Owner's Manual
Freedom XRS Elite Lectern
55289
XRS Elite with surround, keyboard tray,
and rack cabinet installed on left
(shown retracted)
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 5 days of receipt. To report information regarding
missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
™
XRS Elite with overbridge, keyboard tray,
and rack cabinet installed on right
(shown extended)
0118857R10 Page 1 of 17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spectrum Industries Freedom XRS Elite Lectern
Summary of Contents for Spectrum Industries Freedom XRS Elite Lectern
- Page 1 Owner’s Manual ™ Freedom XRS Elite Lectern 55289 XRS Elite with surround, keyboard tray, XRS Elite with overbridge, keyboard tray, and rack cabinet installed on left and rack cabinet installed on right (shown retracted) (shown extended) Important Before using this product: •...
- Page 2 / or video equipment furniture. outlet(s) before installing or removing components Use caution when raising or Note: The Freedom XRS Elite Lectern is not designed for use with cord reels or surface-mount cord reel accessories. lowering lectern!
- Page 3 Assembly / Setup 1. Unloading lectern Utility knife Note: Upon receiving lectern, inspect packaging for damage. To report information regarding damages, please call 1-800-235-1262 within 5 days of receipt. 1. Cut and remove banding using a utility knife, scissor, or other cutting tool. 2.
-
Page 4: Normal Operation
2. Lectern lift mechanism initial setup, operation, and reset procedure Control buttons Preparation: • Read all instructions before operation. • Make sure lectern is plugged-in using the 15-foot, 15-amp power cord. • Locate the “Up” and “Down” control buttons. Control pad is located on the instructor- side under the worksurface front edge on opposite side from rack cabinet. - Page 5 3. Install 3-piece skirt Note: The skirt has been designed to be installed tool-free with the lectern Keyhole Lectern Base upright. Do not tip the lectern to install. Slot The skirt should be removed when the lectern will be moved over long distances or thresholds to prevent damage to the skirt panels.
-
Page 6: Quick-Release Door
Rack Cabinet - optional The removable rack cabinet (14RU front, 10RU rear) simplifies installation and provides the ability to integrate equipment remotely, and docked into the lectern at a later date. Figure 4A. Detaching Cabinet 1. To detach the rack cabinet from the lectern, unlock the cabinet lock pawl near the floor. - Page 7 Overbridge insert panel - optional 4mm hex Drill wrench 1. To remove the overbridge insert panel, remove the (2) 1/4-20 x 35mm JC bolts with a 4mm hex wrench and lift out the panel. Figure 5A. Measuring Drill bit 2. To make cutouts in the insert panel [optional]: device A.
- Page 8 Freedom XRS Elite Lectern overbridge insert panel blank (flat view) 2” Grommet 2” Grommet Max cutout area Figure 5B ™ Note: The Overbridge Control Console has been designed for many of the currently available controllers on the market, however, modified cutouts should be reviewed by Spectrum...
-
Page 9: Wiring Diagram
Wiring Diagram Actuator Actuator Up / Down buttons Control box Note: Power cord can be plugged into a power strip (not included) inside lectern. To wall outlet Figure 6A Note: A separate power strip is recommend- ed (not included) to plug the control box and other power plugs into. - Page 10 Note: Leave enough slack in the cords and wires from the rack cabinet to pull the rack cabinet out from the lectern. Cords and wires from Rack Cabinet Rack Cabinet Figure 6C Bottom view 2” Grommets for floor power access Rack cabinet Figure 6D 0118857R10 Page 10 of 17...
- Page 11 Caster operation 1. Lock the brake levers to lock movement of the casters. (Two instructor-side casters only). Figure 7. 2. To resume operation, lift up on brake levers. Brake lever Figure 7 Note: The skirt should be removed when the lectern will be moved over long distances or thresholds to prevent damage to the skirt panels.
- Page 12 Accessories (Available separately after initial configured purchased) Rack Cabinet - 55297 • One rack cabinet attaches to the left or right side of the XRS Elite Lectern (opposite keyboard tray and wiring panel) • Locking door can be flipped to be hinged left or right •...
- Page 13 Keyboard Tray - 55334 • Installed in left or right position (opposite rack cabinet) using pre-drilled holes • Tray can be installed and used as a keyboard tray or flipped and used as a storage drawer using pre-drilled mounting holes under the worksurface. •...
-
Page 14: Safety Information
Electric actuator information Warning! Only for EU markets • This appliance can be used by children aged from 8 years and above and persons with Failure to comply with these instructions may result in accidents involving serious person- reduced physical, sensory or mental capabilities or lack of experience and knowledge if al injury. - Page 15 Misc. on the DESKLINE® DL5/DL6 system Electrical connection of the DL5/DL6 system This system is a DESKLINE system developed for desks and for indoor use in offi ces. Do The DESKLINE® DL5/DL6 system is to be connected as shown in Figure 4. Each DL5/ not use it in industrial kitchens or in other enviroments that have to be cleaned with ag- DL6 is to be connected to the sockets on the control box by means of the motor cables, gressive detergents.
- Page 16 Freedom XRS Elite Troubleshooting Guide Symptom Problem Solution Loss of power Be sure control box is plugged into a live circuit. Make sure all electrical connections are securely plugged into the control box. Loose electrical connections See wiring diagram on p.9 for reference. 1.
-
Page 17: Warranty
• 10 Years • Cart Chassis • Lectern Chassis DESIGNED AND ASSEMBLED IN CHIPPEWA FALLS WISCONSIN.USA 925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM 0118857R10 Page 17 of 17 © 2017 Spectrum Industries Inc., All rights reserved.
