PV = Process Value
SV = Set Value
TECHNICAL SPECIFICATION
INPUT SPECIFICATION:
Input
Input Types
J
0 to 600°C,
K
0 to 1200°C,
PT-100
PT.1
J,K,PT-100 = 1°C
Resolution
PT.1 = 0.1°C
±1% of FSD ± 1°C
Indication
(FSD:-Full Scale Deflection)
Accuracy
DISPLAY & KEYS :
Upper: 4 digit, 7 segment, 0.56" Red
Display
Lower: 4 digit, 7 segment, 0.33" Green
Key
SET, INC, DEC , ENT
DIMENSION :
Size (mm)
48 (H) x 48 (W) x 95 (D) mm
Panel Cutout
45(H) x 45(W) mm
CONTROL METHOD :
1) PID control with Auto-Tuning
Heating
2) (TP) Time Proportional
3) ON-OFF control
(1) BL.TP ( Blower Time Proportional)
Cooling
(2) ON-OFF control
High/ Absolute Low/Inband/Absolue
Alarm
Outband/End Alarm
POWER SUPPLY:
100 to 270V AC, 50-60Hz
Supply Voltage
Power Consuption
Approx 4VA @ 250V AC MAX
(VA Rating)
TEMPERATURE CONTROLLER
UTC-4202
Range
-99 to 400°C,
-99.9 to 400.0°C,
OUTPUT SPECIFICATION:
Relay Output
Relay
2 Nos
Relay Type
1C/O (NO-C-NC)
Rating
10A, 230V AC / 28V DC
SSR Drive Output
12V DC, 30mA DC
Output Signal
(On-Off condition)
Relay 1 parallel to SSR
ENVIRONMENT CONDITION:
Operating Temp.
0°C to 55°C
UP to 95% RH
Relative Humidity
(non-condensing)
MECHANICAL INSTALLATION
Outline Dimension (mm)
UTC4202
PV
48
R1
R2
SV
TUNE
SET
ENT
48
3
TERMINAL CONNECTION
L
1
~
N
2
Made in India
3
NC
C
4
R1
NO
www.multispanindia.com
5
UTC 4202-RG
Sensor Input
8
8
9
9
10
10
3-Wire RTD
2-Wire RTD
Panel Cutout
Dimension (mm)
45
95
45
8
TC
7
9
-
RTD
10
SSR
-
NO
11
6
R2
C
12
Install jumper
when using
Thermocouple
2 Wire RTD
8
9
Page -1
