Spectrum Industries 68161 Assembly Instructions

Assembly Instructions
Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts or
accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
Note if you are also installing a logo panel over the Corner module accent panels, you'll need to drill out
the (4) starter holes on the back of the accent panel prior to installation. See the instruction included with
your logo panel for more information. The drilling needs to be completed before panel installation.
Corner module parts
(1) Accent panel-corner
0184629 (36"H)
0201585 (29"H)
(1) 0184630
Bottom panel
(1) 0184855
Accent panel bracket-
upper right
(1) 0184680
Accent panel bracket-
upper left
Accent Panel Kit for Corner module
(Elite Console)
68161
Assembly tip: Do not tighten component fasteners completely
until all have been installed. Keeping them loose will help with
alignment between parts during assembly.
(7) 021491
#8 x 1/2" PHSM
(2) 0101382
#14 x 7/8" PHSM
(3) 0100167
8-32 x 1/2" PH thrd ctg
0600021 Page 1 of 2
