iRay Technology Co., Ltd
Mars1717V Wireless Digital Flat Panel
Mars1717V Wireless Digital Flat Panel
文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。
This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,
except as may be specifically authorized by prior written agreement or permission of iRay.
Detector User's Manual
Detector User's Manual
Doc ID
037-201-02
Version
Revision Date
2019.05.27
Page
A5
1 / 144

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mars1717V and is the answer not in the manual?

Questions and answers

Related Manuals for iRay Technology Mars1717V

Summary of Contents for iRay Technology Mars1717V

  • Page 1 Doc ID 037-201-02 iRay Technology Co., Ltd Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 1 / 144 Mars1717V Wireless Digital Flat Panel Detector User’s Manual 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 2: To Customers

    To Customers Congratulations on your purchase of the Mars1717V Wireless Digital Flat Panel (hereinafter referred to as Mars1717V) which is manufactured by iRay Technology Co., Ltd. (hereinafter referred to as iRay). At iRay, we strive to not only make the world-class products that deliver the best value possible to our customers but also offer the highest quality of service and customer care.

  • Page 3: Caring For Your Environment

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 3/144 Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Page 4 All rights reserved  No part of this publication may be reproduced in any form or by any means without the written permission of iRay. The information contained herein is designed only for use with iRay Mars1717V. Trademarks  The iRay name and iRay logo are registered trademarks of iRay Technology Co., Ltd.

  • Page 5: Symbols And Conventions

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 5/144 Symbols and Conventions The following symbols and conventions are used throughout the user guide. This symbol is used to identify conditions under which improper use of the product may cause death or serious personal injury.

  • Page 6: Labels And Markings On The Equipment

    6/144 Labels and markings on the equipment The contents of the labels and markings on iRay Mars1717V product are indicated below: Caution: please refer to the instructions in the user manual. This symbol is used to indicate that the equipment has passed CE testing and it is followed by the CE number.
  • Page 7 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 7/144 This symbol is used to indicate the name and address of the manufacturer. This symbol is used to indicate the name and address of iRay authorized representative in the European region.
  • Page 8 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 8/144 This symbol is used to indicate the storage temperature limits. non-ionizing radiation Federal Communications Commission certificate Package symbol, fragile. Package symbol, keep away from sunlight Package symbol, keep dry Package symbol, this symbol is used to indicate the humidity limits.

  • Page 9: Table Of Contents

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 9/144 Contents To Customers Symbols and Conventions Labels and markings on the equipment Contents Safety Information Safety precautions Notes for Using...
  • Page 10 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 10/144 Detector Installation Battery Charging Installation Software Installation Panel Infrastructure Operation Main Operation 4.1.1 Software Mode 4.1.2 Inner Mode 4.1.3 FreeSync Mode...
  • Page 11 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 11/144 4.13.4 SDK Page 4.13.5 Detector Page 4.13.6 Images 4.14 Calibrate Page 4.15 Local File Page 4.15.1 Information prompts 4.15.2 Progress Bar 4.15.3 Infrared Registration...
  • Page 12 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 12/144 Dark Image Acquisition after Exposure in Inner Mode No Image Acquire After Exposure Image Inspection Artifact on bright image 6.9.1 Horizontal Line on Bright Image 6.9.2...

  • Page 13: Safety Information

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 13/144 1 Safety Information 1.1 Safety precautions Follow these safeguards and properly use the equipment to prevent injury and damage to any equipment/data.
  • Page 14  Never disassemble or modify the equipment. No modification of this equipment is allowed. Parts of the Mars1717V that are not serviced or maintained while in use with the patient Doing so may result in fire or electric shock. Also, since the equipment incorporates parts that may cause electric shock as well as other hazardous parts, touching them may cause death or serious injury.
  • Page 15 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 15/144 The equipment may be damaged. If so, the equipment should be used in bucky.  Have the patient take a fixed posture and do not let the patient touch parts unnecessarily.
  • Page 16 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 16/144 Installation and environment of use  Do not install the equipment in any of the locations listed below. Doing so may result in failure, malfunction, equipment falling, fire or injury.
  • Page 17 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 17/144 Power supply  Always connect the three-core power cord plug to a grounded AC power outlet.  To make it easy to disconnect the plug at any time, avoid putting any obstacles near the outlet.
  • Page 18 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 18/144  Do not place excessive weight on the equipment. Otherwise, the internal image sensor may be damaged and image may be incorrect.

