-2 Description of live view function bar Icon Function Description Manually position the tracking speed dome to the selected location of corresponding panoramic camera. Click the icon and click or select randomly on the image of panoramic camera channel, the tracking speed dome will automatically position the selected location.
  • Page 26 Operation Manual Icon Function Description Click the icon, and select an area on the live image, the camera will automatically count the Vehicle Density number of the vehicles in the selected area, and display the number on the Live interface. Displays alarm output state.
  • Page 27 Operation Manual Icon Function Description Click the icon to record video, and it will be saved to the configured storage path. Record About viewing or configuring storage path, see "4.5.2.5 Path". Click the icon, the AF Peak (focus eigenvalue) and AF Max (max focus eigenvalue) are displayed on the video image.
  • Page 28 Operation Manual Table 4-3 Description of adjustment bar Icon Function Description Click the icon, and then the Image Adjustment interface is displayed at the right side of the Live interface. You can adjust brightness, contrast, hue, and saturation. The adjustment is only available on the web interface, and it does not adjust the camera parameters.
  • Page 29 Operation Manual Icon Function Description Click the icon to select the fluency from Realtime, Fluency and Normal. ● Realtime: Guarantees the real time of the image. When the bandwidth is not enough, the image might not be smooth. Fluency ● Fluency: Guarantees the fluency of the image.
  • Page 30 Operation Manual Icon Function Description When view multi-channel image, you Window Layout can select display layout. Click the icon and select the Enable check box. The Crowd Map interface is Crowd Map displayed. For details, see"5.9 Setting Crowd Map". 4.2.4.2 Zoom and Focus You can adjust focal length to zoom in or out video image and the image clarity.
  • Page 31 Operation Manual Parameter Description Adjusts image clarity automatically. Auto Focus Do not make any other operation during auto focus process. Restores focus to default value and corrects errors. Restore All You can restore the focus if the image has poor clarity or has been zoomed too frequently.
  • Page 32 Operation Manual Figure 4-6 Fisheye Table 4-5 Description of fisheye configuration Parameter Description Installation mode Includes ceiling mount, wall mount, and ground mount. The display model of the current image. There are different display modes for each installation mode. ● Ceiling: 1P+1, 2P, 1+2, 1+3, 1+4, 1P+6, 1+8. ●...
  • Page 33 Operation Manual Parameter Description 360° rectangular panoramic image screen + independent sub-screens. ● You can zoom or drag the image in all the 1P+1 screens. ● You can move the start point (left and right) on rectangular panoramic image screen. Two associated 180°...
  • Page 34 Operation Manual Parameter Description 180° rectangular panoramic image screen (from left to right). You can drag the image in all the screens (up and down) to adjust the vertical view. 180° rectangular panoramic image screen + three independent sub-screens. ● You can zoom or drag the image in all the 1P+3 screens.
  • Page 35 Operation Manual Parameter Description ● You can drag the image in upper/lower/left/right direction. Press I to display the panorama, and press O to return Asteroid to the original size. ● Press the left mouse-button to slide down to display the image on the plane surface. ●...
  • Page 36 Operation Manual Figure 4-8 Preset Step 2 Set the speed, and click to adjust the parameters of direction, zoom, focus and iris, to move the camera to the position you need. Click Add to add the current position to be a preset, and the preset is displayed in preset Step 3 list.
  • Page 37 Operation Manual Figure 4-9 Tour Step 2 Click Add① to add tour. Double-click the tour name to edit the name. Step 3 Click Add② to add preset. Double-click the duration to set the duration. Step 4 Select the tour mode. ●...
  • Page 38 Operation Manual Figure 4-10 Scan Step 2 Select the scan number, and set the speed. Click Setup to set left limit and right limit. Step 3 1) Click Set Left Limit to set the current position to be the left limit. 2) Click Set Right Limit to set the current position to be the right limit.
  • Page 39 Operation Manual Figure 4-11 Pattern Step 2 Select the pattern number. Click Setup, and then click Start Rec. Adjust the parameters of direction, zoom, focus and Step 3 iris according to the actual situation. Step 4 Click Stop Rec to stop recording. Step 5 Click Start to start patterning.
  • Page 40 Operation Manual Click Stop to stop rotation. 4.3.2.6 PTZ Speed PTZ speed means the rotation speed of the PTZ camera during touring, pattern, or auto tracking. Step 1 Select Setting > PTZ settings > Function > PTZ Speed. Figure 4-13 PTZ speed Step 2 Select the PTZ speed: Low, Middle, and High.
  • Page 41 Operation Manual Figure 4-14 Idle motion Step 2 Select the Enable check box to enable the idle motion function. Step 3 Select the idle motion and set the idle time. You need to select the corresponding number for some selected idle motions, such as Preset001.
  • Page 42 Operation Manual Step 3 Select the power up motion. When you select Auto, the system will perform the last motion that is executed for more than 20 s before power-off. Step 4 Click OK. 4.3.2.9 PTZ Limit After setting PTZ limit, the camera can only rotate within the configured area. Select Setting >...
  • Page 43 Operation Manual Figure 4-17 Time task Step 2 Select the Enable check box to enable time task function. Step 3 Select the time task number. Step 4 Select the time task action. You need to select the corresponding action number for some selected time task actions. Step 5 Set the auto home time in AutoHome.
  • Page 44 Operation Manual Figure 4-18 PTZ restart Step 2 Click PTZ Restart to restart PTZ. 4.3.2.12 Default Be careful when doing this operation. It will restore the camera to default configuration, and result in data loss. Select Setting > PTZ settings > Function > Default. Step 1...
  • Page 45 Operation Manual Figure 4-19 Default Step 2 Click Default and the PTZ function is restored to default. 4.3.3 Calling PTZ Click on Live interface, and the PTZ configuration panel is displayed. You can control PTZ and call PTZ function. 4.3.3.1 PTZ Control You can rotate device, zoom image, and adjust iris through PTZ control or virtual joystick.
  • Page 46 Operation Manual Figure 4-20 PTZ control Figure 4-21 Joystick ● : Rotate PTZ direction through direction button. PTZ supports eight directions: left/right/up/down/upper left/upper right/bottom left/bottom right. Click , and draw a box in the image, PTZ will rotate, focus and quickly position the defined scene. ●...
  • Page 47 Operation Manual 4.3.3.2 PTZ Function Select the PTZ function from the drop-down list to call the corresponding functions, including Scan, Preset, Tour, Pattern, Pan, Go to, Assistant and Light Wiper. See Figure 4-22. For details, see Table 4-6. Before calling PTZ function, see "4.3.2 Configuring PTZ Function" to configure PTZ function. ●...
  • Page 48 Operation Manual picture playback. ● Before playing back video, configure record time range, record storage method, record schedule and record control. For details, see "5.1.1.2.1 Setting Record Plan". ● Before playing back picture, configure snapshot time range, snapshot storage method, snapshot plan.
  • Page 49 Operation Manual Figure 4-24 Picture playback Table 4-7 Playback interface description Function Description Click , you can select display mode according to the installation mode during playback. Fisheye This function is only available on fisheye cameras. Click , intelligent rules and object detection box are displayed.
  • Page 50 Operation Manual Function Description Controls playback. ● : Click the icon to play back recorded videos. ● : Click the icon to stop playing back recorded videos. Play control bar ● : Click the icon to play the next frame. ●...
  • Page 51 Operation Manual video playback as an example. Select dav from the Record Type drop-down list and SD card from the Data Src Step 1 drop-down list. Select jpg from Record Type drop-down list when playing back pictures, and you do not need to select data source.
