Chapter 2: Jumpers and Connectors
Pin Definition
A15 CLK_PCIE_X8_OCP_P
A16 GND
A17 NC
A18 NC
A19 GND
A20 NC
A21 NC
A22 GND
A23 NC
A24 NC
A25 GND
A26 NC
A27 NC
A28 GND
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
B15 NC
B16 GND
B17 NC
B18 NC
B19 GND
B20 NC
B21 NC
B22 GND
B23 NC
B24 NC
B25 GND
B26 NC
B27 NC
B28 GND
Pin Definition
A29 GND
A30 NC
A31 NC
A32 NC
A33 GND
A34 NC
A35 GND
A36 NC
A37 NC
A38 GND
A39 NC
A40 NC
A41 GND
A42 NC
17
Pin Definition
B29 GND
B30 NC
B31 NC
B32 NC
B33 GND
B34 NC
B35 GND
B36 NC
B37 NC
B38 GND
B39 NC
B40 NC
B41 GND
B42 NC
