2 External Appearance
2.1 Indoor Units
Table 1-2.1: Indoor unit appearance
One-way Cassette
Q1
Compact Four-way Cassette
Q4C
Medium Static Pressure Duct
T2
Wall-mounted
G
Floor Standing
F
2.2 Outdoor Units
Table 1-2.4: Outdoor unit appearance
8KW
Mini C Series VRF 50/60Hz
Two-way Cassette
Q2
Four-way Cassette
Q4
High Static Pressure Duct
T1
Ceiling & Floor
DL
10-12KW
14-16KW
5
