Figure 5-1.4: 140/160 model outdoor unit Communication switchboard PCB Ports
Table 5-1.4: 140/160 model communication switchboard PCB ports
Label in
Port code
Figure 5-1.4
1
CN502
2
CN501
3
CN4
4
CN20
5
CN21
6
CN18
7
CN5
8
CN24
9
CN12
10
CN27
11
CN22
12
CN13
13
CN7
14
CN10
15
CN11
16
CN50
17
/
18
CN17
19
CN19
20
U
21
V
22
W
40
Content
Power input port
Power input port
Relay control/current sampling input port
Communication port between outdoor unit and indoor
unit
Reserved
Outdoor unit heat exchanger pipe temperature/outdoor
environment temperature detection port
Compressor discharge temperature detection port
Compressor discharge temperature detection port
Signal input port of system low pressure & high pressure
detect switch
Online Programmable Port
EEV driving port
Load output port(4-way valve)
Reserved
Reserved
Load output port(crankcase heating)
Power input port
EEPROM Port
DC fan1 port
DC fan2 port(Reserved)
Compressor's U phase voltage output port
Compressor's V phase voltage output port
Compressor's W phase voltage output port
Port voltage
AC 220V
AC 220V
DC 12V/AC 0-10.4V
DC 2.5~5V
/
DC 0~5V(in dynamic change)
DC 0~5V(in dynamic change)
DC 0~5V(in dynamic change)
DC 0~5V(in dynamic change)
DC 5V
The first pin: DC12V;
The other four pins: in dynamic change
AC 220
/
/
AC 220
AC 220V
DC 5V
DC 380
DC 380
DC 380
DC 380
DC 380
