Scotchman CPO-350-VS Manual

Cold saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
You have downloaded a manual for our
MODEL CPO-350-VS COLD SAW
Please download our .pdf
"Guide to Extend the Life of Your Saw Blade" too.
Please read this Manual & the Guide
before operating this saw!!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPO-350-VS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Scotchman CPO-350-VS

Summary of Contents for Scotchman CPO-350-VS

  • Page 1 You have downloaded a manual for our MODEL CPO-350-VS COLD SAW Please download our .pdf "Guide to Extend the Life of Your Saw Blade" too. Please read this Manual & the Guide before operating this saw!!
  • Page 2 MODEL CPO 350 VARIABLE SPEED COLD SAW S/N B12632 & AFTER JUNE 2024 SCOTCHMAN IND. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Phone: 605-859-2542.

  • Page 3: Table Of Contents

    Power Down Feed Set-up & Maintenance Stroke Control Adjustment (Power Down Feed) Guard Adjustment (Power Down Feed) Installing Blades (Power Down Feed) Page 2 SCOTCHMAN IND. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Call: 1-605-859-2542...
  • Page 4 Overview of Scotchman Measuring Systems 10.8 Cutting Coolants & Lubricants 10.9 Material Stop 30 Inch (76 CM) 11.0 STOCK BLADES Page 3 SCOTCHMAN IND. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Call: 1-605-859-2542...

  • Page 5: Introduction

    All electrical connections shall be made by a qualified electrician. This machine must be grounded in accordance with the National Electric Code. SCOTCHMAN INDS. - 180 E. HWY 14 - PO BOX 850 - PHILIP, SD 57567 PHONE: 1-800-843-8844 Page 4...

  • Page 6: Warranty

    This machine is top heavy and must be anchored to the floor via the holes in the saw base. 3.0 WARRANTY Scotchman Industries, Inc. will, within three years of the date of purchase, replace F.O.B. the factory or refund the purchase price for any goods which are defective in materials or workmanship, provided the buyer, at the seller’s option, returns the defective goods freight and delivery prepaid to the seller, which...

  • Page 7: Installation & Set-Up

    4.0 INSTALLATION AND SET-UP CAUTION: THIS SECTION DISCUSSES INSTALLATION, SET-UP AND START-UP PROCEDURES. PLEASE READ IT THOROUGHLY BEFORE OPERATING THIS MACHINE. IF YOUR MACHINE IS EQUIPPED WITH EITHER THE POWER VISE OR THE POWER DOWN FEED OPTION, READ ALL SECTIONS CONCERNING THESE OPTIONS BEFORE OPERATING THE SAW.
  • Page 8 VISE FIGURE 1 Page 7...

  • Page 9: Machine Moving Procedures

    4.2 MACHINE MOVING PROCEDURES SEE FIGURE 2 ON THE FOLLOWING PAGE. This machine is shipped on a pallet and can be moved to the installation location by means of a fork lift. CAUTION : THIS MACHINE IS TOP HEAVY AND MUST BE MOVED WITH CARE, ON HARD, FLAT SURFACES ONLY.

  • Page 10: Lifting Eye

    LIFTING EYE LIFTING FORKS FIGURE 2 Page 9...

  • Page 11: Physical Inspection

    4.3 PHYSICAL INSPECTION Once the machine is located, check it for any possible damage incurred in shipment. Remove the lifting eyelet and install the draw handle. CAUTION: DO NOT USE THE LIFTING EYELET FOR ANY MACHINES OTHER THAN THIS SAW. MAKE SURE THAT THE DRAW HANDLE HAS A JAM NUT ON THE THREADS BEFORE INSTALLING IT ON THE SAW.