  • Page 19: Notes For Using

    Be sure to check the equipment daily and confirm that it works properly.  Be sure there be a battery installing on the Mars1717V to avoid the power off suddenly.  Sudden heating of the room in cold areas will cause condensation to form on the equipment. In this case, wait until the condensation evaporates before performing an exposure.

  • Page 20: General Description

    Mars1717V can be used as a real portable panel. 2.1 Scope This manual contains information about the iRay Mars1717V. All operators must read and understand this manual before using equipment. All information in this manual, including the illustrations, is based on equipment prototype.

  • Page 21: Model

    2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 21/144 Share Mars1717V for different Radiography modality like an IP plate Mars1717V 2.2 Model Mars □ □ □ PSI- GOS scintillator screen, VSI- CsI scintillator screen Product Application：cassette size detector Product dimension：1717，17inch×...

  • Page 22: Intended Use

    To keep the data transmission function, the Mars1717V shall be not influenced to the data and signal transmission 2.5 Standard Product Components Mars1717V comes with power supply both 24V DC and battery package. Once powered on, it would build a connection with PC through Ethernet cable or Wireless connection. Item Description 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。...
  • Page 23 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 23/144 1 pcs Mars1717V Detector Main Unit Medical Adapter for 1 pcs  Detector and DC 24V  Battery Charger 2 pcs...
  • Page 24 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 24/144 1 pcs Gigabit Ethernet Cable AC Power Cable 1 pcs 1 pcs DC Power cable 3.5 m Battery Charger 1 pcs 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。...

  • Page 25: Optional Product Component

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 25/144 1 pcs Gain correction data CD-Rom Defect correction map Manual 2.6 Optional Product Component Item Description Wireless AP Device 1 pcs...

  • Page 26: Components Description

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 26/144 2.7 Components Description 2.7.1.1 Detector External Signals Input Control Panel Control Panel Item Name Description DC Input Interface 24V DC input...
  • Page 27 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 27/144 Detector Indicator Detector indicator of control panel Power Button Power button of control panel Infrared Window Infrared device window Antenna...
  • Page 28 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 28/144 The location pin Indicator Installation direction indicator 2.7.1.3 Battery Charger Item Name Description Battery Interface 8 Pin Battery connector Capacity Indicator...
  • Page 29 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 29/144 Firmware versions Lighting Status Value range (BCD) Major 00-11 Minor 0000-1111 Power indicator definition: Power Indicator Lighting Status Operating Status...

  • Page 30: Product Specification

    2.7.1.4 Power Supply Mars1717V supports both DC Power and Battery package input. 2.7.1.5 Infrared Device Mars1717V does not include Infrared Device. Users can select by themselves, however some basic requirements should be followed. 2.8 Product Specification 2.8.1 Detector 2.8.1.1 Basic...
  • Page 31 Dimension (L × W × H) 460 x 460 x 15.1 mm Weight (with one battery) Mars1717V-PSI: 4.45 kg without battery, 4.67 kg with battery Mars1717V-VSI: 4.65 kg without battery, 4.87 kg with battery Image Transfer Wired : 100M Ethernet(100BASE-T) Wireless : IEEE802.11a/b/g/n...

  • Page 32: Battery

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 32/144 0.15 0.39 0.05 0.24 0.01 0.16 2.8.2 Battery Item Specifications Model Battery-KV 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 33: Battery Charger

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 33/144 Rated Capacity Min. 3950mAh, Typ. 4180mAh @ Discharge 0.2C Nominal Voltage 10.8V Charge Voltage 12.6± 0.05V Discharged End Voltage 8.25V...

  • Page 34: Power Supply

    Compliant with IrDA V1.0 and V1.1 Compliant with USB V2.0 and V1.1 Data Rate Max. 4Mbps 2.8.6 AP Router (Optional) Mars1717V do not include AP Router. Users can select AP Router as they wish, however specification below is a requirements. Item Specifications Wireless Standard IEEE 802.11 a/b/g/n...

