CHARACTERISTICS:
The HD67154-A1, HD67154-B2, HD67154-A3 and HD67154-A4 are converters from Ethernet to DeviceNet Master and vice-versa.
They have the following characteristics:
Up to 63 DeviceNet slaves devices;
Triple isolation between Ethernet - Power Supply, Ethernet - DeviceNet, Power Supply - DeviceNet.
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / +85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67154 software on your PC in order to perform the following:
Define the parameter of Ethernet line;
Define the parameter of DeviceNet line;
Define the DeviceNet slaves connected to the network;
Update the device.