  • Page 12: Electrical Requirements

    4.4 ELECTRICAL REQUIREMENTS SEE FIGURE 3-1 THRU 3-4 ON THE FOLLOWING PAGES. CAUTION: TO PREVENT DAMAGE TO THE MACHINE AND DANGER TO THE OPERATOR, ALL ELECTRICAL CONNECTIONS SHOULD BE MADE BY A QUALIFIED ELECTRICIAN. THIS MACHINE OPERATES WITH LIQUID COOLANT AND MUST BE GROUNDED IN ACCORDANCE WITH NATIONAL ELECTRIC CODES.
  • Page 13 TRIGGER SWITCH DETAIL 350 VS MANUAL & PK 230-460 VOLT RELAY FIGURE 3-1 Page 12...
  • Page 14 TRIGGER SWITCH DETAIL 350 VS MANUAL & PK 230V SINGLE PHASE RELAY FIGURE 3-2 Page 13...
  • Page 15 350 VS POWER DOWN 230-460 VOLT (See Section 7.10 for Power Down Feed Wiring Diagram) BLACK RELAY BLUE FIGURE 3-3 Page 14...
  • Page 16 350 VS POWER DOWN 230V SINGLE PHASE (See Section 7.10 for Power Down Feed Wiring Diagram) BLACK RELAY BLUE FIGURE 3-4 Page 15...

  • Page 17: Machine Start-Up

    On machines equipped with either a power vise or a power down feed, the air supply must also be disconnected and locked or tagged. Scotchman offers a lock-out switch for this machine as an option, if your plant is not equipped with lock-out capabilities. If you are interested in this option, REFER TO SECTION 7.14 or contact your local dealer or the factory.

  • Page 18: Frl Use And Maintenance

    4.6 FRL USE AND MAINTENANCE SEE FIGURE 4 ON THE NEXT PAGE CAUTION: SHUT OFF AIR SUPPLY BEFORE SERVICING THE FRL The FRL (Filter Regulator Lubricator) is an important and often overlooked item on a cold saw. It helps to keep moisture from contaminating the pneumatic system and adds a little oil to keep the system lubricated.
  • Page 19 Scotchman Air Line Then pull water trap free. Filter Lubricant is recommended can be removed by squeezing the Qt.

  • Page 20: Guard Adjustment

    4.7 GUARD ADJUSTMENT SEE FIGURE 5 BELOW. FOR GUARD ADJUSTMENT PROCEDURES ON SAWS EQUIPPED WITH THE POWER DOWN FEED OPTION, REFER TO SECTION 7.8. The proper adjustment of the blade guard on this machine is crucial to the operation of the machine and the safety of the operator.

  • Page 21: Coolant System

    4.8 COOLANT SYSTEM The coolant reservoir has a capacity of eight (8) gallons (30.3 liters). One gallon of coolant is shipped with the saw. For normal cutting, it should be mixed in a ratio of one part coolant to seven parts water. In conditions of heavier cutting, the ratio of water should be reduced to five parts.

  • Page 22: Cutting Oils & Lubricants

    5.2 CUTTING OILS AND LUBRICANTS SECTION 10.8 lists Scotchman’s parts numbers for cutting oils and lubricants. Using high quality lubricants and oils will greatly increase the life of this equipment. We recommend using only pure, synthetic, water soluble cutting oil for coolant. For the saw head, use a non-EP additive ISO-460 gear oil specified for worm gears.

  • Page 23: Coolant Pump Maintenance

    5.4 COOLANT PUMP MAINTENANCE IF YOUR COOLANT PUMP IS LEAKING OR LACKS POWER, USE THE FOLLOWING STEPS. We recommend replacing the pump seal kit anytime that the pump is dismantled. FOR PART NUMBER IDENTIFICATION, REFER TO SECTION 9.6. Make sure that the power to the machine is off. Remove the four bolts (J) and remove the pump from the machine.
  • Page 24 FIGURE 7 Page 23...

  • Page 25: Machine Operation

    6.0 MACHINE OPERATION 6.1 INSTALLING THE BLADE - MANUAL MACHINES SEE FIGURE 8 BELOW. FOR INSTALLING BLADES ON MACHINES EQUIPPED WITH THE POWER DOWN FEED OPTION, REFER TO SECTION 7.9. Remove Knob (A) & Spread Open Lower Guard To Access Saw Blade FIGURE 8 Page 24...
  • Page 26 CAUTION: USE ONLY HIGH SPEED STEEL BLADES DESIGNED FOR THIS MACHINE. DO NOT MODIFY ANY BLADE TO FIT THIS MACHINE. DO NOT USE BLADES DESIGNED FOR THIS MACHINE ON ANY OTHER EQUIPMENT. The CPO-350 saw is designed to use a maximum 14 inch (350mm) diameter blade. The arbor size is 40mm with four 12mm pins spaced at 64mm.