  • Page 35: Recommended Applicance Condition

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 35/144 13: (Ch. 1-13) – Europe 14: (Ch. 1-14) – Japan 5G: 5.15 ~ 5.85 GHz 12: United States 19: Europe 8: Japan 802.11b : Max.

  • Page 36: Mechanical Outlines

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 36/144 2.8.9 Mechanical Outlines 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 37 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 37/144 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 38: Use Environment

    45%~70% RH (1kp=1.0197E-5Pa) The Mars1717V serial detectors shall operate at an altitude specified not more than 3000m. 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 39: Installation

    3.1.1.1 Attach Battery Pack Mars1717V can be powered on by both battery package and DC power. Once battery package is inserted or DC power is on, Detectors would be activated immediately. If none of battery and DC power is on, Mars1717V would power off.
  • Page 40 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 40/144 3.1.1.2 Attach DC Power Please see below for DC power installation. Connect one end of DC Power Cable to the Medical...
  • Page 41 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 41/144 If detector is powered off, users can press the button for 4 seconds to power on the detector when battery is inserted and battery capacitor is not less than 10%, or direct current power is connected.
  • Page 42 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 42/144 OFF after Orange ≤10% Power OFF ON with 1 sec. Link indicator is as table: Link Indicator Lighting Status Description ...

  • Page 43: Battery Charging Installation

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 43/144 1. Network connection error; 2. Network connection is wired connection; Wireless connection ok，connection mode is Green ON Wireless connection ok，connection mode is...

  • Page 44: Software Installation

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 44/144 Press the battery to the bottom of battery compartment. 3.3 Software Installation In the case of IDetector doesn’t work, please install following VC redistribute package、NET Framework.
  • Page 45 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 45/144 3) Wireless AP Mode To build connection between workstation and Panel, User should follow steps below. 3.4.1.1 Wired Mode To complete Wired connection configuration, users have to finish actions listed below.
  • Page 46 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 46/144 Open Local network configuration open IPV4 setting IP setting IP address: 192.168.8.188 Network mask setting Subnet mask: 255.255.255.0 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 47 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 47/144 Open SDK and choose product start connection 3.4.1.2 Wireless Client mode To complete Wireless Client mode configuration, users have to finish actions listed below.
  • Page 48 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 48/144 Open Local network configuration open IPV4 setting Select “Obtain an IP address automatically” IP setting Network mask setting 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 49 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 49/144 Open browser and type 192.168.1.1 Log into external wireless AP Wireless setup Configure 2.4GHz wireless network SSID: NETGEAR_BIG_24 Security: WPA2-PSK...
  • Page 50 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 50/144 Configure 5GHz wireless network SSID: NETGEAR_BIG_50 Security: WPA2-PSK Password: 12345678 Channel: [Please check the current Wi-Fi environment, and choose a...
  • Page 51 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 51/144 Recover Local Network IPv4 setting of PC wired Ethernet interface IP setting IP address: 192.168.8.188 Network mask setting Subnet mask: 255.255.255.0 Configuration of detector Either Wired Cable or Infrared device can be used to configure detector in wireless client mode.
  • Page 52 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 52/144 Click “Detector” Click “Read Config” Choose Client mode Click “Add” Type SSID and Password Click “Apply” Choose SSID and select(There will be √...
  • Page 53 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 53/144 Turn on wireless router. Make sure there are wired connection between router and work station and IP 192.168.8.188. Click “Read wifi Status” to check...
  • Page 54 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 54/144 Start IrDARegister.exe Click “ ” to open wifi setting 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 55 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 55/144 Change SSID and password, do not select AP mode Click “Apply” Click” ” 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 56 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 56/144 Click “Start” Point Infrared device to detector’s infrared interface 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 57 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 57/144 Do not click “Exit” until success Disconnect Infrared device from PC 3.4.1.3 Wireless AP mode To complete wired connection configuration, user has to finish actions listed below.
  • Page 58 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 58/144 Click “Detector” Select “wifi” Choose AP mode 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 59 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 59/144 Click “Read Config” to get default setting. Change SSID and password setting , make sure SSID is different from other already exist;...
  • Page 60 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 60/144 Click “write config” Do not remove wired cable until FPD status from Busy become Ready Since we have chosen default SSID and password, it would connect to wireless AP immediately after powered on next time.
  • Page 61 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 61/144 Start IrDARegister.exe 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 62 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 62/144 Click “ ” to open wifi setting 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 63 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 63/144 Select “AP mode” 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 64 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 64/144 Change SSID and password and other parameter Click “Apply” Click “ ” 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 65 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 65/144 Click “Start” 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 66 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 66/144 Do not click “Exit” until success Configuration of external wireless card Open Wireless signal List 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...
  • Page 67 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 67/144 Select SSID which belongs to Detectors, input password and log into system Open wireless card configuration open IPV4 setting IP setting IP address: 192.168.8.188...
  • Page 68 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 68/144 Network mask setting Subnet mask: 255.255.255.0 Open SDK and choose product start connection 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 69: Operation