  • Page 52 Operation Manual Figure 4-27 Specific event types Step 3 Select the month and year of the video that you want to play. Those dates with blue color indicate there were videos recorded in those days. Step 4 Play video. ● Click in the control bar.
  • Page 53 Operation Manual Figure 4-29 Playback file list 4.4.3 Clipping Video Step 1 Click , the video files of the selected date are listed. Step 2 Select dav or mp4 in Download Format. Step 3 Click on the progress bar to select the start time of the target video, and then click See Figure 4-30.
  • Page 54 Operation Manual Step 5 Click to download the video. The system will prompt that it cannot play back and download at the same time. Step 6 Click OK. The playback stops and the clipped file is saved in the configured storage path. For the configuration of storage path, see "4.5.2.5 Path".
  • Page 55 Operation Manual Figure 4-31 Batch download Step 2 Select the record type, set the start time and end time, and then click Search. The searched files are listed. Step 3 Select the files to be downloaded, select dav or mp4 from the Format drop-down list, and then set the storage path.
  • Page 56 Operation Manual ● Camera with PTZ function supports zoom, focus and iris operations. See Figure 4-33. Configure speed, click direction button, to adjust the direction, zoom, focus and iris and so on, to adjust the camera to the proper position. Figure 4-32 Camera conditions Figure 4-33 Camera conditions (PTZ camera) 4.5.1.1.2 Picture...
  • Page 57 Operation Manual Figure 4-34 Picture Step 2 Configure picture parameters. Table 4-8 Description of picture parameters Parameter Description Select the picture style from soft, standard and vivid. ● Soft: Default image style, displays the actual color of the image. Style ●...
  • Page 58 Operation Manual Parameter Description Changes the display direction of the picture, see the options below. ● 0°: Normal display. ● 90°: The picture rotates 90° clockwise. ● 180°: The picture rotates 90° counterclockwise. Flip ● 270°: The picture flips upside down. For some models, please set the resolution to be 1080p or lower when using 90°...
  • Page 59 Operation Manual Table 4-9 Description of exposure parameters Parameter Description You can select from 50 Hz, 60 Hz and Outdoor. ● 50 Hz: When the electric supply is 50 Hz, the system adjusts the exposure according to ambient light automatically to ensure that there is no stripe appears.
  • Page 60 Operation Manual Parameter Description When selecting Gain Priority or Manual in Mode, you can set shutter Gain range. With minimum illumination, the camera increases Gain automatically to get clearer images. When selecting Aperture Priority in Mode, you can set iris range. Iris This configuration is available only when the camera is equipped with auto-iris lens.
  • Page 61 Operation Manual Backlight mode Description Enable BLC, the camera can get clearer image of the dark areas on the target when shooting against light. You can select Default mode or Customized mode. ● When in Default mode, the system adjusts exposure according to ambient lighting condition automatically to ensure the clarity of the darkest area.
  • Page 62 Operation Manual Table 4-11 Description of WB parameters WB mode Description The system compensates WB according to color temperature to ensure Auto color precision. The system auto compensates WB to environments without artificial Natural light to ensure color precision. The system compensates WB to outdoor night scene to ensure color Street Lamp precision.
  • Page 63 Operation Manual Table 4-12 Description of day and night parameters Parameter Description You can select device display mode from Color, Auto, and B/W. Day & Night configuration is independent from profile management configuration. Mode ● Color: The system displays color image. ●...
  • Page 64 Operation Manual Parameter Description Adjusts zoom speed. The higher the value is, the higher the speed will Zoom Speed Sets focus mode. ● Auto: When image moves or object changes in the scene, the camera will focus automatically. ● Semi Auto: Click corresponding to Focus or Zoom, Mode the camera will focus.
  • Page 65 Operation Manual Table 4-14 Description of illuminator parameters Illuminator Description Set Fill Light for sound and siren cameras. ● IR Mode: Enable the IR illuminator, and the white light is disabled. When an alarm is triggered, the system will link white light. ●...
  • Page 66 Operation Manual 4.5.1.1.9 Defog The image quality is compromised in foggy or hazy environment, and defog can be used to improve image clarity. Step 1 Select Setting > Camera > Conditions > Conditions > Defog. Figure 4-41 Defog Step 2 Configure defog parameters.
  • Page 67 Operation Manual Figure 4-42 Fisheye Step 2 Set install mode and record mode. Table 4-16 Description of fisheye parameters Parameter Description Install Mode You can select Ceiling, Wall, or Ground. ● 1O: The original image before correction. ● 1P: 360°rectangular panoramic image. ●...
  • Page 68 Operation Manual Figure 4-43 Image correction 4.5.1.1.12 Splicing Mode Select the splicing mode to splice several images of different lens to a panoramic image. You can select Merged Splicing or Splicing for Mode. Figure 4-44 Image correction 4.5.1.2 Profile Management The surveillance system works in different ways as profile configured in different time.
  • Page 69 Operation Manual Figure 4-45 General ● When Profile Management is set as Full Time, you can select Day or Night in the Always Enable list, the surveillance system works under Always Enable configuration. Figure 4-46 Full time ● When Profile Management is set as Schedule, you can drag the slide block to set certain time as Day or Night.
  • Page 70 Operation Manual Figure 4-48 Day/Night Step 3 Click Save. 4.5.1.3 Zoom and Focus You can adjust image clarity through auto or manual focus; and adjust the image size through zoom. For details, see "4.2.4.2 Zoom and Focus". 4.5.1.4 Splicing When the panorama contains multiple images of various lens, enable this function. Before splicing, make sure that the surveillance scene is large and there is no shield on the image, and do not move the camera;...
  • Page 71 Operation Manual and path. Click Default, and the device is restored to default configuration. Click Refresh to view the latest configuration. 4.5.2.1 Video Configure video stream parameters, such as stream type, encode mode, resolution, frame rate, bit rate type, bit rate, I frame interval, SVC, and watermark. Select Setting >...
  • Page 72 Operation Manual Parameter Description Enable smart codec to improve video compressibility and save storage space. Smart Codec After smart codec is enabled, the device would stop supporting the third stream, ROI, and smart event detection, and the actual interface shall prevail. The resolution of the video.
  • Page 73 Operation Manual Parameter Description This parameter can be configured only when the Bit Rate Type is set as CBR. Bit Rate Select bit rate value in the list according to actual condition. The number of P frames between two I frames, and the I Frame Interval range changes as FPS changes.
  • Page 74 Operation Manual Table 4-18 Description of snapshot parameter Parameter Description You can select General and Event. ● General: The system takes snapshot as scheduled. For details, see "4.7.2 Setting Schedule". Snapshot Type ● Event: The system takes snapshot when the video detection, audio detection, event, or alarm is triggered.
  • Page 75 Operation Manual Figure 4-52 Privacy masking (1) Figure 4-53 Privacy masking (PTZ dome) Step 2 Configure privacy masking. ● PTZ dome 1. Select the SN. 2. Adjust the live image to the proper location through PTZ, select the color, and then click Draw.
  • Page 76 Operation Manual ● Other cameras 1. Select Enable, and then drag the block to the area that you need to cover. You can drag 4 rectangles at most. ◇ Click Remove All to delete all the area boxes; select one box, and then click ◇...
  • Page 77 Operation Manual 4.5.2.3.2 Configuring Channel Title You can enable this function when you need to display channel title in the video image. Step 1 Select Setting > Camera > Video > Overlay > Channel Title. Figure 4-55 Channel title Step 2 Select the Enable check box, enter the channel title, and then select the text align.
