RIUKOE Ares Profile 700 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
Ares Profile 700

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ares Profile 700 and is the answer not in the manual?

Questions and answers

Related Manuals for RIUKOE Ares Profile 700

Summary of Contents for RIUKOE Ares Profile 700

  • Page 1 Ares Profile 700 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    INDEX 1.STATEMENT ..................... 2 2.ACCESSORIES ..................2 3.SAFETY INSTRUCTION ................2 4.INSTALLATION ..................4 5.DMX CONNECTION ..................5 6.TECHNICAL SPECIFICATION ..............7 7.HOW TO SET THE UNIT .................11 8.CHANNEL DESCRIPTION ..............14 9.TROUBLE SHOOTING ................19 10.CLEANING AND MAINTENANCE ............20...

  • Page 3: Statement

    1.STATEMENT product well capability intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included guarantee, also cannot be responsible for any malfunction & problem owing to ignore the manual.

  • Page 4: Preventing Electric Shock

    installation code by a person familiar with the construction and operation of the fixture and the hazards involved. Preventing electric shock WARNING! Risk of electric shock. Always power off/unplug the fixture before removing any covers.  Ensure that the power is turned off when connecting the fixture to the AC ...

  • Page 5: Installation

    Do not look directly at the light source from close range.  Take precautions to prevent injury due to falls when working at height.  For permanent installation, ensure that the fixture is securely fastened to a  load-bearing surface with suitable corrosion-resistant hardware. For temporary installation with clamps, ensure that the quarter-turn ...

  • Page 6: Dmx Connection

    point integrated in the base assembly. 5.DMX CONNECTION DMX-512 control connection: Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-pin XLR input of the moving head. You can chain multiple Moving head together through serial linking.

  • Page 7: Dmx-512 Connection With Dmx Terminator

    DMX-512 connection with DMX terminator: For installations where the DMX cable has to run a long distance or is in an electrically noisy environment, such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain.

  • Page 8: Dmx Address Setting

    DMX Address Setting: By using a universal DMX controller to control the units, you will need to set DMX address from 1 to 512 so that the units can receive DMX signal. Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink.
  • Page 9 - Lamp source: Lamp : 750W White LED 7000K Module - Power:820W - Color temperature: 7000-7500k - Light source life: 20000h - Voltage:AC100-240V,50/60Hz Optical System - Zoom angle: linear 5°- 55° Color Wheel - 1 Color wheel with 6 colors - Linear CMY color mixing system - Variable CTO: 2700K-7000K Gobo wheel...
  • Page 10 Protocols - Control mode: DMX512, master-slave operation , Auto, Sound - Channel mode: 36/41 CHs mode - Support RDM function, DMX software upgrade function Display/Case/Base - Display mode: LCD display, lamp temperature display, Chinese and English display, reverse display - High temperature resistant engineering plastic case + aluminum base - Dust-proof and oil-proof design Movement - Pan/ Tile: 540°/270°...

  • Page 11: Gobo Wheel

    Gobo Wheel...

  • Page 12: How To Set The Unit

    Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. 7.HOW TO SET THE UNIT To select any of the given functions, press the MENU button up to where the required function is showing on the display.
  • Page 13 language 中文 English Mode 1 Screen Saver Mode 2 Mode 3 Mode 4 Auto Screen Rot Reverse Display Forward Normal DMX indicate Mode 1 Mode 2 Signal Bright 1-10 Screen light 1-10 Touch Enable Touch Rectify Scene select 1-10 Scene time 1-255S Control Mode 1:Pan...
  • Page 14 8.Cyan 0-255 9.Magenta 0-255 10.Yellow 0-255 11.CTO 0-255 12.Color wheel 0-255 13.Color2 0-255 14.Gobo wheel 0-255 15.R-Gobo wheel 0-255 16.Gobo wheel rotation 0-255 17.Effect wheel insert 0-255 18.Effect wheel rotation 0-255 19.Focus 0-255 20.Focus Fine 0-255 21.Zoom 0-255 22.Prism 0-255 23.Prism Rotation 0-255 24.Prism Fine...

  • Page 15: Channel Description

    Close Tilt invert Open Close P/T rectify Open Close Pan offset 4-150 Tilt offset 4-48 Dimmer Mode Normal Mode 1 Mode 2 Data hold Open Close Scene time 1-255 Factory setting Open Close Stepper info Error logging Fixture status Status Version H3.12 Light time...
  • Page 16 [ CH3 ] [ CH3 ] Tilt 0-255 0-270(degree) [ CH4 ] [ CH4 ] Tilt Fine 0-255 0-1(degree) [ CH5 ] [ CH5 ] PT Spd 0-255 Fast to slow [ CH6 ] [ CH6 ] Strobe Dark 4-127 Pluse strobe slow to fast 128-191 Fade strobe slow to fast...
  • Page 17 White 10-19 Gobo1 20-29 Gobo2 30-39 Gobo3 40-49 Gobo4 50-59 Gobo5 60-69 Gobo6 70-79 Gobo7 80-89 Gobo8 90-94 Shake slow to fast Gobo2 95-99 Shake slow to fast Gobo2 100-104 Shake slow to fast Gobo3 105-109 Shake slow to fast Gobo4 110-114 Shake slow to fast Gobo5 115-119...
  • Page 18 80-89 Shake slow to fast Gobo1 90-99 Shake slow to fast Gobo2 100-109 Shake slow to fast Gobo3 110-119 Shake slow to fast Gobo4 120-129 Shake slow to fast Gobo5 130-139 Shake slow to fast Gobo6 140-149 Shake slow to fast Gobo7 150-190 Rotate reverse (fast to slow) 191-192...
  • Page 19 196-255 Rotate reverse (slow to fast) [ CH24 ] [ CH27 ] Pri.R1 F 0-255 [ CH28 ] Prism2.R 0-127 0-360(degree) 128-187 Rotate forward (fast to slow) 188-195 Stop 196-255 Rotate reverse (slow to fast) [ CH29 ] Pri.R2 F 0-255 [ CH25 ] [ CH30 ]...

  • Page 20: Trouble Shooting

    240-255 Reset fixture over 3 second 9.TROUBLE SHOOTING Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1.

  • Page 21: Cleaning And Maintenance

    2. Internal temperature may be too high. Check if replacement of fan is needed on the head. E. No response to the sound 1. Make sure the unit does not receive DMX signal.. 2. Check microphone to see if it is good by tapping the microphone. F.
  • Page 22 MAINTENANCE Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized service technician. Should you need any spare parts, please order genuine parts from your local dealer.
  • Page 23 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