  • Page 27: Saw Capacities

    6.2 SAW CAPACITIES Figure 9 below is a chart showing the maximum capacities of this machine in various materials at the most common angles from 0 degrees to 90 degrees. CPO - 350 #060331 03/21 90° 45° CAPACITIES WITH MAXIMUM DIAMETER BLADES 350 MM INCHES...

  • Page 28: Selecting The Proper Blade & Cutting Speed

    6.3 SELECTING THE PROPER BLADE AND CUTTING SPEED In cold sawing, there is no such thing as a general purpose blade. To achieve the best results from your saw, proper blade selection is important. There are a couple of charts at the top of the next page (one for tube, the other for solids) that will help to determine the proper blade for your application.

  • Page 29: Material Clamping

    If your saw is equipped with either the power vise or the power down feed options: SEE SECTION 7.0 - OPTIONAL EQUIPMENT, for additional information. Page 28 SCOTCHMAN INDS. - 180 E. HWY 14 - PO BOX 850 - PHILIP, SD 57567 PHONE: 1-800-843-8844...
  • Page 30 Cut thru the thinnest Cut angle with the web section whenever possible up whenever possible. with tube and solids. Special form jaws P/N 076910 - Square tube for multiple parts jaws for the 350 cold saw. or special shapes FIGURE 10 Bolt and Lock Nut for Adjusting Blade Cutting Depth...

  • Page 31: Miter Locking Device

    6.5 MITER LOCKING DEVICE SEE FIGURE 12 ON THE FOLLOWING PAGE. All models manufactured for domestic sales are equipped with a miter locking device which allows quick set-up for mitering at 45 degrees, left and right, and 90 degrees for straight cutting. A miter locking device is available as an option for models manufactured for international sales.
  • Page 32 FIGURE 12 Page 31...

  • Page 33: Optional Equipment

    7.0 OPTIONAL EQUIPMENT 7.1 POWER VISE The power vise is an option that is normally ordered with the saw. It is not recommended as a retro-fit in the field. The power vise allows automatic clamping of the material, which improves productivity and reduces operator fatigue.
  • Page 34 TO ADJUST THE VISE TO THE SIZE OF MATERIAL BEING CUT: Release the locking collar (D) on the vise spindle (see below). The vise spindle is left hand threaded and the locking collar must be turned clockwise to release it. Open the vise, using the positioning handles (E), and place the material in the vise.

  • Page 35: Replacing The Spindle In The Power Vise

    7.3 REPLACING THE SPINDLE IN THE POWER VISE SEE FIGURE 14 BELOW. CAUTION: DISCONNECT THE MACHINE’S POWER AND AIR SUPPLY Disconnect the air lines (A). The air connections on the cylinder are snap connectors. To release the air connections, push the collar around the hose into the fitting and pull the hose out. To reconnect the lines, simply push the air line into the fitting as far as it will easily go.

  • Page 36: Replacing The Seals In The Power Vise

    7.4 REPLACING THE SEALS IN THE POWER VISE SEE FIGURE 15 BELOW. CAUTION: DISCONNECT THE MACHINE’S POWER AND AIR SUPPLY SEAL KIT IS P/N 076371 - Contains two small and two large o-rings and an oil seal. Locations below. Open the vise to its full open position. Disconnect the air lines from the cylinder (A).

  • Page 37: Power Down Feed

    7.5 POWER DOWN FEED The power down feed option, used in conjunction with the power vise option, changes a manual saw into a semi-automatic saw. These options will increase productivity and reduce operator fatigue. The power down feed option will not retrofit to machines with serial number 11940491 and prior in the field. This option can be used on machines with or without the power vise option.
  • Page 38 FIGURE 16 Page 37...