  • Page 78 Operation Manual Figure 4-56 Time title Step 2 Select the Enable check box. Step 3 Select the Week Display check box. Step 4 Move the time box to the position that you want in the image. Step 5 Click Save. 4.5.2.3.4 Configure Text Overlay You can enable this function if you need to display text in the video image.
  • Page 79 Operation Manual is displayed in the video image. Click to expand the text overlay, and you can expand 9 lines at most. Step 3 Move the text box to the position that you want in the image. Step 4 Click Save. 4.5.2.3.5 Configure Font Attribute You can enable this function if you need to adjust the font size in the video image.
  • Page 80 Operation Manual Figure 4-59 Picture overlay Step 2 Select the Enable check box, click Upload Picture, and then select the picture to be overlaid. The picture is displayed on the video image. Step 3 Move the overlaid picture to the position that you want in the image. Step 4 Click Save.
  • Page 81 Operation Manual 4.5.2.3.8 Configuring OSD Info You can enable this function if you want to display the information of preset, PTZ coordinates, zoom, tour and location on the video image. Only tracking speed dome supports OSD info function. Step 1 Select Setting >...
  • Page 82 Operation Manual 4.5.2.3.9 Configuring Counting The image displays statistics of the enter number and leave number. When the overlay function is enabled during intelligent rules configuration, this function is enabled simultaneously. Step 1 Select Setting > Camera > Video > Overlay > Counting. Figure 4-62 Counting Step 2 Select the Enable check box, and then configure counting method and alignment.
  • Page 83 Operation Manual Step 4 Click Save. 4.5.2.3.11 Configuring GDP Position The image displays GPS position. When the overlay function enabled during intelligent rules configuration, this function is enabled simultaneously. Select Setting > Camera > Video > Overlay > GDP Position. Step 1 Figure 4-64 GDP position Step 2...
  • Page 84 Operation Manual Figure 4-65 Ranging Step 2 Select the Enable check box, and then set the installation height and time display. Time display: The display time of the ranging information on live image. Step 3 Click Save. 4.5.2.3.13 Configuring ANPR The image displays ANPR statistics information.
  • Page 85 Operation Manual 4.5.2.3.14 Configuring Face Statistics The image displays face statistics information. When the overlay function enabled during intelligent rules configuration, this function is enabled simultaneously. Step 1 Select Setting > Camera > Video > Overlay > Face Statistics. Figure 4-67 Face statistics Step 2 Select the Enable check box, and select text align.
  • Page 86 Operation Manual Figure 4-68 ROI Step 2 Select the Enable check box, draw the area on the image, and then configure the image quality of ROI. ● You can draw four area boxes at most. ● The higher the image quality value is, the better the quality will be. ●...
  • Page 87 Operation Manual Table 4-20 Description of path Parameter Description The snapshot of live interface. The default path is Live Snapshot C:\Users\admin\WebDownload\LiveSnapsh The recorded video of live interface. Live Record The default path is C:\Users\admin\WebDownload\LiveRecord. The snapshot of playback interface. The default path is Playback Snapshot C:\Users\admin\WebDownload\PlaybackSn Admin in the path refers to...
  • Page 88 Operation Manual Figure 4-70 Audio Step 2 Select the Enable check box in Main Stream or Sub Stream. For the camera with multiple channels, select the channel number. Please carefully activate the audio acquisition function according to the actual requirements of the application scenario. Step 3 Configure audio parameters.
  • Page 89 Operation Manual ● Click to play the selected audio. ● Click to download the audio to local storage. Step 1 Select Setting > Camera > Audio > Alarm Audio. Figure 4-71 Alarm audio Click Add Audio File. Step 2 Figure 4-72 Add audio file Step 3 Configure the audio file.
  • Page 90 Operation Manual Figure 4-73 TCP/IP Step 2 Configure TCP/IP parameters. Table 4-22 Description of TCP/IP parameters Parameter Description Host Name Enter the host name, and the maximum length is 15 characters. Select the Ethernet card that need to be configured, and the default Ethernet Card one is Wire.
  • Page 91 Operation Manual Parameter Description ● IPv6 does not have subnet mask. Default Gateway ● The default gateway must be in the same network segment with the IP address. Preferred DNS IP address of the preferred DNS Alternate DNS IP address of the alternate DNS Select the check box, get the camera MAC address, and then you can modify and configure the device IP address with ARP/ping command.
  • Page 92 Operation Manual 4.6.2 Port Configure the port numbers and the maximum number of users (includes web, platform client, and mobile phone client) that can connect to the device simultaneously. Step 1 Select Setting > Network > Port. Figure 4-74 Port Step 2 Configure port parameters.
  • Page 93 Operation Manual Parameter Description ● Real time streaming protocol port, and the value is 554 by default. If you play live view with QuickTime, VLC or Blackberry smart phone, the following URL format is available. ● When the URL format requiring RTSP, you need to specify channel number and bit stream type in the URL, and also user name and password if needed.
  • Page 94 Operation Manual The configuration of Max Connection takes effect immediately, and others will take effect after reboot. 4.6.3 PPPoE Point-to-Point Protocol over Ethernet, it is one of the protocols that device uses to connect to the internet. Get the PPPoE username and password from the internet service provider, and then set up network connection through PPPoE, the camera will acquire a WAN dynamic IP address.
  • Page 95 Operation Manual Procedure Step 1 Select Setting > Network > DDNS. ● Third-party server might collect your device information after DDNS is enabled. ● Register and log in to the DDNS website, and then you can view the information of all the connected devices in your account.
  • Page 96 Operation Manual Figure 4-77 SMTP (Email) Step 2 Configure SMTP (Email) parameters. Table 4-25 Description of SMTP (Email) parameters Parameter Description SMTP Server SMTP server address The port number of the SMTP Port server. For details, see Table 4-26. Username The account of SMTP server.
  • Page 97 Operation Manual Parameter Description Mail Receiver Receiver’s email address. Supports 3 addresses at most. The system sends test mail to check if the connection is successfully Health Mail configured. Select Health Mail and configure the Update Period, and then the system sends test mail as the set interval. For the configuration of major mailboxes, see Table 4-26.
  • Page 98 Operation Manual SMTP Authentica Mailbox Port Description server tion ● You need to enable SMTP service in your mailbox. ● The authentication code is required; the email password is not applicable. Authentication code: the code you receive when enabling SMTP service. ●...
  • Page 99 Operation Manual Figure 4-78 UPnP Step 2 Select the Enable check box, and there are two mapping modes: Custom and Default. ● Select Custom, click and then you can modify external port as needed. ● Select Default, and then the system finishes mapping with unoccupied port automatically, and you cannot modify mapping relation.
  • Page 100 Operation Manual Figure 4-79 SNMP (1) Figure 4-80 SNMP (2) Step 2 Select SNMP version to enable SNMP. ● Select V1, and the system can only process information of V1 version. ● Select V2, and the system can only process information of V2 version. ●...
  • Page 101 Operation Manual password and authentication type. It requires corresponding user name, password and authentication type to visit your device from the server. Using V1 and V2 might cause data leakage, and V3 is recommended. In Trap Address, enter the IP address of the PC that has MIB Builder and MG-SOFT MIB Browser installed, and leave other parameters to the default.
  • Page 102 Operation Manual 5. Unfold all the tree lists displayed in the MG-SOFT MIB Browser, and then you can view the configuration information, video channel amount, audio channel amount, and software version. Use PC with Windows OS and disable SNMP Trap service. The MG-SOFT MIB Browser will display prompt when alarm is triggered.
