200W COB Zoom PAR
This product manual contains important information about the safe
installation and use of this projector. Please read and follow these
instructions carefully and keep this manual in a safe place for future
reference.
User manual
Please read the instructions carefully before use
(Warm White)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RIUKOE Glow Z200
Summary of Contents for RIUKOE Glow Z200
- Page 1 200W COB Zoom PAR (Warm White) This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Information....................2 2. Configuring the fixture ..................3 3. DMX Connection ....................4 5. Cleaning ........................ 6 5. DMX Channel ....................... 6 6. Control menu ......................7 7. Specification ......................8... -
Page 3: Safety Information
STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 4: Avoid Personal Injury
WARNING! Take measures to prevent burns and fire. Install in a location that prevents accidental contact with the fixture. Install only in a well-ventilated space. Install only in accordance with applicable building codes. Do not paint, cover or modify the fixture. ... -
Page 5: Dmx Connection
Show "Set DMX Address DMX Address: 001", Press the "UP and DOWN" keys to amended Press "ENTER “keys to save and Exit, Press the "MENU" Keys does not save When display is d001(002..) or E001(002...), can be controlled by infrared remote control, the LED color and remote control button color will be the same 3. -
Page 6: Dmx Address Setting
signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 resistor connected between pins 2 and 3,which is then plugged into the output XLR socket of the last fixture in the chain. Please see illustrations below. Complimentary signal cable can transmits signals to 20 unit fixtures at most. -
Page 7: Cleaning
Press the MENU button up to when the DMX Address is showing on the display. Pressing the ENTER button and the display will blink. Use the UP/DOWN buttons to change the DMX address. Once the address has been selected, press the ENTER button to setup, to go back to the functions without any change press the MENU button again. -
Page 8: Control Menu
3 CHs 2CHs Dimmer 000-255 Dimmer, dark →bright (0-100%) Zoom 000-255 From small to big Strobe 000-255 Strobe from slow →fast 6. Control menu Display: MENU To select the programming functions To go forward in the selected functions DOWN To go backward in the selected functions ENTER To confirm the selected functions Set DMX Address Code... -
Page 9: Specification
2 Channel address code, (001-512) d001 B, C key to add and subtract address code values Strobe, (01-99) CP01 B, C key to modify jump to change speed SOUd Sound control Zoom, (001-255) t000 B and C modify pulse variable, velocity gradient 7. - Page 10 Bracket allows for multiple rigging or floor standing applications Weight & Size N.W. : 5kg G.W.: 5.5kg Packing Size: 290x290x520mm Approvals / Rating CE | IP20 ...
- Page 11 Add: Room 220, Building 3, Seiko Creative Park, Huadu District, Guangzhou +86-20-2904 6476 info@riukoe.com...
- Page 12 YouTube www.riukoe.com Facebook...
