- Page 1 Dahua HD IR Bullet Network Camera Quick Start Guide Dahua HD IR Bullet Network Camera Quick Start Guide Version 1.0.0 ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.
- Page 2 Dahua IR Bullet Network Camera Quick Start Guide Welcome Thank you for purchasing our network cameras. This user’s manual is designed to be a reference tool for using your product. Please read the following safeguards and warnings carefully before you use this series product. Please keep this user’s manual well for future reference.
- Page 3 Dahua IR Bullet Network Camera Quick Start Guide Do not directly touch the heat dissipation component of the device to avoid scald. Do not dismantle the device because there is no component that can be fixed by users themselves. Otherwise, it might cause water leakage or bad image due to unprofessional dismantling.
- Page 4 Dahua IR Bullet Network Camera Quick Start Guide Disclaimer This manual is for reference only. Please refer to the actual product for more details. Minor differences might be found in user interface, and there might be deviation between the actual value of some data and the value provided in the manual due to the reasons such as the real environment is not stable.
- Page 5 Dahua IR Bullet Network Camera Quick Start Guide Please refer to the disk for more details, check and download the corresponding user’s manual and tool. Before installation, please open the package and check all the components are included. ...
-
Page 6: Table Of Contents
Dahua IR Bullet Network Camera Quick Start Guide Table of Contents 1 Device Framework ..........................6 1.1 Device External Cable ........................6 1.2 Dimension ............................. 7 2 Device Installation ..........................8 2.1 Install SD Card ..........................8 2.2 Fix Device ............................. 9 2.3 Connect Device Cable ........................ -
Page 7: Device Framework
Dahua HD IR Bullet Network Camera Quick Start Guide 1 Device Framework 1.1 Device External Cable Note The following structure figure is for reference only. It is only used to know the functions of cable ports. There might be some minor differences between different devices, so please refer to the actual products you purchased. -
Page 8: Dimension
Dahua HD IR Bullet Network Camera Quick Start Guide Port name Connector name Function description Alarm input port, receive on-off signal from external ALARM_IN1 alarm source. Alarm output port, output alarm signal to alarm I/O Port ALARM_OUT1 device. ALARM_GND Ground terminal. Table 1-2 1.2 Dimension Note... -
Page 9: Device Installation
Dahua HD IR Bullet Network Camera Quick Start Guide 2 Device Installation 2.1 Install SD Card Note Please implement the step when the device is equipped with Micro SD card slot and it needs to use Micro SD card. ... -
Page 10: Fix Device
Dahua HD IR Bullet Network Camera Quick Start Guide 2.2 Fix Device Note The following figures are for reference only; please refer to the product for more details. Make sure the bracket installation surface can sustain at least 3X weight of the total ... - Page 11 Dahua HD IR Bullet Network Camera Quick Start Guide Connect alarm input and output terminal to external cable according to “Connect Alarm Input/output Port”, and use insulated tape to twine connection to make it waterproof. Connect network cable to corresponding network port of the device cable according to “Install Waterproof Connector (Optional)”.