    Detector User’s Manual Page 69/144 4 Operation Mars1717V provides SDK for users to integrate detector into their DR system. Additionally, it also provides an application for demonstration, i.e. IDetector. User can use IDetector to control detector without DR system. 4.1 Main Operation To Acquire X-ray image is the main operation of Mars1717V.
  • Page 70 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 70/144 4.1.1.2 Work flow Click “Prep” Panel preparation, wait until the warning message change from “Exposure Prohibit” to “Exposure Enable” Shoot X-ray at any time. However the longer time you wait. The worse image would be.
  • Page 71 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 71/144 Panel receives “clear” from workstation, start detector internal clear cycle. At the same time, detector would tell workstation “Exposure Prohibited”.

  • Page 72: Inner Mode

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 72/144 4.1.2 Inner Mode 4.1.2.1 Block Diagram Workstation（Inner） Tube Workstation is a host PC device installed with IDetector and SDK. Chapter 3 has described how to establish connection between panels and workstation.
  • Page 73 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 73/144 4.1.2.3 Timing Setting To set a clear scenario for program, see diagram below for details Process Clear Exposure Acquisition Detector...

  • Page 74: Freesync Mode

    037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 74/144 If Hardware Post offset and Hardware calibration is selected, image got from detector would be preview image (2x2 binning). After step12, Detector would do another dark image acquisition. With both light image and dark image, detector completes all the correction process.
  • Page 75 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 75/144 Workstation is a host PC device installed with IDetector and SDK. Chapter 3 has described how to establish connection between panel and Workstation. In Freesync mode, User doesn’t interact with Workstation. After shooting, images would be shown on screen immediately.

  • Page 76: Connection Build

    037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 76/144 3. Panel starts uploading Pre-dark image and Light image to Workstation for preview. If hardware offset is selected, panel would do offset first, and then upload preview image (2X2 binning).
  • Page 77 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 77/144 Acquire module related setting, such as loading correction and calibration template, acquiring images SDK module related setting, such as IP...

  • Page 78: Correction And Calibration Template Generation

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 78/144 Local File module related setting, such as import Raw or Dcm image. Note: 1. If panel works in FreeSync mode, it is not allowed to change any parameters and write into ROM or RAM.

