Spectrum Industries 67066 Assembly Instructions

Assembly Instructions:
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for choosing Spectrum products!
(1) 042948
Grommet
(15) 026064 (4) 041289
1/4-20 x 5/8" PHMS 1/4-20 x 1-3/4" PHMS
(1) 037749 (1) 036281
Unit-to-unit bracket Dual Unit-to-unit bracket
Before you begin, please make sure all parts and proper quantities are
included. Any parts damaged during shipment must be reported within
15 days of receipt. To report information regarding damages or if you 1 f
have any questions, please call 1-800-235-1262.
1.
Attach Legs and Sway Brace to Worksurface
A. Place the worksurface face-down onto a non-abrasive surface.
B. Orient and align the left and right legs as shown with the
worksurface and sway brace. Make sure the grommet hole
is on the back side of the desk. Figure 1.
C. Secure with (4) 1/4-20 x 1-3/4" PHM screws, but do not tighten
completely.
D. Install the (4) glides-these can be adjusted after the desk is
assembled.
(4) 025068
5/16-18 Glide
(1) 025069
Glide wrench
f
1/4-20 x 1-3/4"PHMS
(4 req'd)
Multi-Use Student Desks
27½"H
#67066 (48"W)
#67067 (60"W)
#67068 (72"W)
f
Sway Brace
Worksurface
29½"H
#67166 (48"W)
#67167 (60"W)
#67168 (72"W)
Tools Required:
Phillips screwdriver
Glide wrench (included)
Glides (4 req'd)
Leg
044170XR3 Page 1 of 2
Figure 1
