Valcom VE4122-D44 Manual

INTRODUCTION
The VE4122-D44 IP Clock with Speaker includes a
4" Digital Clock and a 2' x 2' Lay-in Ceiling Speaker.
This provides synchronized time, talkback intercom
and loudspeaker paging from one IP network
connection. The 4-digit Digital Clock can be
programmed to sync with any NTP (Network Time
Protocol) server. The clock enclosure is made of
steel with a durable powder coated finish. The
color of the enclosure can be easily changed to
match any décor. Power is provided to both the
clock and speaker via a Power over Ethernet (PoE)
switch meeting the 802.3af specification.
SPECIFICATIONS
Features

RJ-45 network connection

Easy to read, high visibility Red digits display
hours and minutes (4 digit display)

Selectable 12 or 24 hour format

Power over Ethernet (PoE) 802.3af compatible

High Efficiency
DIMENSIONS/WEIGHT – 4 Digit

VIP-D44 – 17.00" L x 3.00" W x 6.75" H
(43.18 cm) x (7.62 cm) x (17.14 cm)
Weight: 4.50 lbs. (2.0 kg)

V-CTLA –23.75" L x 23.75" W x 3.75" D
(60.33 cm) x (60.33 cm) x (9.53 cm)
Weight: 5.5 lbs. (2.5 kg)
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch:
Environment
Temperature:
Humidity:
VE4122-D44
IP CLOCK/SPEAKER DIGITAL 2' X 2'
Class 3
0 to +40° C
0 to 85% non-precipitating
Precautionary Designations

WARNING
Electric Shock. Do Not Expose This
Apparatus To Rain Or Moisture.

AVERTISSEMENT: Afin de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système à la
pluie ou à l'humidité.

Apparatus shall not be exposed to dripping
or splashing and no objects
filled with liquids, such as vases, shall be
placed on the apparatus.

L'appareil ne doit pas être exposé à des
égouttements et éclaboussures et
aucun Objet Rempli de liquide, comme
vase, ne doit être placé sur l'appareil.
CAUTION: To reduce the risk of electric shock,
Refer servicing to qualified service personnel.
1
Issue 2
:
To Reduce The Risk Of Fire Or
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Do not remove cover (on back).
No user serviceable parts inside.
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
947309