  • Page 79: Gain Calibration Template Generation

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 79/144 Choose Calibrate module, click “Update HWPreOffset”, wait until image acquisition ends 4.4.1 Gain Calibration Template Generation Dose study 4.4.1.1 Through the study of dose, can be familiar with high voltage and dose relationship, under different conditions to the follow-up correction is more convenient.
  • Page 80 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 80/144 Pay attention to this file [study] under the module of six measuring values Enter Acquire module，choose HWPreOffset Set voltage 70KV,adjust MAS and...
  • Page 81 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 81/144 Change the value mAs1_2 in iDetectorConfig.ini into MAS value above Set voltage 40KV,adjust MAS and exposure, until the brightest area...
  • Page 82 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 82/144 Set voltage 120KV,adjust MAS and exposure, until the brightest area gray value in the range of 11000-12000 Change the value mAs1_2 in iDetectorConfig.ini into MAS...
  • Page 83 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 83/144 Choose “Acquire” module, do not choose any calibration Choose Calibrate module, choose PreOffset, click “Start Generate Templates” Make sure correction and calibration template meet the requirements.
  • Page 84 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 84/144 Click “Start the journey of Calibration”, wait 5s offset template start create, if need skip, click SKIP in the top right corner in 5s.
  • Page 85 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 85/144 Make sure correction and calibration template meet the requirements. Click “Start the journey of Calibration”, wait 5s offset template start create, if need skip, click SKIP in the top right corner in 5s.
  • Page 86 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 86/144 Set voltage based on the radiation dosage in right, then exposure Click Next to get into next condition image acquiring, and...
  • Page 87 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 87/144 Start Gain correction Process According to the left side of the recommended dosage set voltage and MAS, then exposure image do not conform to the requir ements, There will be prompt in the region of the image above.
  • Page 88 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 88/144 After conform to the requirements of the image, do not change voltage and MAS, click NEXT and exposure, acquire next image...
  • Page 89 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 89/144 Defect Correction Template Generation 4.4.1.3 Before Defect template generating, make sure SID1.2m, no copper is required, 1. If then Gain correction processes...
  • Page 90 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 90/144 Image meets the requirements, the lower right corner to hook to be green Click "next" to enter the next, click "prep"...

  • Page 91: Image Acquisition Continually (Nonsupport)

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 91/144 After waiting for the templates to create successful, click Next to complete all the correction Note: 1. please use software post offset mode.

  • Page 92: Single Image

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 92/144 4.6.1 Single image Click “Save” Click “Save Directly” 4.7 Image Check and upload “OPEN” provides two feature for image check and uploading. Local Image Check, Panel Image Upload.

  • Page 93: Local Image Check

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 93/144 4.7.1 Local Image Check Choose “Local File” Click “Local File” to open Dicom、 Raw、tif file Click OPEN 4.7.2 Panel Image Upload 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。...
  • Page 94 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 94/144 Make sure firewall is closed Panel Image is uploaded as following. Choose Detector, choose Image Click Query Images, open image list in...

  • Page 95: Defect Template Check And Modification

    Click the "Stop Uploading" Stop image upload process Upload images stored in the "work_dir \ Mars1717V \ upload \ tablet serial number" folder 4.8 Defect Template Check and Modification IDetector provides function to check defect template. If defect template has updates, user could add and delete defect pixel or defect lines by modifying defect template opened.

  • Page 96: Defect Template Modification

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 96/144 choose the file type DFT format, select the corresponding defect template, click on the "Open" button 4.8.2 Defect Template Modification Select "Local File"...

  • Page 97: Correction And Calibration Management

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 97/144 If there is a new defect line, input defect line starting coordinates and end coordinates, click "Add". If there is a...
  • Page 98 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 98/144 Choose Calibrate module, click “Download File” Click on the path of the pop-up window button, select the calibration template generated path...
  • Page 99 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 99/144 A single set of calibration template to use: 1, the calibration template (Gain, Defect and Lag templates), when downloaded to...
  • Page 100 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 100/144 Ensure that the firewall to shut down Choose Calibrate module，click “Upload File” Click on the path of the pop-up window button 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。...

  • Page 101: Correction And Calibration Management

    (Gain, Defect and Lag), as well as the template repository paths: (template in the following path is valid work_dir \ Mars1717V \ Correct \ Default), named after select the Default template FileIndex enter 1, click the OK button to...
  • Page 102 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 102/144 Software Correction and Calibration 4.9.2.1 Make sure work_dir\Mars1717V\Correct\Default Path is related to calibration template file Choose Acquire module Set Offset Mode “SWPreOffset”, Gain mode “SWGain”, Defect mode...

  • Page 103: Sleep And Wake Up

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 103/144 Hardware Correction and Calibration Management 4.9.2.2 To ensure that the relevant calibration file has been downloaded to the tablet, and...

