Figure 5-1.2: 100/120 model electric control box
Main control board
PFC module
DC fan port
Switching power supply
AP2
Communication
converter board
Mini C Series VRF 50/60Hz
Main control board
Common mode inductor
Electric capacitor
Compressor connecter
IPM module
Power supply terminals
Communication
converter board
35
