Summary of Contents for RIUKOE WiB3 Flat
- Page 1 WiB3 Flat This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Information....................2 2. Configuring the fixture for DMX control ............... 3 3. Cleaning ........................ 4 4. DMX Channel ....................... 4 5. Control menu ......................6 6. WiFi App Setting ....................8 7. IR Remote Control ....................9 8. -
Page 3: Safety Information
STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 4: Configuring The Fixture For Dmx Control
Install in a location that prevents accidental contact with the fixture. Install only in a well-ventilated space. Install only in accordance with applicable building codes. Do not paint, cover or modify the fixture. Keep all flammable materials away from the fixture. ... -
Page 5: Cleaning
the DMX start address. Each fixture must have a DMX start address set. For example, if a fixture has a DMX address of 10 and it is in 4-channel DMX mode, then it uses channels 10, 11,12 and 13. The following fixture in the DMX chain could then be set to a DMX address of 14. - Page 6 Blue dimming 0 -255 0 -255 Green dimming 0 -255 Blue dimming White dimming 0 -255 0 -255 Blue dimming 0 -255 White dimming Amber dimming 0 -255 0 -255 White dimming 0 -255 Amber dimming Purple dimming 0 -255 Amber tone 0 -255 Purple dimming light 0-10 Closed light，...
-
Page 7: Control Menu
5. Control menu Display: 20/40/60/80/100: Battery level indicator OPERATING INSTRUCTION Press "Menu" to "Set DMX Address", and press "ENTER" keys to enter into Show "Set DMX Address DMX Address:001",Press the "UP and DOWN" keys to amended Press "ENTER" keys to save and Exit, Press the "MENU" Keys does not save and Exit A001 A001—A512... - Page 8 be adjusted by pressing the up and down keys AUT0 AUT0 All effect modes, confirmed speed mode SP01-SP16, up and down key adjustment AUT1 Color-change self-propelled mode, confirmed speed mode SP01-SP16, up and down key adjustment AUT2 Gradient self-propelled mode, confirmed speed mode SP01- SP16, adjustable with up and down keys AUT3 Mutation self-propelled mode, confirmed speed mode SP01-...
-
Page 9: Wifi App Setting
2.4G Wireless 2.4G on 1、 Wireless mode:ID1 -ID7 (1 red, 2 green, 3 yellow, 4 blue, 5 purple, 6 light blue, 7 white) 2、 The red light flashes slowly when the host sends, and the green light flashes slowly when the slave receives Wireless 2.4G off V1.0... -
Page 10: Ir Remote Control
When the connection is successful, exit the phone function settings, open the LED LAMP application software，select the “LED LIGHT” and open, then can be controlled directly. Different phone operating interface may be different, but the function is the same. 7. IR Remote Control IR Remote Panel ... -
Page 11: Wireless Controller Connection
Auto: Turn on auto running and gradual change switch by pressing +- Strobe: Press +- to change speed Fade: Color gradient, Press +- to change speed On/off: Turn on/off all colors +-: Bright intensity/speed control ... -
Page 12: Specification
There is status lamp on transmitter, it have 7 colors, corresponding to 7 wireless DMX channels in light. CH1>>RED, CH2>>GREEN, CH3>>RED+GREEN, CH4>>BLUE CH5>>RED+BLUE CH6>>BLUE+GREEN CH7>>RED+BLUE+GREEN 9. Specification Power • Input Voltage: 100~240V AC, 50/60 Hz. • Power : 54W Photometrics •... - Page 13 Effects • Dimming: 0-100%. • Strobe: 1-20 Hz. Control • Control mode: DMX512, Master-Slave, Auto, 2.4G Wireless DMX,IR,App • DMX Channels: 6 / 8 / 10 • Display: Display with 4-touch button control. Housing • Materials: Die Cast Aluminum. • Finishing: Matte Black.
- Page 14 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
