Owner's Manual - Basic Setup Dimensions & Assembly Notes Place the set on level ground, not less than 6'-7" [2 m] from any structure or obstruction such as a fence, garage, house, overhanging branches, laundry lines, or electrical wires. • While assembling unit, take time before and after each phase to make sure fort is level.
PRE-ASSEMBLY STEP 1 - SORTING PARTS It is critical for ease of assembly that you take the time to sort and organize the wood and hardware. WOOD PARTS: • Organize wood parts by the three-digit, alpha-numeric number stamped on each board (ex. P01). •...
Page 15
PRE-ASSEMBLY STEP 2 - TOOLS REQUIRED Drill Attachments: Phillips Head Open End Wrenches 1/2" & 9/16" 1/8", 3/16", 3/8" & 7/16" Drill Bits 3/8" Drive Ratchet, 1/2" & 9/16" STD Sockets 1/2" & 9/16" Deep Sockets Phillips Screw Driver Cordless Drill or Electric Drill Rubber Mallet - Optional Claw Hammer...
Page 16
PRE-ASSEMBLY STEP 3 - CHOOSE YOUR ASSEMBLY METHOD There are several types of assembly instructions available to you. 1. Printed Assembly Manual included with your set 2. BILT APP - 3D interactive instructions 3. Combination of the Printed Manual and BILT APP (Note: Step numbers can differ between the two methods)
Page 26
STEP 2 - SWING BEAM ASSEMBLY PART DESCRIPTION NUMBER H101166 WASHER LOCK INT 10x18 BLK H101167 WASHER FLAT 11x25 H101168 T-NUT 3/8 BLK H101170 BOLT HEX 3/8x5-3/4 A4M02171 SWING HANGER (x6) TIP: INSTALL T-NUTS IN WOOD FIRST 1168 (x12) T-NUT - 3/8" 1167 (x12) WASHER - 11x25...
Page 27
STEP 3 - SWING BEAM ASSEMBLY QTY PART NUMBER DESCRIPTION H100202 SCREW PWH 8x5/8 BLK A100164 BYD ID TAG (LARGE) AGES 3-10 (x1) (x1) (x4) BYD ID TAG (LARGE) AGES 3-10 SCREW - 5/8"...
STEP 22 - FORT ASSEMBLY QTY PART NUMBER DESCRIPTION H100387 SCREW PFH 8x1-1/4 BLK 1 1/8 in 7/8 in 7/8 in 1 1/8 in [29 mm] [23 mm] [23 mm] [29 mm] SUPPORT BLOCK - W4L19099 SUPPORT BLOCK - W4L19100 1"x2 3/8"x6 1/4"...
Page 53
STEP 23 - FORT ASSEMBLY QTY PART NUMBER DESCRIPTION H100195 BOLT WH 5/16x2-3/4 BLK H100198 WASHER LOCK EXT 8x19 BLK H100379 T-NUT 5/16 BLK SUPPORT BLOCK - W4L19084 TABLE SUPPORT - W4L19083 1"x2 3/8"x3 3/8" (24x60x86) (x1) 1"x3 3/8"x22 3/8" (24x86x567) (x1) TIP: INSTALL T-NUTS IN WOOD FIRST...
Page 80
STEP 50 - FORT ASSEMBLY PART DESCRIPTION NUMBER H100397 BOLT WH 1/4x1-1/4 BLK H100398 T-NUT 1/4 BLK H100403 LAG SCREW WH 1/4x1-1/2 BLK H100405 WASHER LOCK EXT 6x15 BLK A6P00654 HAND GRIP H101026 BOLT WH 1/4x1-3/4 BLK (x4) GREY PLASTIC TIP: INSTALL T-NUTS IN WOOD FIRST (x4)
Page 81
STEP 51 - FORT ASSEMBLY QTY PART NUMBER DESCRIPTION H100202 SCREW PWH 8x5/8 BLK 21 1/8 in [538 mm] A6P00324 CHALK BOARD (x1) LARGE TIP: CENTER CHALK BOARD ON WALL AS SHOWN. 21 1/8 in 2 in [538 mm] [51 mm] (x8) SCREW - 5/8"...
STEP 1 - FINAL ASSEMBLY QTY PART NUMBER DESCRIPTION H100198 WASHER LOCK EXT 8x19 BLK H100378 BOLT WH 5/16x1 3/4 BLK (x2) BOLT - 1 3/4" (x2) WASHER - 8x19 ROCK WALL ASSEMBLY...
Page 83
STEP 2 - FINAL ASSEMBLY A6P00537 CLIMBING ROPE (x1) TIE KNOT 17 1/2 in [444 mm] 3 PLACES TIE KNOTS APPROXIMATELY AS SHOWN (x1) CLIMBING ROPE TIE KNOT...
Page 84
STEP 3 - FINAL ASSEMBLY QTY PART NUMBER DESCRIPTION H100379 T-NUT 5/16 BLK H100468 BOLT WH 5/16x1 BLK A6P00554 8' BLOW MOLDED SLIDE - GREY (x1) 3 1/4 in 3 3/8 in [83 mm] [86 mm] 3 1/4 in [81 mm] LOCATE SLIDE IN OPENING USING DIMENSIONS SHOWN.
Page 86
STEP 1 - WEB SWING ASSEMBLY QTY PART NUMBER DESCRIPTION H100831 NUT BARREL PTH BLK 1/4x3/4 H100832 BOLT PTH 1/4x3/4 IMPORTANT: SLIDE ROPE LOOPS OVER TUBE ENDS FIRST! SLIDE NARROW END OF TUBES INTO LARGER OPENING AFTER SLIDING ROPE LOOPS ONTO TUBES. (x4) BOLT - 3/4"...
Page 87
STEP 5 - FINAL ASSEMBLY A6P00708 ROPE-CHAIN BLACK 51.25" (x4) A4M00633 QUICK LINK BLK (x4) A6P00595 SWING SEAT GREY 22" (x2) A4M01415 26" WEB SWING (x1) WHEN HANGING YOUR SWINGS IT IS RECOMMENDED THAT THE BOTTOM OF THE SWING SEAT, WHEN SITTING ON IT, IS LOCATED NO LOWER THAN (35 cm) 13 7/8 INCHES FROM THE GROUND.
Page 88
STEP 6 - FINAL ASSEMBLY QTY PART NUMBER DESCRIPTION H100379 T-NUT 5/16 BLK H100459 BOLT WH 5/16x1 1/4 BLK A4M02252 AUGER GROUND (x6) STAKE TWIST GROUND STAKE INTO GROUND AT LOCATIONS SHOWN. USING AUGER STAKE AS A GUIDE, DRILL A 3/8" [10mm] HOLE FOR HARDWARE.