  • Page 39: Stroke Control Adjustment (Power Down Feed)

    7.7 STROKE CONTROL ADJUSTMENT (POWER DOWN FEED) SEE FIGURE 17 ON THE FOLLOWING PAGE. Before powering the machine, the up and down strokes of the saw head must be set. The stroke is set by the collars (A & B) on the shaft (C). TO SET THE STROKE: The saw blade control switch for the saw blade is located in the electrical box on top of the motor.
  • Page 40 FIGURE 17 Page 39...

  • Page 41: Guard Adjustment (Power Down Feed)

    7.8 GUARD ADJUSTMENT (POWER DOWN FEED) SEE FIGURE 18 ON THE FOLLOWING PAGE. CAUTION: THE GUARD MUST BE ADJUSTED EVERY TIME THAT THE STROKE OF THE MACHINE IS ADJUSTED. TO ADJUST THE GUARD: Before adjusting the guard, set the up and down stroke of the machine by following the instructions in SECTION 7.7.

  • Page 42: Detail View

    DETAIL VIEW FIGURE 18 Page 41...

  • Page 43: Installing Blades (Power Down Feed)

    7.9 INSTALLING BLADES (POWER DOWN FEED) SEE FIGURE 19 ON THE FOLLOWING PAGE. CAUTION: USE ONLY HIGH SPEED STEEL BLADES DESIGNED FOR THIS MACHINE. DO NOT MODIFY ANY BLADE TO FIT THIS MACHINE. DO NOT USE BLADES DESIGNED FOR THIS MACHINE ON ANY OTHER EQUIPMENT. The CPO-350 saw is designed to use a maximum 14 inch (350mm) diameter blade.
  • Page 44 FIGURE 19 Page 43...

  • Page 45: Power Down & Power Vise Trouble Shooting

    FOR THE CURRENT ELECTRIC POWER THE PD SOLENOID. DOWN-FEED SYSTEM. Hydraulic Reservoir was overfilled or seals are leaking in the cylinder. SCOTCHMAN IND. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Call: 1-605-859-2542 Page 44...
  • Page 46 UPPER LIMIT SWITCH POWER DOWN FEED WIRING DIAGRAM (Ser. #'s 6425& Up) OIL RESERVOIR CHECK VALVE LOWER 13 21 LIMIT SWITCH DIL A-31 24V RELAY PD CYLINDER 14 22 FLOW CONTROL VISE CYL. VALVE BLACK WHITE BLACK WHITE PK CYLINDER HEAD UPPER LIMIT SW.

  • Page 47: Material Supply Tracks

    Several Guide Assemblies can be mounted to the conveyor if needed. ► NOTE: WE ALSO HAVE COVERED ROLLER CONVEYORS AND SOLID FLAT CONVEYORS AVAILABLE. CONTACT YOUR DEALER OR THE FACTORY FOR MORE INFORMATION OR VISIT WWW.SCOTCHMAN.COM Page 46...

  • Page 48: Exploded View

    EXPLODED VIEW DETAIL VIEW 076938 13" GUIDE ASSEMBLY 029242 - 10' ROLLER CONVEYER W/LEGS WE HAVE COVERED ROLLER CONVEYORS AND SOLID FLAT TABLES (NO ROLLERS) AVAILABLE TOO. SEE AT: WWW.SCOTCHMAN.COM FIGURE 21 Page 47...

  • Page 49: Scotchman Measuring Systems

    For more information, please call your dealer or the factory. Or visit our website at: www.scotchman.com Page 48 SCOTCHMAN IND. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Call: 1-605-859-2542...
  • Page 50 QUICK-LOC 141517 133313 MULTI-LOC DIGITAL QUICK STOP FIGURE 22 Page 49...

  • Page 51: Special Vise Jaws

    7.13 SPECIAL VISE JAWS Special vise jaws for holding square tubing, rectangular tubing and angle iron are stock items. Jaws for holding thin wall round tubes, profiles and bundles are available on a made-to-order basis. See SECTION 6.4 for examples. For prices and delivery on special jaws, contact your local dealer or the factory.
  • Page 52 UPPER LIMIT SWITCH OIL RESERVOIR CHECK VALVE LOWER LIMIT SWITCH PD CYLINDER FLOW CONTROL PK CYLINDER PK SOLENOID PD SOLENOID FIGURE 23 Page 51...