  • Page 104: Sleep

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 104/144 4.10.1 Sleep Waiting for a fixed period of time without operation or click “Sleep”, panel will go to sleep immediately, click “Wake Up”, panel will go to wake up immediately.
  • Page 105 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 105/144 Choose “Detector”, change trigger mode into Software trigger mode, click Upgrade Firmware Click Browse to open the upgrade file storage path...

  • Page 106: Short Cut

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 106/144 Depending on the Type of upgrade file, select the corresponding Device Type, click on the "Start Update", waiting for the upgrade is complete...

  • Page 107: Software

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 107/144 4.13 Software 4.13.1 Main GUI Double-click iDetector. Exe can be seen after the software main interface as shown in the figure below, function description menu to see the table below.

  • Page 108: Acquire Page

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 108/144 Calibrate Calibration template files are generated and management Local File Local image open and image processing List 4.13.1 4.13.2 Home Page This page below the main function for the connection detector，see figure 4.13.1.
  • Page 109 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 109/144 Figure 4.13.2 Note: different product page display content may be slightly different This page below is a status bar, SN, can show the detector, detector of the current state and tasks, carry out orders to the system of feedback information, etc.
  • Page 110 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 110/144 Indicates to the acquisition of image hard PostOffset correction (currently HWPostOffset only support Mars series detector) SWGain Selected soft Gain the acquisition of image correction...

  • Page 111: Sdk Page

    037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 111/144 Drag the left mouse button, drag the image displayed. Lateral-drag the right mouse button to adjust the window width, and vertical-drag the right mouse button to adjust the window level.

  • Page 112: Detector Page

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 112/144 4.13.5 Detector Page Connect different detector display on the page when the Tab is different, the Parameters of Sensor is connected to each type of detector display Tab, and Wifi, such as Image display Tab in the connection Mars series products.
  • Page 113 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 113/144 Figure 4.13.4 Parameter configuration items（Not listed all the parameters, the actual software display shall prevail）： Description Modifiable ParmName Main Version...
  • Page 114 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 114/144 Keys function description： Function Button Description Reset Detector Restart the detector Read Read the probe parameters Write Write the probe parameters...
  • Page 115 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 115/144 Wifi 4.13.5.3 Parameters Description Client Click pop-up editor window to increase among the list after a default SSID To delete the specified SSID in the list...
  • Page 116 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 116/144 Client mode settings 4.13.5.4 Figure 4.13.6 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 117: Images

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 117/144 settings AP mode 4.13.5.5 Figure 4.13.7 4.13.6 Images 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 118: Calibrate Page

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 118/144 Figure 4.13.8 Figure of detector can be uploaded to the PC. 4.14 Calibrate Page This page is mainly Mars and series of Mercu template management, as well as the flow into the generated template.

  • Page 119: Local File Page

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 119/144 Figure 4.14.9 The table below to generate a template page button options, such as functional description. Function Button Description Create templates work mode selection（Mercu plate must be selected, other Mode tablet without this parameter）...
  • Page 120 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 120/144 figure 4.15.10, choose to open file click open, select the raw or DFT format file after clicking will pop up the dialog box shown in figure 4.15.11, input the correct opening size, click OK, you can open the image.
  • Page 121 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 121/144 Figure 4.15.12 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 122: Information Prompts

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 122/144 4.15.1 Information prompts State 4.15.1.1 The status bar the current state feedback detector. Value description Unknow IDetector lose connection with detectors, IDetector heartbeat package not received...

  • Page 123: Infrared Registration

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 123/144 If the progress bar shows green X-ray exposure, the image quality can be accepted, otherwise the image quality is deteriorating.

  • Page 124: List Of The Hazardous Situations Resulting From A Failure Of The It-Network

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 124/144 Read Only: infrared registration tools is allowed to read from panel Read & Write: infrared registration tools is allowed to read from panel and write to panel Read &confirm by User: infrared registration...
  • Page 125 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 125/144 The inconsistent of interface or format leads to data distortion; The data output failed; 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 126: Regulatory Information

    Not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide Not suitable for use in the oxygen rich environment Note: The product safety standards that apply to Mars1717V which includes the main units: detector and charger-kv . ...

