The functions and interfaces of different models might vary, and the actual product shall prevail.
No.
1
2
3
4
4.2.2 Encode bar
For encode bar, see Figure 4-4.
● Main Stream: It has large bit stream value and image with high resolution, but also requires large
bandwidth. This option can be used for storage and monitoring. For details, see "4.5.2.1 Video".
● Sub Stream: It has small bit stream value and smooth image, and requires less bandwidth. This
option is normally used to replace main stream when bandwidth is not enough. For details, see
"4.5.2.1 Video".
● Protocol: You can select the network transmission protocol as needed, and the options are TCP,
UDP and Multicast.
Before selecting Multicast, make sure that you have set the Multicast parameters.
4.2.3 Live View Function Bar
For the live view function bar, see Table 4-2.
Figure 4-3 Live
Table 4-1 Description of function bar
Function
Encode bar
Live view
Live view function bar
Window adjustment bar
Figure 4-4 Encode bar
Description
Sets stream type and protocol.
Displays the real-time monitoring image.
Functions and operations in live viewing.
Adjustment operations in live viewing.