  • Page 53: Trouble Shooting Guide

    8.0 TROUBLE SHOOTING GUIDE 8.1 ELECTRICAL TROUBLE SHOOTING THE MOTOR WILL NOT RUN: A. Some models have a lock-out switch in the base of the saw. If your saw has this option, make sure that it is in the ON position. On manual and power vise machines, the motor switch must be in the ON position for the trigger switch to work.

  • Page 54: Breakage Or Excessive Dulling Of Blades

    Improper re-sharpening is one of the most common problems encountered in cold sawing. Here at Scotchman Ind. We use only modern CNC equipment operated by experienced people. Keep the blade flange, the face of the blade spindle and the blade clean and free from nicks. Any contamination or nicks on the flange, spindle or the blade will cause the blade to run out of alignment.
  • Page 55 FOR BEST RESULTS, USE ONLY SCOTCHMAN COLD SAW BLADES AND COOLANT Send your blades back to our factory to be professionally resharpend on modern CNC equipment operated by our experienced employees. We have a fast turn-around time!! Ship them to: Make sure to include SCOTCHMAN IND.

  • Page 56: Coolant System

    8.3 COOLANT SYSTEM IF COOLANT WILL NOT FLOW: A. Check the wiring connections to the pump and make sure that the pump is running in the right direction. The pump has an arrow in the casting to indicate the direction. B.

  • Page 57: Gear Replacement

    8.4 GEAR REPLACEMENT SEE FIGURE 24 ON THE FOLLOWING PAGE. NOTE: SEE SECTION 9.1 FOR PART NUMBERS Remove the drain plug (A) from the head casting and allow the fluid to drain. Remove the motor from the head. Remove the four bolts (B) from the bearing retainer (C). Remove the worm shaft assembly (D).
  • Page 58 FIGURE 24 Page 57...

  • Page 59: Parts Lists

    9.0 PARTS LISTS 9.1 SAW HEAD ITEM PART # DESCRIPTION 075075 Seal 077150 Needle Bearing 077628 Bearing Housing 077322 Worm Shaft 077624 Saw Spindle 077323 Pivot Bearing 077626 Saw Flange (Includes DD & UU) 077324 221212 M-10 x 30 SHCS Spacer Ring 077325 Bearing...
  • Page 60 SMALL I.D. THIS SIDE 073641 M10 x 65 073641 M10 x 65 073641 M10 x 65 FIGURE 25 Page 59...

  • Page 61: Vise Assembly

    9.2 VISE ASSEMBLY ITEM PART # DESCRIPTION 221220 M-10 x 40 SHCS Cast Grip Cheek (Rear - Includes F) 077319 Vise Jaw (Right) 077610 Vise Jaw Set (Inc. 2 of C & 2 of W) 077612 208012 M-10 Hex Nut 077309 Guide Shaft 077310...
  • Page 62 FIGURE 26 Page 61...

  • Page 63: Guard Assembly

    9.3 GUARD ASSEMBLY MANUAL & POWER VISE MACHINES DESCRIPTION ITEM PART # Guard Shell 077165 Spacer Ring (thin) Hinge Cap (front) 077146 Spacer Ring (thick) Hinge Cap (rear) 077166 Nylon Spacer 077167 M30 Ext. Ret. Ring 077160 M8 Nylon Washer Coupling Arm 077162 077161...
  • Page 64 S & T FIGURE 27 Page 63...

  • Page 65: Motor Assembly

    9.4 MOTOR ASSEMBLY ITEM PART # DESCRIPTION 076883 Fan Cover EMOD 076886 Fan Cover 1 PH 073407 M-5 x 6 Slot Head Fan (25mm Bore) FIMEC 076887 Fan (30mm Bore) EMOD 076884 076893 Fan 1 PH Motor End Casting (30mm Bore) 077381 Motor Bearing (6205Z) (25mm) 075049...
  • Page 66 FIGURE 28 Page 65...

