MULTISPAN MS-1208-M1 User Manual page 6

SAFETY PRECAUTION
!
All safety related codifications, symbols and instructions that appear in this operating manual or on
the equipment must be strictly followed to ensure the safety of the operating personnel as well as the
instrument.
If all the equipment is not handled in a manner specified by the manufacturer, it might impair the
protection provided by the equipment.
Read complete instructions prior to installation
and operation of the unit.
WARNING : Risk of electric shock.
WARNING GUIDELINES
WARNING : Risk of electric shock.
1. To prevent the risk of electric shock, power supply to the equipment must be kept OFF while doing the wiring
arrangement. Do not touch the terminals while power is being supplied.
2. To reduce electro magnetic interference, use wire with adequate rating and twists of the same of equal size
shall be made with shortest connection.
3. Cable used for connection to power source, must have a cross section of 1mm or greater. These wires
should have insulations capacity made of at least 1.5kV.
4. When extending the thermocouple lead wires, always use thermocouple compensation wires for wiring for
the RTD type, use a wiring material with a small lead resistance (5 max per line) and no resistance
differentials among three wires should be present.
5. A better anti-noise effect can be expected by using standard power supply cable for the instrument.
INSTALLATION GUIDELINES
1. This equipment, being built-in-type, normally becomes a part of main control panel and in such case the
terminals do not remain accessible to the end user after installation and internal wiring.
2. Do not allow pieces of metal, wire clippings, or fine metallic fillings from installation to enter the product or
else it may lead to a safety hazard that may in turn endanger life or cause electrical shock to the operator.
3. Circuit breaker or mains switch must be installed between power source and supply terminal to facilitate
power 'ON' or 'OFF' function. However this mains switch or circuit breaker must be installed at convenient
place normally accessible to the operator.
4. Use and store the instrument within the specified ambient temperature and humidity ranges as mentioned
in this manual.
MECHANICAL INSTALLATION GUIDELINES
1. Prepare the panel cutout with proper dimensions as shown above.
2. Fit the unit into the panel with the help of clamp given.
3. The equipment in its installed state must not come in close proximity to any heating source, caustic vapors,
oil steam, or other unwanted process Byproducts.
4. Use the specified size of crimp terminal (M3.5 screws) to wire the terminal block. Tightening the screws on
the terminal block using the tightening torque of the range of 0.5 N.m.
5. Do not connect anything to unused terminals.
1. The equipment should be cleaned regularly to avoid blockage of ventilating parts.
2. Clean the equipment with a clean soft cloth. Do not use isopropyl alcohol or any other cleaning agent.
3. Fusible resistor must not be replaced by operator.
MAINTENANCE
Ω
