Mini C Series VRF 50/60Hz
1 Outdoor Unit Electric Control Box Layout
Figure 5-1.1: 80 model electric control box
Module board
DC fan motor control module
Output control assembly
Main control board
34
Module board
Main control board
Power input and power filter
PFC module
IPM module