  • Page 67: Electrical Unit (After June 1996)

    9.5 ELECTRICAL UNIT ITEM PART # DESCRIPTION 060094 Switch Box and Lid Sales Included with Item A 221002 M-4 x 12 SHCS 060071 Contactor-24 Volt (S/N Needed) 077881 220 Volt Contactor (Used from 1990-1996) 460 Volt Contactor (Used from 1990-1996) 077882 078456 M4/6 TERMINAL BLOCK...
  • Page 68 DANGER ELECTRICAL HAZARD Turn off power and lock out before servicing. FIGURE 29 Page 67...

  • Page 69: Coolant Pump

    9.6 COOLANT PUMP ITEM PART # DESCRIPTION 1PH 230V Pump 060166 230V 1PH Pump Assembly 060205 230V 3PH Pump 060150 230V 3PH Pump Assembly 060200 460V 3PH Pump 060158 460V 3PH Pump Assembly 060201 575V Coolant Pump 060160 Above Assemblies include A, G & I. Impeller (Obsolete) 060152 End Cap...
  • Page 70 FIGURE 30 Page 69...

  • Page 71: Cast Base And Pedestal

    9.7 CAST BASE AND PEDESTAL ITEM PART # DESCRIPTION Pedestal (Inc. S, R & V) 077300 078600 Pivot Shaft Spring Mount (Lower) 077364 Return Spring 077365 221210 M10 x 25 SHCS Spring Mount (Upper) 077363 077142 M10 Grease Zerk Cast Base (Inc. I & U) 077113 073350 M10 x 100 HHCS...
  • Page 72 FIGURE 31 Page 71...

  • Page 73: Saw Base Cabinet

    9.8 SAW BASE CABINET ITEM PART # DESCRIPTION 760115 CPO Base Cabinet Painted Drawer Sales 760113 Pump Mounting Bracket 760115.8 073420 M-8 x 16 DIN912 SHCS 215013 M-8 Greer Nut 660110 275/350 Complete Base Page 72...
  • Page 74 FIGURE 32 Page 73...

  • Page 75: Variable Speed Drive

    9.9 VARIABLE SPEED DRIVE VARIABLE SPEED MOTOR CONTROLS ITEM QTY PART # DESCRIPTION 019121 230V STICKER 019122 460V STICKER 078205 240V 5HP VFD ASSY-PAINTED 078220 1PH 10HP VFD ASSY-PAINTED 078210 480V 5HP VFD ASSY-PAINTED 077867 GROUND LUG 87-003 078285 5HP 230V VFD-PROGRAMMED 078270 10HP 1PH VFD-PROGRAMED 078286 5HP 460V VFD-PROGRAMMED...
  • Page 76 FIGURE 33 Page 75...

  • Page 77: Optional Equipment Parts Lists

    10.0 OPTIONAL EQUIPMENT PARTS LISTS 10.1 POWER VISE ASSEMBLY ITEM PART # DESCRIPTION 077542 Lubricator Seal Kit -Parker (Obsolete) 077462 077539 Cast Grip Cheek Front (inc. HH) Bowl - Parker (Obsolete when stock is gone) 077319 Cast Grip Cheek Rear (inc. HH) 077554 Bowl, Lubicator - Parker (Modular FRL) M-6 x 80 SHCS...
  • Page 78 FIGURE 34 Page 77...

  • Page 79: Power Down Feed Assembly

    10.2 POWER DOWN FEED ASSEMBLY ITEM PART # DESCRIPTION 078510 350 PD Upper Bracket Assy. 221210 M10 X 25 SHCS 077211 Return Spring 078524 PD Cylinder Pivot 078525 350 PD Lower Brkt Assy. 140415 1/2" x 1-1/2" Clevis Pin 078520 PD Stop Rod Assy.
  • Page 80 FIGURE 35 Page 79...

