Specifications

The SGPAT10xx-0x5 was designed to meet the specifications below.
Standards
Max Packet Size
Max MAC Addresses
Shared buffer memory
Dimensions
Power Source

Power Consumption

Operating Temp.
Storage Temp.
Operating Humidity
Altitude
Weight
Weight
Compliance
Immunity Compliance
Safety Compliance
MTBF
Warranty
Power Consumption
The table below shows SGPAT power consumption. The table shows SFP models (SGPAT1040-x05) loaded with
one or two TN-SFP-SXD (1000Base-SX) SFPs.
Model
SGPAT1013-105
SGPAT1039-105
SGPAT1040-105
SGPAT1040-205
SGPAT1040-305
33719 Rev. D
IEEE 802.3-2012, IEEE 802.at PSE-PoE+, IEEE 802.3U, IEEE 802.3ab, IEEE 802.3z,
IEEE 802.3x, IEEE 802.3az
10240 bytes
8k
1Mbit
3.25" (82mm) W x 4.8" (122mm) D x 1.0" (25mm) L
External AC/DC 56VDC power adapter
56VDC, 1.17A, 65.5W (assumes both PoE ports are delivering the full 30W).
See Power Consumption table below.
0 to +45 deg. C (0 to +113 deg. F)
-40 to +85 deg. C (-40 to +185 deg. F)
5% to 95% (non-condensing)
0-10,000 feet
2lbs. (0.90kg) SGPAT with packaging
1.55 lbs. (0.7 Kg.) SGPAT
EN55022 Class A, EN55024, CE Mark, Power Supply is UL listed
EN55024-2010
SGPAT: N/A. External AC-DC supply: CE mark, UL Listed.
Without power supply:
Per MIL-HDBK 217F Parts Stress Method (GB) MTBF = 163000 Hrs.
Per Bellcore Parts Stress Method MTBF = 450000 Hrs.
With power supply:
Per MIL-HDBK 217F Parts Stress Method (GB) MTBF = 42000 Hrs.
Per Bellcore Parts Stress Method MTBF = 115000 Hrs.
Lifetime
Converter Power
43mA@55.8V (2.3W)
43mA@55.8V (2.3W)
43mA@55.8V (2.3W)
60mA@55.8V (3.4W)
80mA@55.6V (4.5W)
https://www.transition.com
SGPAT10xx-x05 PoE+ Converter User Guide
PoE Power
537mA@55.8V (30W)
537mA@55.8V (30W)
537mA@55.8V (30W)
537mA@55.8V (30W)
1.07A@55.8V (60W)