  • Page 103 Operation Manual Figure 4-82 Multicast Step 2 Select the Enable check box, and enter IP address and port number. Table 4-28 Description of multicast parameters Parameter Description The multicast IP address of Main Stream/Sub Stream is 224.1.2.4 Multicast Address by default, and the range is 224.0.0.0–239.255.255.255. The multicast port of corresponding stream: Main Stream: 40000;...
  • Page 104 Operation Manual 4.6.11 QoS You can solve problems such as network delay and congestion with this function. It helps to assure bandwidth, reduce transmission delay, packet loss rate, and delay jitter to improve experience. 0–63 means 64 degrees of priority; 0 for the lowest and 63 the highest. Step 1 Select Setting >...
  • Page 105 Operation Manual Figure 4-85 Dialing setting Table 4-31 Dialing setting Parameters Parameter Description Wireless Net Type Select the wireless net type according to the carrier. Acquired from the carrier. Authentication Mode Select the authentication mode according to different carrier. The number is different according to different carrier, and it Dial-up Number can be acquired from carrier.
  • Page 106 Operation Manual 4.6.12.2 Mobile Setting Configure the mobile phone, and all alarm messages support sending message the configured receiver. After receiving a message, the receiver can active the camera and connect it to 5G network through message or call. ● Message send: Set the receiver's phone number, and when an alarm is triggered, the system will send message to the receiver.
  • Page 107 Operation Manual ● Select a phone number, and click to delete it. ● You can edit the message in Title during configuration. Figure 4-86 Mobile setting 4.6.13 Access Platform 4.6.13.1 P2P P2P is a private network traversal technology which enables users to manage devices easily without requiring DDNS, port mapping or transit server.
  • Page 108 Operation Manual Figure 4-87 P2P ● When P2P is enabled, remote management on device is supported. ● When P2P is enabled and the device accesses to the network, the status shows online. The information of the IP address, MAC address, device name, and device SN will be collected.
  • Page 109 Operation Manual Step 3 Click Save. 4.6.13.3 RTMP Through RTMP, you can access the third-party platform (such as Ali and YouTube) to realize video live view. ● RTMP can be configured by admin only. ● RTMP supports the H.264, H.264 B and H.264H video formats, and the AAC audio format only. Select Setting >...
  • Page 110 Operation Manual Step 4 Click Save. 4.7 Storage This section introduces how to manage saved resources (such as recorded video) and storage space. The storage management helps to make best use of storage space. 4.7.1 Setting Storage Plan ● Setting record plan and record control to achieve all-time recording, recording in specific period or alarm linked recording.
  • Page 111 Operation Manual Figure 4-90 Holiday schedule Step 2 Select Record or Snapshot. Step 3 Select the days you need to set as holiday. Those days with yellow color indicates that they were set as holidays. When holiday schedule setting is not the same as the general setting, holiday schedule setting is prior to the general setting.
  • Page 112 Operation Manual Figure 4-91 Path Step 2 Select the storage method that you need for the recorded videos and snapshots of different types. Table 4-33 Description of path parameters Parameter Description Select from Scheduled, Motion Detection and Alarm. Event Type Local Save in the internal SD card.
  • Page 113 Operation Manual ● Click Read Only, and then the SD card is set to read only. ● Click Read & Write, and then the SD card is set to read & write. ● Click Hot Swap, and then you can pull out the SD card. ●...
  • Page 114 Operation Manual Figure 4-93 FTP Figure 4-94 Picture name settings Table 4-34 Description of FTP parameters Parameter Description Server Address The IP address of the FTP server. Port The port number of the FTP server.
  • Page 115 Operation Manual Parameter Description Username The user name to log in to the FTP server. Password The password to log in to the FTP server. Remote Directory The destination path in the FTP server, and it is shared by default. Directory Structure Set the directory structure, which supports three levels at most.
  • Page 116 Operation Manual ● NFS (Network File System): A file system which enables computers in the same network share files through TCP/IP. ● SMB (Server Message Block): Provides shared access for clients and the server. Step 3 Configure NAS parameters. Table 4-35 Description of NAS parameters Parameter Description Server Address...
  • Page 117 Operation Manual Parameter Description Language Select system language. Video Standard Select video standard from PAL and NTSC. Select On or Off. This function is available on models with analog output. TVOut ● If the TV out is On, smart plans will be disabled; if the smart plans are enabled, the TV out will be set as Off.
  • Page 118 Operation Manual Parameter Description Select the check box, and then NTP (network time protocol) is enabled, NTP Server. the system then syncs time with the internet server in real time. Time Zone You can also enter the IP address, time zone, port, and interval of a PC Port which installed NTP server to use NTP.
  • Page 119 Operation Manual When splicing the image through selecting lenses, you need to select the continuous splicing screens. The screen with the icon (deeper color) means the first screen of the splicing. You can select any screen as the first one, and select the following screens continuously.
  • Page 120 Operation Manual Figure 4-100 Username Step 2 Click Add User. Figure 4-101 Add user (operation permission)
  • Page 121 Operation Manual Figure 4-102 Add user (restricted login) Step 3 Configure user parameters. Table 4-38 Description of user parameters (1) Parameter Description User’s unique identification. You cannot use existed user Username name. Password Enter password and confirm it again. The password must consist of 8 to 32 non-blank characters and contain at least two types of characters among upper Confirm Password case, lower case, number, and special character (excluding...
  • Page 122 Operation Manual Parameter Description Select authorities as needed. Operation Permission You are recommended giving fewer authorities to normal users than advance users. Set the PC address that allows the defined user to log in to the camera and the validity period and time range. You can log in to web with the defined IP in the defined time range of validity period.
  • Page 123 Operation Manual Figure 4-103 Change password through old password (Login with non-admin account) Admin Account: Change the password through entering the admin password, and then the ◇ new password for the non-admin account to be changed. Figure 4-104 Change password through admin password (login with admin account) ●...
  • Page 124 Operation Manual Admin account cannot be deleted. ● View the authorities If the current account has with the permission of user management, click to view the login authorities of other accounts. If not, you can only view the login authorities of the current account.
  • Page 125 Operation Manual Figure 4-106 Add group Step 3 Enter the group name and memo, and then select group authorities. Step 4 Click Save to finish configuration. The newly added group displays in the group name list. ● After adding group, click to modify group memo or authorities;...
  • Page 126 Operation Manual Figure 4-108 Add user Step 3 Configure user parameters. Table 4-39 Description of user parameters (2) Parameter Description Username User’s unique identification. You cannot use existed user name. Password Enter password and confirm it again. The password must consist of 8 to 32 non-blank characters and contain at least two types of characters among upper case, lower case, Confirm Password number, and special character (excluding ' "...
  • Page 127 Operation Manual Figure 4-109 Change password through old password (login with non-admin account) Admin Account: Change the password through entering the admin password, and then the ◇ new password for the non-admin account to be changed. Figure 4-110 Change password through admin password (login with admin account) ●...
  • Page 128 Operation Manual Admin account cannot be deleted. ● View the authorities If the current account has the permission of user management, click to view the login authorities of other accounts. If not, you can only view the login authorities of the current account.
  • Page 129 Operation Manual Function Description Enable this function, and then other devices can access through CGI Service this service. Enable this function, and then other devices can access through Onvif Service this service. Enable this function, and then other devices can access through Genetec Service this service.
  • Page 130 Operation Manual Figure 4-113 HTTPS dialog box ● For uploading the authenticated certificate, click Browse to select the certificate and certificate key, click Upload to upload them, and then skip to Step5. Step 3 Enter the required information and then click Create. The entered IP or Domain name must be the same as the IP or domain name of the device.