  • Page 81: Power Down Feed Controls - S/N B64251003 & Up

    10.3 POWER DOWN FEED CONTROLS (S/N B64251003 & UP) ITEM PART # DESCRIPTION 077736 PD Valve Mount 077183 Cord Connector 077738 90° Swivel 047535 Flow Control Valve 077746 1/4" NPT x 1/4" Street PL Regulator with Gauge 078190 1/8" Hex Nipple 077770 Gauge 077538...
  • Page 82 BAFFLE HEAD RETURN CHECK VALVE CLAMP RELEASE FLOW MAIN CONTROL PRESSURE REG. OPTIONAL: PRESSURE REGULATOR FOR VISE SHUT CONTROL SOL. FIGURE 36 Page 81...

  • Page 83: Power Down Feed Electric Controls - S/N B64251003 & Up

    10.4 POWER DOWN FEED ELECTRICAL CONTROLS S/N B64251003 & UP (See Note) ITEM PART # DESCRIPTION 075250 Enclosure Cord Grip 077183 Mounting Plate 075205 Electric PD Mount Strip 075210 073440 M4 x 6 SHCS 078104 End Bracket 078456 M4/6 Terminal Block Jumper Screw 078457 24 Volt Relay AC...
  • Page 84 T* U* These components were used with the old style DC controlled power down-feed Above used in S/N B64251003 to B79960607 FIGURE 37 Page 83...

  • Page 85: Guard Assembly (Power Down Feed)

    10.5 GUARD ASSEMBLY (POWER DOWN FEED) ITEM PART # DESCRIPTION 350 PD Guard Sales 077645 073641 M10 x 65 SHCS Movable Guard Snap Ring 077167 Spacer Nylon 077202 PD Guard Stop 078516 073691 M6 x 12 Knob 077165 Ring 060140 9/16 x 85”...
  • Page 86 073641 M10 x 65 073641 M10 x 65 073641 M10 x 65 FIGURE 38 Page 85...

  • Page 87: Foot (304 Cm) Supply Track

    BASE MATERIAL GUIDE 13" PAINT 214012 M10 DIN125 REGULAR WASHER 221120 M8 X 25 DIN9121580 12.9 SHCS 229225 M10 X 12 X 70 SB912 Page 86 SCOTCHMAN IND. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Call: 1-605-859-2542...
  • Page 88 076938 FULLY ASSEMBLED 13" GUIDE VIEW ASSEMBLY 029242 - 10' ROLLER CONVEYER W/LEGS FIGURE 39 Page 87...

  • Page 89: Overview Of Scotchman Measuring Systems

    10.7 OVERVIEW OF SCOTCHMAN MEASURING SYSTEMS Scotchman Ind. has several measuring systems available for our saws. They can be attached to our conveyors and increase speed and accuracy. All are AMERICAN MADE and below is the name and brief description of each.
  • Page 90 Below is an example of our Quick-Loc Measuring System on a conveyor that is mounted to a saw. To change the measurement you grab the squeeze handle and move the stop to the desired length indicated on the measuring tape. The Quick-Loc Arm is designed to pivot up out of the way if needed.

  • Page 91: Cutting Coolants & Lubricants

    10.8 CUTTING COOLANTS AND LUBRICANTS ITEM PART # DESCRIPTION 1 Gal. 075751 Synthetic Coolant 5 Gal. 075752 Synthetic Coolant Synthetic Coolant 55 Gal. 075754 1 Gal. 075756 Stainless Coolant 5 Gal. 075757 Stainless Coolant 1 Qt. 075753 Air Line Lubricant 1 Gal.
  • Page 92 FIGURE 41 Page 91...

  • Page 93: Stock Blades

    100 Tooth 074392 110 Tooth 074393 120 Tooth 074394 150 Tooth 074395 180 Tooth 074396 220 Tooth 074397 280 Tooth Page 92 SCOTCHMAN INDS. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Phone: 1-800-843-8844...
  • Page 94 Triple Chip and Alternate Grinds are by far the most common. Power 2000 Blades have the Notch Grind & Titanium Coating. FIGURE 42 Page 93 SCOTCHMAN INDS. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Phone: 1-800-843-8844...
