RIUKOE SL-960 Manual

RIUKOE SL-960 Manual

960 leds rgb 3in1 strobe

Advertisement

Quick Links

960 LEDs RGB 3in1 Strobe
This product manual contains important information about the safe installation and use of
this projector. Please read and follow these instructions carefully and keep this manual in
a safe place for future reference.
User manual
Please read the instructions carefully before use
SL-960

Advertisement

loading
Need help?

Need help?

Do you have a question about the SL-960 and is the answer not in the manual?

Questions and answers

Summary of Contents for RIUKOE SL-960

  • Page 1 960 LEDs RGB 3in1 Strobe SL-960 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Information....................2 2. Connecting to a DMX control device ..............3 3. Configuring the fixture for DMX control ............... 4 4. Cleaning ........................ 5 5.DMX Channel ......................5 6. Control menu ......................7 7. Specification ......................8...
  • Page 3: Safety Information

    STATEMENT Thank you for choosing RIUKOE. The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction & problem owing to ignore the manual.
  • Page 4: Connecting To A Dmx Control Device

    WARNING! Take measures to prevent burns and fire. Install in a location that prevents accidental contact with the fixture. ⚫ Install only in a well-ventilated space. ⚫ Install only in accordance with applicable building codes. ⚫ Do not paint, cover or modify the fixture. ⚫...
  • Page 5: Configuring The Fixture For Dmx Control

    If using a cabled DMX system, connect the DMX in cable (with male 3-pin XLR plug) and out cable (with female 3-pin XLR plug) to the DMX data link. Terminate the DMX out cable of the last fixture in the data link. For outdoor installations, use only IP-rated XLR connectors suitable for outdoor use.
  • Page 6: Cleaning

    could then be set to a DMX address of 14. If two or more DMX fixtures of the same type have the same DMX address, then they will mimic each other’s behavior. Incorrect settings will result in unpredictable responses to the lighting controller.
  • Page 7 11-255 : Slow- Fast ;(1HZ-20HZ) effect; 11-255 : Each 36 Values with 1 color (Color 1-7); 5.3 Channels Mode 10CH 12CH 24CH Dimmer Dimmer Red 1 Red 1 Strobe Strobe Green 1 Green 1 Red 1 Blue 1 Blue 1 Green Green 1 Red 2...
  • Page 8: Control Menu

    CH24 Blue 8 6. Control menu Display: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions, ENTER To confirm the selected functions Set DMX Address Code Press "Menu" to "Set DMX Address",and press "ENTER" keys to enter into Show "Set DMX Address DMX Address:001",Press the "UP and DOWN"...
  • Page 9: Specification

    55 Auto Effects(SP01-- SP16: Auto Speed E000--E100 Effect Mode Slow to Fast) E000:Full Auto Effects Long press ENTER to confirm color SOU0-SOU3 Sound Control SOU0:Sound Control Effect SOU1: Sound control change color SOU2:Sound control DB1 SOU3:Sound control DB2 (SE1—99: Sound sensitivity slow - high) d000--d255:Total dimmer MANU Manual Mode...
  • Page 10 XLR sockets:3-pin XLR IN/OUT Display: LED display Electronic dimming:0-100% 12bit linear dimming Strobe:1-20 times/second strobe Control model:DMX512 and Master/slav,Sound active DMX Channels: 7CH/10CH/12Ch/24CH Dimension: 500 x 275 x140 mm Weight:7.5 kg...
  • Page 11 Add: No.619 Building C Jiahua Square Yingbin Avenue Guangzhou China +86-20-2904 6476 info@ricostagelight.com YouTube www.riukoe.com Facebook...