  • Page 131 Operation Manual Figure 4-115 File download Click Open. Step 7 Figure 4-116 Certificate information Click Install Certificate. Step 8...
  • Page 132 Operation Manual Figure 4-117 Certificate import wizard (1) Step 9 Click Next. Figure 4-118 Certificate Store Step 10 Select the storage location and click Next.
  • Page 133 Operation Manual Figure 4-119 Certificate import wizard (2) Step 11 Click Finish and a dialog box showing The import was successful pops up. Figure 4-120 Import succeeds 4.8.5.3 Firewall Configure Network Access, PING prohibited and Prevent Semijoin to enhance network and data security.
  • Page 134 Operation Manual ● You cannot set allowlist or blocklist for camera IP or MAC addresses. ● You cannot set allowlist or blocklist for port MAC addresses. ● When the IP addresses of the camera and your PC are in the same LAN, MAC verification takes effect.
  • Page 135 Operation Manual Figure 4-122 Add IP/MAC Step 3 Configure parameters. Table 4-41 Description of adding IP/MAC parameters Parameter Description Select IP address, IP segment, MAC address or all IP addresses. ● IP address: Select IP version and enter the IP address of the host to be added.
  • Page 136 Operation Manual Figure 4-123 Serial port settings Step 2 Configure serial port settings parameters. Table 4-42 Description of serial port settings parameters Parameter Description The corresponding device address. It is 1 by default. Address Make sure that the address is the device address; otherwise you cannot control the device.
  • Page 137 Operation Manual Figure 4-124 External Light Step 2 Configure external light work mode. Table 4-43 Description of external light parameters Parameter Description ● Off: Turn off the external light. ● Manual: Set the light brightness manually. Work Mode ● Auto: The camera turns on or turns off the light according to the light time and photoresister automatically.
  • Page 138 Operation Manual Figure 4-125 Wiper Step 2 Configure wiper work mode. Table 4-44 Description of wiper parameters Parameter Description The interval time between stop mode and start mode. For example, set Interval Time the time to10 s, and the wiper will work every 10 s. Start Set the work status of the wiper.
  • Page 139 Operation Manual 5 Event This chapter introduces intelligent event settings, including smart track, panoramic calibration, video detection, audio detection, smart plan, IVS, face detection, face recognition, people counting, heat map, video Metadata, alarm, and abnormality. 5.1 Setting Alarm Linkage 5.1.1 Alarm Linkage When configuring alarm events, select alarm linkages (such as record, snapshot).
  • Page 140 Operation Manual Figure 5-1 Alarm linkage 5.1.1.1 Setting Period Set arming periods. The system only performs corresponding linkage action in the configured period. Step 1 Click Setting next to Period.
  • Page 141 Operation Manual Figure 5-2 Period Step 2 Set arming periods. Alarms will be triggered in the time period in green on the timeline. ● Method one: Directly press and drag the left mouse button on the timeline. ● Method two: Enter an actual time period. 1.
  • Page 142 Operation Manual Figure 5-3 Record Step 2 Set record plan. Green represents normal record plan (such as timing recording); yellow represents motion record plan (such as recording triggered by intelligent events); red represents alarm record plan (such as recording triggered by alarm-in). ●...
  • Page 143 Operation Manual Make sure that the SD card is authenticated before recording if you use Dahua smart card. For details, see "4.5.2.5 Path". Step 1 Select Setting > Storage > Record Control. Figure 5-5 Record control Step 2 Set parameters. Table 5-1 Description of record control parameters Parameter Description...
  • Page 144 Operation Manual Figure 5-6 Record linkage 5.1.1.3 Snapshot Linkage After snapshot linkage is configured, the system can automatically alarm and take snapshots when an alarm is triggered. After Motion is enabled in Snapshot, the system takes snapshots when an alarm is triggered. For querying and setting snapshot storage location, see "4.5.2.5 Path".
  • Page 145 Operation Manual Figure 5-8 Setting (snapshot time period) 2. Select a day, and the alarm type next to a period. Then set the period. Select All or check boxes of some days to set the time period of multiple days at ◇...
  • Page 146 Operation Manual Figure 5-11 Email linkage 5.1.1.6 PTZ Linkage When an alarm is triggered, the system links PTZ to do some operations. For example, the system links PTZ to rotate to the preset X. Figure 5-12 PTZ linkage 5.1.1.7 Warning Light Linkage When an alarm is triggered, the system can automatically enable the warning light.
  • Page 147 Operation Manual Figure 5-14 Audio linkage 5.1.2 Subscribing Alarm 5.1.2.1 About Alarm Types For alarm types and preparations of alarm events, see Table 5-2. Table 5-2 Description of alarm types Alarm Type Description Preparation Motion detection is enabled. For The alarm is triggered when Motion Detection details, see "5.4.1 Setting Motion moving object is detected.
  • Page 148 Operation Manual Alarm Type Description Preparation Voltage detection is enabled. For The alarm is triggered when the Security Exception details, see "5.19.5 Setting device detects malicious attack. Security Exception". 5.1.2.2 Subscribing Alarm Information You can subscribe alarm event. When a subscribed alarm event is triggered, the system records detailed alarm information at the right side of the interface.
  • Page 149 Operation Manual 5.2.1 Setting Calibration Parameters for Smart Track The camera has calibration parameters by default, and you can modify the parameters manually when the effect is not good with default setting. Auto calibration mode is available on some select models. Select Setting >...
  • Page 150 Operation Manual Figure 5-17 Manual calibration (1) Figure 5-18 Manual calibration (2) 1) Adjust the speed dome lens and turn it to the same view as the chosen lens, and then click The calibration boxes are displayed in both images.
  • Page 151 Operation Manual 2) Pair each box in the two images, and keep the paired boxes at the same spot of the live view. 3) Click You need at least 4 pairs of calibration boxes to ensure the views of the speed dome and the panoramic camera as similar as possible.
  • Page 152 Operation Manual Parameter Description Idle Time It is an interval from the end of alarm track of the speed dome to the start of idle mode. Set Idle Time and Idle Position. If no event needs to be tracked after the configured idle time, the device automatically rotates to the set idle position.
  • Page 153 Operation Manual Figure 5-20 Panoramic calibration Step 2 Select channel 2, and then select a calibration number under the video images in turns (See Figure 5-21) to add calibration points to the corresponding video images. Take Calibrate 1 as an example. Figure 5-21 Selecting a calibration number 1) Adjust the PTZ angle of channel 1 through the PTZ control interface to rotate the center of channel 1 to a position aligned with the green point in Calibrate 1 image, and then...
  • Page 154 Operation Manual 5.4 Setting Video Detection Check whether there are considerable changes on the video by analyzing video images. In case of any considerable change on the video (such as moving object, fuzzy image), the system performs an alarm linkage. 5.4.1 Setting Motion Detection The system performs an alarm linkage when the moving object appears on the image and its moving speed reaches the preset sensitivity.
  • Page 155 Operation Manual Figure 5-22 Motion detection Step 2 Select the Enable check box to enable motion detection function. Step 3 Set the area for motion detection. 1) Click Setup next to Area.
  • Page 156 Operation Manual Figure 5-23 Area 2) Select a color and set the region name. Select an effective area for Motion Detection in the image and set Sensitivity and Threshold. ● Select a color on to set different detection parameters for each region. ●...
