- Page 1 Bullet Network Camera Quick Start Guide ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD V1.0.2...
-
Page 2: Foreword
Quick Start Guide Foreword General This manual introduces the installation and operations of network camera. Read carefully before using the device, and keep the manual safe for future reference. Safety Instructions The following categorized signal words might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could... - Page 3 Quick Start Guide ● There might be deviations in the description of the technical data, functions and operations, or errors in the print. If there is any doubt or dispute, we reserve the right of final explanation. ● Upgrade the reader software or try other mainstream reader software if the manual (in PDF format) cannot be opened.
-
Page 4: Important Safeguards And Warnings
Quick Start Guide Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, comply with the guidelines when using it. Transportation Requirements ●... - Page 5 Quick Start Guide against lightning. For outdoor scenarios, strictly comply with the lightning protection regulations. ● Ground the function earthing portion of the device to improve its reliability (certain models are not equipped with earthing holes). The device is a class I electrical appliance. Make sure that the power supply of the device is connected to a power socket with protective earthing.
- Page 6 Quick Start Guide ● Use the accessories suggested by the manufacturer. Installation and maintenance must be performed by qualified professionals. ● Do not directly touch the photosensitive CMOS. Use an air blower to clean the dust or dirt on the lens.
-
Page 7: Table Of Contents
Quick Start Guide Table of Contents Foreword ........................................I Important Safeguards and Warnings ............................III 1 Introduction ......................................1 1.1 Cable ........................................ 1 1.2 Connecting Alarm Input/Output ............................2 2 Network Configuration ..................................4 2.1 Initializing the Camera ................................4 2.2 Changing the Device IP Address ............................5 2.3 Logging in to the Webpage .............................. -
Page 8: Introduction
Quick Start Guide 1 Introduction 1.1 Cable Waterproof all the cable joints with insulating tape and waterproof tape to avoid water damage and prevent short circuits from occurring. For details, see the FAQ manual. Figure 1-1 Cables Table 1-1 Cable information Port name Description Inputs 12 VDC power. -
Page 9: Connecting Alarm Input/Output
Quick Start Guide 1.2 Connecting Alarm Input/Output The camera can connect to external alarm input/output devices through the digital input/output port. Alarm input/output is available on select models. Step 1 Connect the alarm input device to the alarm input end of the I/O port. See Figure 1-2. The device collects different statuses of the alarm input port while the input signal is idling and being grounded. - Page 10 Quick Start Guide when an alarm occurs. Set the input mode to "NO" (default) if the alarm input signal is logic "0", and to "NC" if the alarm input signal is logic "1". ● The alarm output on the webpage corresponds to the alarm output end of the device, which is also the alarm output end of the I/O port.
-
Page 11: Network Configuration
Quick Start Guide 2 Network Configuration Device initialization and IP setting can be finished with the ConfigTool or on webpage. For more information, see the Web Operation Manual. ● Device initialization is available on select models, and it is required at first-time use and after device is being reset. -
Page 12: Changing The Device Ip Address
Quick Start Guide If initialization failed, click to see more information. Click Finish. Step 4 2.2 Changing the Device IP Address ● You can change the IP address of one or more devices at a time. This section is based on changing IP addresses in batches. -
Page 13: Installation
Quick Start Guide 3 Installation 3.1 Packing List ● Tools required for installation, such as the electric drill, are not included in the package. ● The operation manual and information on the tools are on the disk or the QR code. Figure 3-1 Packing list 3.2 Dimensions Figure 3-2 Dimensions (Unit: mm [inch]) -
Page 14: Installing The Camera
Quick Start Guide 3.3 Installing the Camera 3.3.1 Installation Methods Figure 3-3 Installation methods 3.3.2 (Optional) Installing SD Card ● SD card slot is available on select models. ● Disconnect the power before installing or removing the SD card. Press the reset button for 10 seconds to reset the device. Figure 3-4 Install SD card 3.3.3 Attaching the Camera Make sure that the mounting surface is strong enough to hold at least three times the weight of the... -
Page 15: Optional) Installing Waterproof Connector
Quick Start Guide device and bracket. Figure 3-5 Cable going through the side cable tray Figure 3-6 Cable going through the mounting surface 3.3.4 (Optional) Installing Waterproof Connector This part is needed only when there is waterproof connector in the package and the device is used outdoors. -
Page 16: Adjusting The Lens Angle