  • Page 127: Guidance And Manufacture's Declaration For Emc

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 127/144 for radiography and radioscopy Secondary cells and batteries containing alkaline or other non- acid electrolytes – Safety requirements for portable sealed...
  • Page 128 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 128/144 Professional healthcare facility environment ±8 kV contact ElectrostaticDischarg IEC 61000-4-2 ±2kV, ±4kV, ±8kV, ±15kV air 3V/m Radiated RF EM field IEC 61000-4-3 80MHz-2.7GHz...
  • Page 129 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 129/144 Professional healthcare facility environment ±2 kV Electrical fast IEC 61000-4-4 transients/burst 100kHz repetition frequency Surges IEC 61000-4-5 ±0.5 kV, ±1 kV...
  • Page 130 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 130/144 transients/burst 100kHz repetition frequency 3V, 0.15MHz-80MHz Conducted disturbances induced IEC 61000-4-6 6V in ISM bands between 0.15MHz and 80MHz by RF fields 80%AM at 1kHz 5.2.4...

  • Page 131: Radio Frequency Compliance Information

    037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 131/144 This user’s manual specifies the use of transmitter and cable accessories. If using the equipment other than those sold by our company as replacement parts of the internal components of flat panel detector, the immunity from interference may be influenced.

  • Page 132: Battery Safety Standards

    037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 132/144 equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measure.

  • Page 133: Ethernet Cable Inspection

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 133/144 the definition of Gigabit Ethernet cable and test the conductive between each pin of connector. 6.1.1.2 Definition of Gigabit Ethernet Cable...

  • Page 134: Adapter Inspection

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 134/144 6.2 Adapter Inspection 6.2.1 Adapter Connector Definition Description DC +24V/5.0A 文件包含奕瑞公司机密资料，非经奕瑞正式书面授权不得复制、打印、披露及传播该文件的任何内容。 This document contains confidential and proprietary information of iRay, any reproduction, disclosure, or use in whole or in part is strictly prohibited,...

  • Page 135: Inspection Method

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 135/144 6.2.2 Inspection Method Measure the Adapter is intact Is it 5A？ voltage between pin 2 and pin 3 Measure the...

  • Page 136: Inspect Method

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 136/144 Battery Discharge Negative Terminal 6.3.2 Inspect Method Measure the voltage between the Pin1,2 and Pin Less than 9v Voltage About 10.V...

  • Page 137: Inspection Method

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 137/144 Voltage Description Battery Charge Positive Terminal Battery Charge Negative Terminal 6.4.2 Inspection Method Replace Adapeter 1. Does power Measure the...

  • Page 138: Connection Inspection

    037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Detector User’s Manual Page 138/144 is the label of power indicator. Skip the step “Press reset button” if no reset button, because the previous version doesn’t include reset button.

  • Page 139: Disconnect In Ap Mode

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 139/144 6.6.3 Disconnect in AP mode Replace PC or Check WLAN of Does it work Connection failed modify to correct Flash...
  • Page 140 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 140/144 Gain *.gn The gain file can be selected or deselected Defect *.dft The gain file can be selected or deselected *.lag...
  • Page 141 Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 141/144 Save the previous Decrease the value Acquire an bright Acquire a dark Horizontal line value of “Acquire of “Acquire image with post...

  • Page 142: Service Information

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 142/144 6.9.4 Defective point Check the defect Defective Does the Does the map and add the point on the Defect calibration...

  • Page 143: Replacement Parts Support

    037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 143/144 equipment, make adjustments, or replace consumables such as fuses, detector cable, etc. There may be cases where overhaul is recommended depending on conditions. Contact iRay service office or local iRay dealer for regular inspection or maintenance.

  • Page 144: Appendix A Information Of Manufactures

    Doc ID 037-201-02 iRay Technology Co.，Ltd. Version Revision Date 2019.05.27 Mars1717V Wireless Digital Flat Panel Page Detector User’s Manual 144/144 Appendix A Information of Manufactures COMPANY: iRay Technology Co.，Ltd. ADDRESS: Rm202, Building 9, No. 590, Ruiqing Rd, Pudong, New Area Shanghai.

Table of Contents