  • Page 157 Operation Manual function is available on some select models. Figure 5-24 Video tampering Table 5-4 Description of video temper parameter Parameter Description Temper Area When the percentage of the tampered image and the duration exceed the configured values, an alarm will be triggered. Duration The tamper area is 30% and the duration is 5 s by default.
  • Page 158 Operation Manual Figure 5-25 Scene changing Step 2 Set arming periods and alarm linkage action. For details, see "5.1.1 Alarm Linkage". Step 3 Click Save. 5.5 Setting Smart Motion Detection The system performs alarm linkage when human, non-motorized vehicle, or motor vehicle appear on the image and its moving speed reaches the preset sensitivity.
  • Page 159 Operation Manual Figure 5-26 Smart motion detection Select the Enable check box to enable the smart motion detection function. Step 2 Step 3 Set effective object and sensitivity. ● Effective object: Includes Human and Motor vehicle. When you select Human, the camera will detect human and non-motorized vehicle.
  • Page 160 Operation Manual Figure 5-27 Audio detection Step 2 Set parameters. ● Input abnormal: Select the Enable Input Abnormal check box, and the alarm is triggered when the system detects abnormal sound input. ● Intensity change: Select the Enable Intensity Change check box and then set Sensitivity and Threshold.
  • Page 161 Operation Manual threshold for noisy environment. The red line in the waveform indicates audio detection is triggered, and the green ◇ one indicates no audio detection. Adjust sensitivity and threshold according to the waveform. Step 3 Set arming periods and alarm linkage action. Step 4 Click Save.
  • Page 162 Operation Manual The selected smart function is highlighted. Click it again to cancel the selection. Click Save. Step 3 5.8 Setting IVS This section introduces scene selection requirements, rule configuration, and global configuration for IVS (intelligent video surveillance). Basic requirements on scene selection are as follows. ●...
  • Page 163 Operation Manual such as vehicle parked at roadside or road lamp poles. Arrange three persons to draw at each of the three positions in the monitoring scene. Horizontal ruler: Select reference object with known length on the ground, such as sign on ◇...
  • Page 164 Operation Manual 3. Set calibration area and ruler. a. Click Add Calibration Area and draw a calibration area in the image. b. Select a calibration type and enter the actual length, and then click Add Rulers. c. Draw one horizontal ruler and three vertical rulers in the calibration area. 4.
  • Page 165 Operation Manual Rule Description Applicable Scene Scenes with sparse targets and without obvious and frequent light change. Simple scene in the detection area is recommended. ● Missed alarm might increase in the scenes with dense targets, When an object is abandoned in the Abandoned object detection area over the set time, the frequent occlusion, and...
  • Page 166 Operation Manual Rule Description Applicable Scene Scenes with medium or long distance, such as outdoor When the crowd gathers or the crowd plaza, government entrance, Crowd gathering density is large, the system performs station entrance and exit. It is alarm linkages. not suitable for short-distance view analysis.
  • Page 167 Operation Manual Table 5-8 Description of IVS analysis Rule Description Tripwire Draw a detection line. Intrusion Draw a detection area. ● During the detection of abandoned object, the alarm is also Abandoned object triggered if pedestrian or vehicle stays for a long time. If the Missing object abandoned object is smaller than pedestrian and vehicle, set Fast moving...
  • Page 168 Operation Manual Parameter Description triggered, the camera automatically tracks the person or object that triggers the alarm. Tracking time is the duration that the camera automatically tracks the object. Before enabling this function, you need to enable or disable the Track Time Alarm Track function under Smart Track as needed.
  • Page 169 Operation Manual Calibration Purpose Determine corresponding relationship between 2D image captured by the camera and 3D actual object according to one horizontal ruler and three vertical rulers calibrated by the user and the corresponding actual distance. Notes When drawing calibration ruler, keep the ruler length consistent with the actual length of the object. Procedure 1.
  • Page 170 Operation Manual Procedure Step 1 Select Setting > Event > Crowd Map > Crowd Map. Figure 5-31 Crowd map Select the Enable check box, and then the crowd map function is enabled. Step 2 Click Draw Detection Area to draw global area for detecting crowd distribution in the Step 3 image.
  • Page 171 Operation Manual Parameter Description Select the Smart Track check box, and when alarm is triggered by the panoramic camera, the speed dome automatically turns to the position where alarm is triggered. The tracking time is "idle time + five seconds." For the details of idle time configuration, see "5.2.2 Enabling Alarm Track"...
  • Page 172 Operation Manual Figure 5-33 Crowd map (2) 5.10 Setting Face Recognition When a face is detected or recognized in the detection area, the system performs alarm linkage and supports searching face detection and recognition results. ● Face Detection: When a face is detected in the area, the system performs alarm linkage, such as recording and sending emails.
  • Page 173 Operation Manual Figure 5-35 Face detection Select the Enable check box to enable the face detection function. Step 2 (Optional) Click Draw next to Detect Region to draw a face detection area in the image. Step 3 (Optional) Click Draw next to Exclude Region to draw a non-face detection area in the Step 4 Detect Region.
  • Page 174 Operation Manual Parameter Description Set a range for snapping face image, including face picture, one-inch picture, and custom. When selecting Custom, click Setting, configure the parameters on the prompt interface, and then click OK. ● Customized width: Set snapshot width; enter the times of the Snap Face Image original face width.
  • Page 175 Operation Manual detected. Face database configuration includes creating face database, adding face picture, and face modeling. 5.10.2.1 Creating Face Database Face database includes face picture, face data and other information. It also provides comparison data for the captured face pictures. Step 1 Select Setting >...
  • Page 176 Operation Manual Figure 5-38 Face database successfully added Step 5 Set parameters. Table 5-12 Description of face database parameters Parameter Description Select the Deploy check box, and the face database deployment is Deploy enabled. The captured face picture is compared to the armed face database.
  • Page 177 Operation Manual Figure 5-39 Face database configuration Click Registration. Step 3 Figure 5-40 Registration (1) Step 4 Click Upload Picture, select a face picture to be uploaded, and then click Open.
  • Page 178 Operation Manual You can manually select the area for a face. After uploading picture, box select a face and click OK. When there are multiple faces in a photo, select the target face and click OK to save face picture. Figure 5-41 Registration (2) Step 5 Enter the information about face picture according to the actual situation.
  • Page 179 Operation Manual Parameter Error Description The quality of the added pictures is to the 0x1134000E upper limit. The space of the face database exceeds the 0x11340019 upper limit. The picture format is not correct. Import the picture in JPG format. No face in the picture or the face is not clear.
  • Page 180 Operation Manual Figure 5-43 Batch add Step 4 Click to select file path. Figure 5-44 Batch import Step 5 Click Browse. The interface shows import process. After finishing the import, the interface shown as Figure 5-45 is displayed. Figure 5-45 Importing successfully 5.10.2.3 Managing Face Picture Add face pictures to face database, and then manage and maintain face pictures to ensure correct information.
  • Page 181 Operation Manual 5.10.2.3.1 Modifying Face Information Go to the Face Database Config interface, set filtering condition as needed, and click Step 1 Search. The search result is displayed. Step 2 Select the row where the face picture or the personnel information is located, and then click Figure 5-46 Face information modification Step 3...
  • Page 182 Operation Manual intelligent detections can be realized. ● The more the selected face pictures are, the longer time the face modeling takes. Please wait patiently. ● During modeling, some intelligent detection functions (such as face recognition) are not available temporarily, and will be available after modeling. Step 1 Select Setting >...
  • Page 183 Operation Manual Figure 5-49 Failed modeling Click Search, and the face details are displayed. Click to view the face picture in list format. See Figure 5-50. Click to view the face picture in thumbnail format. See Figure 5-51. When the modeling status is Valid in the list or is displayed on the left corner of the ◇...
