User Manual
Remote Control IK3 Transmitters
Technical description
IK3 Detailed description
Description
Stop function (400 - 900 MHz)
Stop Function (2.4 GHz)
Ingress Protection rating
Anti-condensation system
Frequency band - ERP
Range Line of sight (guaranteed)
Main mechanisms (maximum number)
Auxiliary mechanisms
Removable EEPROM
Battery model
Battery life
Response Time
Operating temperature range
Storage Temperature Range (24h)
Storage Temperature Range (long periods)
Relative Humidity
Weight (with battery)
Dimensions LxWxH mm
Harness
Fast Teleteaching
Buzzer
Vibration
Free Fall Detection
Tilt Switch
Available Options
Display (400-900MHz)
Display (2.4 Ghz)
LED Panel
Tether connector
Range limiter
Link Quality Indication (2.4GHz + Display)
RFID User Validation (2.4GHz)
Associated receivers (400-900MHz)
Associated receivers (2.4GHz)
Multikey
©
Danfoss | February 2025
The Multikey is a device connected to the Transmitter via RFID. It does engulf the following features:
Extractable Key (RFID) + START Pushbutton + Up to 5 position Selector switch.
There are different options for the Multikey, being the most common:
Value
Cat. 3-PLd
Cat3 - PLe
IP65/NEMA4
Goretex Film
433.050 to 434.040 MHz; ERP<1 mW
434.040 to 434.790 MHz; ERP<10mW
869.700 to 870.000 MHz; ERP<5 mW
902.000 to 928.000 MHz; ERP<1mW
2405MHz to 2475MHz; ERP 20dBm/100mW
100m
Joystick (3) or Paddle (6)
Pushbutton, toggle and rotary switches
External
BT27IK
10 hours
100ms
-20 °C to 70 °C (-4 °F to 158 °F)
-25ºC to 75ºC (-13ºF to 167ºF)
-25ºC to 55ºC (-13ºF to 131ºF)
max. 95% without condensation
1780 grams
245,04x216,56x181,16
Belt/shoulder strap
Yes
Yes
N/A
Yes
Yes
3.5-inch color TFT
4.3-inch color TFT and RCD430
Yes ( up to 12 LEDs)
Yes (M12 Connector)
Yes
Yes
Yes
R06, R13, R70, R70 PLUS, MP08, MPCAN, MP20
R13F, MP08, MPCAN, MP20
BC290857689420en-000301 | 9
