This product manual contains important information about the safe
installation and use of this projector. Please read and follow these
instructions carefully and keep this manual in a safe place for future
reference.
User manual
Please read the instructions carefully before use
CiB6 IP
(GZ Wireless Version)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RIUKOE CiB6 IP
Summary of Contents for RIUKOE CiB6 IP
- Page 1 CiB6 IP (GZ Wireless Version) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual...
- Page 2 TABLE OF CONTENTS 1. Safety Information....................2 2. IP65 Rated ......................3 3. Configuring the fixture for DMX control ............... 4 4. Cleaning ........................ 5 5. DMX Channel ....................... 5 6. Control menu ......................8 7. WiFi App Setting ....................11 8.
- Page 3 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
- Page 4 Install in a location that prevents accidental contact with the fixture. ⚫ Install only in a well-ventilated space. ⚫ Install only in accordance with applicable building codes. ⚫ Do not paint, cover or modify the fixture. ⚫ Keep all flammable materials away from the fixture. ⚫...
- Page 5 define the degree of protection. The first digit (Foreign Bodies Protection) indicates the extent of protection against particles entering the fixture and the second digit (Water Protection) indicates the extent of protection against water entering the fixture. An IP65 rated lighting fixture is one, which has been designed and tested to protect against the ingress of dust (6) and high-pressure water jets from any direction (5).
- Page 6 4. Cleaning To maintain optimal performance, regular cleaning is essential. Cleaning schedules will vary depending on the operating environment, and the installation should therefore be checked at frequent intervals within the first few weeks of operation to see whether cleaning is necessary. This procedure will allow you to assess cleaning requirements in your particular situation.
- Page 7 141-150 CT 6400K 151-160 CT 6800K 161-170 CT 7200K 171-180 CT 7600K 181-190 CT 8000K 191-200 CT 8400K 201-210 CT 8800K 211-220 CT 9200K 221-230 CT 9600K 231-240 CT 10000K 241-255 NO FUNCTION 0-255 1-255 Blue 0-100% 1-255 Red 0-100% 1-255 Green 0-100% 0-255 1-255 White 0-100%...
- Page 8 111-120 CT 5200K 121-130 CT 5600K 131-140 CT 6000K 141-150 CT 6400K 151-160 CT 6800K 161-170 CT 7200K 171-180 CT 7600K 181-190 CT 8000K 191-200 CT 8400K 201-210 CT 8800K 211-220 CT 9200K 221-230 CT 9600K 231-240 CT 10000K 241-255 NO FUNCTION 0-9Closed light 10-50Static color mixing 51-100 Jump mode...
- Page 9 6. Control menu Display: OPERATING INSTRUCTION Press "Menu" to "Set DMX Address", and press "ENTER" keys to enter into Show "Set DMX Address DMX Address:001",Press the "UP and DOWN" keys to amended Press "ENTER" keys to save and Exit, Press the "MENU" Keys does not save and Exit Display Mode Function Description...
- Page 10 25KHZ 25K Refresh Frequency Red:0-255 Red Manual Dimming Green:0-255 Green Manual Dimming Blue:0-255 Blue Manual Dimming Custom White:0-255 White Manual Dimming Yellow:0-255 Yellow/Amber Manual Dimming UV:0-255 Purple Manual Dimming Static Colour:01-32 32 Types Static Color Mixing Speed:00-16 Strobe Speed (static color mixing when the speed is 00) Program Auto Speed:00-16...
- Page 11 Back Light Always on Display Normally Open Display standby for X seconds and turn off the screen ON/OFF Infrared remote control on/off Menu Lock ON/OFF Key lock on/off (When locking the screen, press and hold the UP+DOWN key to unlock) Factory NO/YES System self check reset...
- Page 12 and operation mode of the lamp) • Over temperature protection function: (1. When the temperature reaches 50 ° 59 ° C, the program will automatically reduce the brightness by 30%; 2. When the temperature reaches 60 ° 69 ° C, the program will automatically reduce the brightness by 25%;...
- Page 13 When the connection is successful, exit the phone function settings, open the LED LAMP application software，select the “LED LIGHT” and open, then can be controlled directly. Different phone operating interface may be different, but the function is the same. 8. IR Remote Control IR Remote Panel •...
- Page 14 • RGBWAUV: static led colors (can press +/- to do the color mixing ) • 0-9 buttons: Built-in colors. • Sound: Sound modes press this to change. Press +- to change sensitivity How to set the IR Remote control Set the infrared remote control function on (ON) in the menu to turn on the remote control function.
- Page 15 CH1>>RED, CH2>>GREEN, CH3>>RED+GREEN, CH4>>BLUE CH5>>RED+BLUE CH6>>BLUE+GREEN CH7>>RED+BLUE+GREEN 10. Specification Power • Input Voltage: 100~240V AC, 50/60 Hz. • Power : 120W Photometrics • Light Source: 6x18W RGBWA UV LEDs. • Beam Angle: 25° • LED Lifespan: 50,000 hours • Color temperature: 2700-10000K adjustable (300K is a unit) •...
- Page 16 Effects • Dimming: 0-100%. • Strobe: 1-20 Hz. Control • Control mode: DMX512 Wireless( Default GZ wireless, Option SD), Master- Slave, Auto, IR, App • DMX Channels: 2 / 6 / 8 / 11 • Display: Display with 4-touch button control. •...
- Page 17 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com YouTube www.riukoe.com Facebook...
