Projector 40x10W RBGW
This product manual contains important information about the safe
installation and use of this projector. Please read and follow these
instructions carefully and keep this manual in a safe place for future
reference.
User manual
Please read the instructions carefully before use
(WL-W4010-IP65)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RIUKOE WL-W4010-IP65
Summary of Contents for RIUKOE WL-W4010-IP65
- Page 1 Projector 40x10W RBGW (WL-W4010-IP65) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Information....................2 2. IP65 Rated ......................3 3. DMX Connection ....................4 4. Cleaning ........................ 6 5. Main Menu......................6 6. How to control the lighting ..................9 7. DMX Channels ....................10 8. Feature & Specifications ..................15... -
Page 3: Safety Information
STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 4: Avoid Personal Injury
Install in a location that prevents accidental contact with the fixture. Install only in a well-ventilated space. Install only in accordance with applicable building codes. Do not paint, cover or modify the fixture. Keep all flammable materials away from the fixture. ... -
Page 5: Dmx Connection
indicates the extent of protection against particles entering the fixture and the second digit (Water Protection) indicates the extent of protection against water entering the fixture. An IP65 rated lighting fixture is one, which has been designed and tested to protect against the ingress of dust (6) and high-pressure water jets from any direction (5). - Page 6 using a DMX cable. If using a cabled DMX system, connect the DMX in cable (with male 3-pin XLR plug) and out cable (with female 3-pin XLR plug) to the DMX data link. Terminate the DMX out cable of the last fixture in the data link. For outdoor installations, use only IP-rated XLR connectors suitable for outdoor use.
-
Page 7: Cleaning
3.4 Master/Slave Signal Connection 4. Cleaning To maintain optimal performance, regular cleaning is essential. Cleaning schedules will vary depending on the operating environment, and the installation should therefore be checked at frequent intervals within the first few weeks of operation to see whether cleaning is necessary. This procedure will allow you to assess cleaning requirements in your particular situation. - Page 8 ○ 1 LCD: Displays menu options and selected features; ○ 2 LED indicator light: When has DMX Signal input Cool White; Wireless Mode Green; Cool Blue Power Power Light ○ 3 Button MENU Select Function DOWN Select the next menu option Select the previous menu option Enter Confirm the selected function...
-
Page 9: Main Function
5.2 Main Function To select a preset feature, press the MENU button to select the MENU option you want. Press ENTER button to ENTER the selected function, the display screen will blink, then use the UP/DOWN button to select the desired function, press ENTER button to confirm. -
Page 10: How To Control The Lighting
G-ADJ Green adjust B-ADJ Blue adjust W-ADJ White adjust Color Select (0-255). Evenly distribute 8 colors Macro (0-20) No function; when the value is greater than 20, 34 built-in programs are allocated equally. Macro Speed (0-255) Macro function speed adjustment: 0 is the fastest and 255 is the slowest. -
Page 11: Universal Dmx Controller
1. With Wireless Launch matching, the matching YK before light hair white light, the code after the completion of the state has the following several kinds of state: 1, the lighting in failing to receives the signal, YK indicator light indicates a red flashing status;... - Page 12 0-255 Green Intensity Green 0-100% 0-255 Blue Intensity Blue 0-100% 0-255 White Intensity White 0-100% 10 CHs Mode Value Function Description 0-255 Master Dimmer All colors 0-100% 0-255 Strobe From slow to fast 0-255 Red Intensity Red 0-100% 0-255 Green Intensity Green 0-100% 0-255 Blue Intensity...
- Page 13 corresponds to built-in programs 0-255 Built-in program speed From fast to slow 0-255 Background Red Dimming Background Red 0-100% 0-255 Background Green Dimming Background Green 0-100% 0-255 Background Blue Dimming Background Blue 0-100% 0-255 Background White Dimming Background White 0-100% 41 CHs Mode Value Function...
- Page 14 0-255 The fifth paragraph light Dimming White 0-100% 0-255 The sixth paragraph light Dimming Red 0-100% 0-255 The sixth paragraph light Dimming Green 0-100% 0-255 The sixth paragraph light Dimming Blue 0-100% 0-255 The sixth paragraph light Dimming White 0-100% 0-255 The seventh paragraph light Dimming Red 0-100%...
- Page 15 The first paragraph light Dimming Blue 0-100% The first paragraph light Dimming 0-100% White The second paragraph light Dimming 0-100% The second paragraph light Dimming 0-100% Green The second paragraph light Dimming 0-100% Blue The second paragraph light Dimming 0-100% White The third paragraph light Dimming Red 0-100%...
-
Page 16: Feature & Specifications
The seventh paragraph light Dimming 0-100% Blue The seventh paragraph light Dimming 0-100% White The eighth paragraph light Dimming 0-100% The eighth paragraph light Dimming 0-100% Green The eighth paragraph light Dimming 0-100% Blue The eighth paragraph light Dimming 0-100% White The ninth paragraph light Dimming Red 0-100%... - Page 17 Power consumption:400W Photometrics Light source:40x10W RGW 4 in 1 LED Beam Angle: 8°(25°、40° optional) Control DMX Control:5/10/14/41/46 CHs Modes of operation: DMX, Auto, Master/Slave, Wireless-DM Structure LCD Display; Cover :Casting Aluminum Weight & IP Rated Weight: net weight (12.4kg) ...
- Page 18 Lumen Date Angle Color 1975 1810 8° 2790 RGBW 9336 2330...
- Page 19 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