  • Page 184 Operation Manual Figure 5-52 Alarm (face recognition) Step 2 Select a face database and an alarm rule. ● Face recognition succeeded: When the detected face matches that in the face database, the device links alarm out. ● Face recognition failed: When the detected face fails to match that in the face database, the device links alarm out.
  • Page 185 Operation Manual ● Face recognition result is displayed at the left side and the captured face pictures and attribute information at the right side. ● Click a face picture in the display area, and the information is displayed. Figure 5-53 Face recognition result 5.10.4.2 Viewing Result by Search Function View face recognition or face snapshot result.
  • Page 186 Operation Manual Figure 5-55 Search result (face recognition) Figure 5-56 MoreInfo (face recognition) 5.11 Setting Face Detection When a face is detected in the detection area, the system performs an alarm linkage. Prerequisites...
  • Page 187 Operation Manual Select Setting > Event > Smart Plan, and then enable Face Detection. Procedure Step 1 Select Setting > Event > Face Detection. Figure 5-57 Face detection Step 2 Select the Enable check box to enable the face detection function. Step 3 (Optional) Click Draw next to Detect Region to draw a face detection area in the image.
  • Page 188 Operation Manual Parameter Description Set a range for snapping face image, including face picture, one-inch picture, and custom. When selecting Custom, click Setting, configure the parameters on the prompt interface, and then click OK. ● Customized width: Set snapshot width; enter the times of the Snap Face Image original face width.
  • Page 189 Operation Manual Result The face detection result is displayed on the live interface. ● The face pictures captured in real time and their attribute information is displayed. ● Click a face picture in the display area, and the details are displayed. Figure 5-58 Face detection result 5.12 Setting People Counting People counting (including enter number, leave number and strand number in area), calibration...
  • Page 190 Operation Manual Figure 5-59 People counting...
  • Page 191 Operation Manual Figure 5-60 In area No. Step 2 Click to add the people counting function. Step 3 Double-click the name to modify the rule name. Select People Counting or In Area No. ● People Counting: The system counts the people entering and leaving the detection area.
  • Page 192 Operation Manual Table 5-16 Description of people counting parameters Parameter Description Select the OSD check box or select the Enter No. or Leave No. check box under OSD to display the people counting data in the image. Click Clear to clear the count. Flip Set the viewing angle of the image as Inclined or Vertical.
  • Page 193 Operation Manual Figure 5-61 Counting result 5.12.2 Calibration Configuration After configuring the rule for people counting, set the installation height and angle of the camera through calibration configuration. Prerequisites You have set at least one rule in Setting > Event > People counting > People Counting. Procedure Select Setting >...
  • Page 194 Operation Manual Figure 5-62 Calibration configuration (stereo analysis) Click Clear to clear the default calibration box. Step 2 Click Ground to draw a rectangular box in the image. Step 3 Ground should be on the same plane and as big as possible for calibration. Step 4 Click Save, and then the camera calculates its height above the ground and the angle it forms with the ground.
  • Page 195 Operation Manual Figure 5-63 Queuing Step 2 Click to add the queuing function. You can add 4 rules at most. Step 3 Double-click the name to modify the rule name. Click Draw Rule to draw a detection area in the image, and right-click to complete the drawing. Step 4 Set parameters.
  • Page 196 Operation Manual Parameter Description Set the minimum height of the people in detection area. The unit Min Height is cm, and the range is 0–200. Step 5 Set arming periods and alarm linkage actions. For details, see "5.1.1 Alarm Linkage". Step 6 Click Save.
  • Page 197 Operation Manual Figure 5-65 Diagram Step 2 Select the Enable check box to enable diagram function. And then you can search the diagram during the set period. Step 3 Set the searching criteria. Table 5-18 Description of searching criteria Parameter Description Select the report type from the following two types: ●...
  • Page 198 Operation Manual Figure 5-66 Diagram With the ruler on the right, you can read the diagram clearly. 5.12.5 Viewing People Counting Report Generate people counting data in report form. Step 1 Select Setting > Event > People Counting > People Counting Report. Figure 5-67 People counting report Step 2 Set search conditions.
  • Page 199 Operation Manual Parameter Description The statistical type of people counting report. ● When you select Number of people, the system generates the report of the number of people that exceeds the configured Statistics Type number of people. ● When you select Average stranding time, the system generates the report of the average stranding time that exceeds the average stranding time.
  • Page 200 Operation Manual Figure 5-68 Heat map Step 2 Select the Enable check box to enable the heat map function. Step 3 Set the arming period. For details, see "5.1.1.1 Setting Period". Step 4 Click Save. 5.13.2 Viewing Heat Map Report The system can export heat map data as a report.
  • Page 201 Operation Manual Live interface. Prerequisites Select Setting > Event > Smart Plan, and then enable Vehicle Density. Procedure Step 1 Select Setting > Event > Vehicle Density. Figure 5-70 Vehicle density (traffic congestion)
  • Page 202 Operation Manual Figure 5-71 Vehicle density (parking upper limit) Step 2 Click to add the vehicle density function. Double-click the name to modify the rule name. Select Traffic Congestion or Parking Step 3 Upper Limit. ● Traffic Congestion: The system counts the vehicles in the detection area. When the counted vehicle number and the continuous congestion time exceed the configured values, an alarm is triggered and the system performs an alarm linkage.
  • Page 203 Operation Manual Parameter Description Select the check box, and set the Threshold. Upper Limit Vehicle When the counted vehicle exceeds the configured values, an Quantity Alarm alarm is triggered. Click Draw Target next to Pixel Counter, and then press and hold Pixel Counter the left mouse button to draw a rectangle, the Pixel Counter then displays its pixel.
  • Page 204 Operation Manual Figure 5-73 Parking upper limit 5.15 Setting Stereo Analysis Stereo analysis includes rule configuration and calibration configuration. 5.15.1 Setting Rules for Stereo Analysis The rules for stereo analysis include Activation Analysis, Back Detection, Fall Detection, Walking Detection, Blackboard Writing Detection, Violence Detection, People No. Error,, Stand Detection, Running Detection, People Approaching Detection, and Strand Detection.
  • Page 205 Operation Manual Rule Function Applicable Scene When the camera that monitors the front of the classroom works with a Walking Detection recording & broadcasting server, Classrooms and detects a working target, an alarm will be triggered. When the camera that monitors the front of the classroom works with a recording &...
  • Page 206 Operation Manual Rule Function Applicable Scene When the camera detects a running Running Detection Classrooms person, an alarm will be triggered. When the distance between two People Approaching walking/standing people reaches Banks and educational Detection the configured value, an alarm will institutions be triggered.
  • Page 207 Operation Manual area. ● When configuring Back Detection, draw the front of a classroom as the detection area. ● When configuring Blackboard Writing Detection, draw the blackboard as the detection area, and make sure that the detection are larger than the blackboard. Click Draw Close-up Area draw the blackboard as the close-up area.
  • Page 208 Operation Manual Parameter Description ● For people No. error function for a recording device, select Tracking Mode as Close-up Mode. Then the camera traces the teacher’s walking trajectory. You can view the tracking effect through sub stream 1 of the live interface. When the number of people on the image is not 1, the full screen is displayed.
  • Page 209 Operation Manual Procedure Step 1 Select Setting > Event > Stereo Analysis > Calibration Config. Figure 5-75 Calibration configuration (stereo analysis) Click Clear to clear the default calibration box. Step 2 Step 3 Click Ground to draw a rectangular box in the image. Ground should be on the same plane and as big as possible for calibration.
