Altronix NetWaySP8C Series Installation Manual page 2

Altronix NetWaySP8C3W Series Hardened Switches are each equipped with two (2) 1Gb SFP ports and eight (8)
PoE+ (30W) ports or up to two (2) Hi-PoE (60W) ports, with 360W total power for deploying the latest high-powered
IP devices in remote locations. NetWaySP8C3W Series accommodate single/multi-mode fiber or composite cable
(fiber+copper) to simultaneously deliver power and data from NetWay Spectrum head-end media converters/injectors.
NetWaySP8C3W Series have an integrated rapid battery charger for extended battery run times. Embedded LINQ
Technology enables monitoring, control, and reporting from anywhere over the network.
Agency Listings:
• CE European Conformity.
Input
POE360 (NetWaySP8C3W2, NetWaySP8C3W5)
• 115VAC, 60Hz, 3.5A or 230VAC, 50/60Hz, 2A.
POE367 (NetWaySP8C7W2, NetWaySP8C7W5)
• 277VAC, 50/60Hz, 1.75A.
Output
• Eight (8) ports PoE+ (30W) or up to
two (2) Hi-PoE (60W) ports.
• IEEE 802.3at (30W) and IEEE 802.3af (15W)
compliant.
• 360W total power.
• Integral surge protection.
SFP Ports:
• Two (2) Gigabit SFP ports.
Ethernet Ports:
• Six (6) 10/100 Mbps and
two (2) 10/100/1000 Mbps ports.
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or better structured cable.
• Distance: up to 100m.
• Speed: 10/100/1000 Mbps, half/full duplex,
auto negotiation.
Indicators (LED)
• Individual PoE On LEDs for each port.
• Individual IP Link status, 10/100/1000
Base-T/active LEDs for each port.
• ALOS LED indicates fiber connection for SFP port.
• Heartbeat LED indicates proper operation of the unit.
*CAUTION: When using lead acid or gel type batteries, enclosure must be properly ventilated.
Battery operational temperature should be derated 10-15ºC lower than manufacture's rated high temperature.
Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily
usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 For use with Single-Mode Fiber for distances up to 10km.
P1AB2K For use with Single Strand Single-Mode Fiber for distances up to 2km.
P1GCE For use with CAT5e or better for distances up to 100m.
- 2 -
Recommended Altronix SFP Modules:
Overview:
Features:
VLAN:
• Multiple management VLAN assignment.
• 802.1Q Tagged VLAN.
• Up to 10 VLAN groups. ID Range 2-4095.
LINQ Technology:
• Remote network management allows for camera/
device reset and diagnostic monitoring.
• Provides local and/or remote access to critical
information via LAN/WAN.
• Email and Windows Dashboard Alert notifications
report real-time events.
• Event log tracks history.
Battery Backup:
• Charging four (4) 12V batteries in series.
• 2A or 4A selectable operation.
• Able to recharge 40AH or larger batteries
in under 8 hours
• AC Fail Supervision (form "C" contacts).
• BAT Supervision: indicates low or missing
batteries (form "C" contacts).
Mechanical:
• NEMA4/4X, IP66 Rated enclosures for outdoor use.
• Accommodates sealed lead acid or gel type
or LiFePO 4 (Lithium Iron Phosphate) 12VDC batteries.
• Dimensions (H x W x D approx.):
NetWaySP8C3W2, NetWaySP8C7W2:
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm)
NetWaySP8C3W5, NetWaySP8C7W5:
19.31" x 17.32" x 9.58"
(490.4mm x 439.9mm x 243.3mm)
NetWaySP8C Series Installation Guide
