User Manual
Remote Control IK3 Transmitters
Technical description
IK Transmitters Start up (400-900Mhz)
crane xx1
LED pulse
display op� on
crane xx1
LED pulse
display op� on
IK Transmitters Start up (2.4 GHz)
©
Danfoss | February 2025
Use the information below to properly turn the transmitter ON (OPERATION mode).
1. Place a charged battery in the transmitter. The charge must be done following the instructions of the
Battery Chargers' Manual.
2. Turn the contact key.
3. Push and pull out the STOP button.
LED will flash green pulse. If the transmitter has LCD, it displays the identification of the machine and
battery level (only if it has been pre-programmed).
LED pulse
crane xx1
LED pulse
Display option
4. Press the start button. The green LED will now light to indicate the transmitter is transmitting. Once
the Tx is connected, press any maneuver button and its corresponding relay will be activated. Check
to make sure all other maneuvers work in a coherent way with the expected movements.
LED pulse
In order to turn the transmitter ON (OPERATION mode), please follow these steps:
BC290857689420en-000301 | 7