  • Page 210 Operation Manual ● When calibrating the zoom for Stand Detection, make sure that there is 1 person in the image at least. ● When calibrating the zoom for People No. Error, make the calibration box in the center of the image, and the zoom value larger than 3. Some models only support calibration by drawing calibration area.
  • Page 211 Operation Manual Figure 5-77 Report 5.16 Setting ANPR Extract information of motor vehicles and display related attributes on the live interface. 5.16.1 Scene Configuration Configure non-motor vehicle detection. Prerequisites Select Setting > Event > Smart Plan, and then enable ANPR. Procedure Select Setting >...
  • Page 212 Operation Manual Figure 5-78 Scene set (ANPR) Step 2 Click Draw to draw a detect region and an exclude region in the image. ● Detect region: The region that needs to be detected. ● Exclude region: The region that does not need to be detected. Click Modify to modify the drawn region.
  • Page 213 Operation Manual ● Click the picture in the display area, and the detailed information is displayed. Figure 5-79 ANPR result 5.16.2 Setting Picture Overlay Set overlay of motor vehicle. Step 1 Select Setting > Event > ANPR > Picture. Figure 5-80 Picture Select Motor Vehicle from the Type drop-down list.
  • Page 214 Operation Manual 5.16.3 Viewing ANPR Report Generate data of ANPR in report form. Step 1 Select Setting > Event > ANPR > Report. Figure 5-81 Report Step 2 Select the report type, start time, end time, and other parameters. Click Search. Step 3 The statistical results are displayed.
  • Page 215 Operation Manual 5.17.1 Scene Configuration Set the detection scenes and rules, including rules for people, non-motor vehicles and motor vehicles. Select Setting > Event > Smart Plan, and then enable Video Metadata. Take setting of the People Detection rules as an example. Step 1 Select Setting >...
  • Page 216 Operation Manual Parameter Description Select the Capture Whole Vehicle check box to capture whole Capture whole vehicle vehicle. The snapshot is saved in the preset path for monitoring snapshots. For details, see "4.5.2.5 Path". Select the Non-motor Vehicle Flow Statistics check box to Non-motor Vehicle Flow Statistics count the number of non-motor vehicles in the detection area.
  • Page 217 Operation Manual Figure 5-84 Video metadata result 5.17.2 Setting Picture Information Set overlay of motor vehicle, non-motor vehicle and people and the box position. This section takes the configuration of motor vehicle overlay as an example. Step 1 Select Setting > Event > Video Metadata > Picture. Figure 5-85 Picture (video metadata) Select Motor Vehicle from the Type drop-down list.
  • Page 218 Operation Manual 5.17.3 Viewing Video Metadata Report Generate data of video metadata recognition in report form. Step 1 Select Setting > Event > Video Metadata > Report. The Report interface is displayed. Step 2 Select the report type, start time, end time, and other parameters. Step 3 Click Search to complete the report.
  • Page 219 Operation Manual Figure 5-87 Alarm linkage Step 2 Select the Enable check box to enable the alarm linkage function. Step 3 Select a relay-in port and a sensor type. ● Sensor Type: NO or NC. ● Anti-Dither: Only record one alarm event during the anti-dither period. Step 4 Set arming periods and alarm linkage action.
  • Page 220 Operation Manual Figure 5-88 SD card Step 2 Select the event type from the Event Type drop-down list, and then select the Enable check box to enable the SD card detection function. When setting Capacity Warning as Event Type, set Capacity Limit. When the remaining space of SD card is less than this value, the alarm is triggered.
  • Page 221 Operation Manual Step 3 Set alarm linkage actions. For details, see "5.1.1 Alarm Linkage". Click Save. Step 4 5.19.3 Setting Illegal Access When you enter a wrong login password more than the set times, the system performs alarm linkage. Step 1 Select Setting >...
  • Page 222 Operation Manual Figure 5-91 Voltage detection Step 2 Select the Enable check box to enable the voltage detection function. Select Overlay, and the alarm icon is displayed by overlapping when the alarm is triggered. indicates undervoltage and indicates overvoltage. Step 3 Set alarm linkage actions.
  • Page 223 Operation Manual Table 5-25 Security exception description Parameter Description Monitors the programs that run in trusted environment to detect whether there are program running without trusted Trusted environment detected signature. program Select it to prevent the program with trojan and virus. The account tries to login during the period that does not allow user to log in.
  • Page 224 Operation Manual Figure 5-93 Disarming Select the Enable check box to disarm. Step 2 Step 3 (Optional) Select the Enable check box next to Disarm by Period to enable the Disarm by Period function, and then you can disarm by period. For setting disarm period, see "5.1.1.1 Setting Period".
  • Page 225 Operation Manual 6 Maintenance 6.1 Requirements To make sure the system runs normally, maintain it as the following requirements: ● Check surveillance images regularly. ● Clear regularly user and user group information that are not frequently used. ● Modify the password every three months. For details, see "4.8.4 Account". ●...
  • Page 226 Operation Manual 6.3 Resetting Password When you need to reset the password for the admin account, there will be a security code sent to the entered email address which can be used to reset the password. Prerequisites You have enabled password reset service. For details, see "4.8.5.1 System Service". Procedure Step 1 Open IE browser, enter the IP address of the device in the address bar and press Enter.
  • Page 227 Operation Manual Figure 6-4 Reset the password (1) Step 4 Reset the password. Step 5 Scan the QR code, and there will be a security code sent to the email address you entered. Enter the security code as instructed. ● Please use the security code within 24 hours after you receive it. Otherwise, it will become invalid.
  • Page 228 Operation Manual Step 8 Click Save. The login interface is displayed. 6.4 Backup and Default 6.4.1 Import/Export ● Export the system configuration file to back up the system configuration. ● Import system configuration file to make quick configuration or recover system configuration. Step 1 Select Setting >...
  • Page 229 Operation Manual ● Click Default, and then all the configurations except IP address and account are reset to default. ● Click Factory Default, and all the configurations are reset to factory settings. Figure 6-7 Default 6.5 Upgrade Upgrading to the latest system can perfect camera functions and improve stability. If wrong upgrade file has been used, restart the device;...
  • Page 230 Operation Manual upgrading. Click Manual Check to check for upgrade manually. 6.6 Information You can view the information, including version, log and online user, and back up or clear log. 6.6.1 Version You can view device information such as hardware, system version, and web version. Select Setting >...
  • Page 231 Operation Manual mode. ● Event (records events such as video detection, smart plan, alarm and abnormality): includes event start and event end. ● Record: Includes file access, file access error, and file search. ● Account: Includes login, logout, adding user, deleting user, modifying user, adding group, deleting group, and modifying group.
  • Page 232 Operation Manual Figure 6-11 Remote Log Step 2 Select the Enable check box to enable remote log function. Step 3 Set address, port and device number. Step 4 Click Save. 6.6.4 Online User View all the current users logging in to web. Select Setting >...
  • Page 233 Operation Manual Appendix 1 Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks.
  • Page 234 Operation Manual 5. Change Default HTTP and Other Service Ports We suggest you to change default HTTP and other service ports into any set of numbers between 1024~65535, reducing the risk of outsiders being able to guess which ports you are using. 6.
  • Page 235 Operation Manual network isolation effect. ● Establish the 802.1x access authentication system to reduce the risk of unauthorized access to private networks. ● Enable IP/MAC address filtering function to limit the range of hosts allowed to access the device.
  • Page 236 Operation Manual...
