MULTISPAN UTI-38 Manual

TECHNICAL SPECIFICATION
INPUT SPECIFICATION:
Input Types
RTD.1
J,K,RTD = 1°C
Resolution
RTD.1 = 0.1°C
±1% of FSD ± 1°C
Indication
Accuracy
(FSD:-Full Scale Deflection)
DISPLAY AND KEY
Display 4 digit, 7 segment, 0.8" RED LED
Keys SET, INC
DIMENSION
Size
51.5 (H) x 98 (W) x 26 (D) mm
Panel Cutout 46 (H) x 92(W) mm
POWER SUPPLY
Supply
Voltage
Power
Consumption
(VA Rating)
ENVIRONMENT CONDITION:
Operating Temp.
Relative Humidity
Protection Level
(As per request)
TEMPERATURE INDICATOR
Input Range
J 0 to 600°C,
K 0 to 1200°C,
RTD -99 to 400°C,
-99.9 to 400.0°C,
100 to 270V AC, 50-60Hz
2VA @ 230V AC MAX
0°C to 55°C
UP to 95% RH
(non-condensing)
IP-65 (Front side) As per IS/IEC
60529 : 2001
UTI-38
250.0
FRONT VIEW
All dimensions are in mm
~
100 270V AC
L
1
Sensor Input
5
4
3
3-Wire RTD
To enter in parameter setting
To set parameter value
To Change parameter value.
Set parameter to be save & exit.
MECHANICAL INSTALLATION
SET
98
TERMINAL CONNECTION
N
2 3
Sensor input
5
4
Install jumper
when using
3
2 Wire RTD
2-Wire RTD
KEY OPERATION
FUNCTION
OPERATOR MODE
PARAMETER SETTING MODE
4.5 26
RIGHT SIDE VIEW
Panel Cutout
92
4 5
5
4
Thermocouple
PRESS KEY
Press For 5 Sec
Press For 3 Sec
