Chapter 2: Jumpers and Connectors
Internal Jumper
Clear CMOS/Power Mode
Connector location: JP1
2
8
1
7
RTC Pin
Settings
1-3
Normal (default)
3-5
Clean CMOS
Pin
Definition
1
NC
3
RTCRST_N
5
GND
7
+P3V_RTC
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
AT/ATX Pin
Definition
2-4
ATX (default)
4-6
AT
Pin
Definition
2
+P3V3_EC
4
AT_ATX_SEL
6
GND
8
FP_PWR_BTN_N
11
NSA 3200 User Manual
