ProLights SmartBat PlusNeo User Manual page 17

IR CONTROL
2 SETUP SCREEN
DIMMER
FIXTURE
RUN TIME
TRANSFER
CONFIGURATION
3 ADVANCED LED
FREQUENCY
RUN TIME
TUNGSTEN
EMULATION
FACTORY
RELOAD
4 INFORMATION DEVICE
TIME
TEMPERATURE
ON
OFF
BACKLIGHT ON
10S
20S
30S
FLIP DISPLAY YES
NO
KEY LOCK
YES
NO
°C
TEMPERATURE
UNIT
°F
DIMMER LINEAR
CURVE
S-CURVE
SQUARE LAW
INVERSE
SQUARE LAW
AUTO
DIMMER
SPEED
FAST
MEDIUM
SLOW
DMX HOLD
FAULT
BLACKOUT
STAND
ALONE
EMERGENCY
STATUS LED ON
OFF
AUTO
3H
6H
8H
12H
18H
WITHOUT DMX
ADDRESS
WITH DMX
ADDRESS
600HZ
1200HZ
2000HZ
4000HZ
6000HZ
25KHZ
3H
6H
8H
12H
18H
ON
OFF
ON
OFF
FIXTURE HOURS TOTAL
PARTIAL
CURRENT HOURS <99999H>
SOURCE
<99999H>
HOURS
POWER
<300>
ON CYCLE
MAINTENANCE
ELAPSED TIME
TIME
ALERT PERIOD
PROLIGHTS - Smart BatPlusNeo
Enable/Disable the IR Controller.
Select the timing after that display will
switch automatically off when unactive.
Allows you to rotate the display by 180°.
Lock the buttons on the control panel by
a password.
Press following combinations (password)
in order to access to the user menu : UP,
DOWN, UP, DOWN, ENTER.
Allows you to choose temperature unit
showed in home screen.
Choose dimmer curve.
Set Dimmer Speed.
This parameter defines interpolation of
DMX Changes for main functions.
Off turns off interpolation
Define the behaviour of fixture in case of
DMX signal lost.
Default value is STAND ALONE (if no
standalone is selected, HOLD)
Define the behaviour of LED on the fixture.
Select Run Time of the fixture.
3H: Max power available 53W.
6H: Max power available 30W.
8H: Max power available 26W.
12H: Max power available 18W.
18H: Max power available 13W.
Run Time is calculated using fixture RGBW
@ Full.
To transfer the same menu settings of one
fixtures to all the other in the daisy chain,
including or not the dmx address.
Select PWM frequency.
Select Run Time of the fixture.
3H: Max power available 53W.
6H: Max power available 30W.
8H: Max power available 26W.
12H: Max power available 18W.
18H: Max power available 13W.
Run Time is calculated using fixture RGBW
@ Full with Calibration on.
Enable/Disable Tungsten emulation.
Reload fixture with Standard settings.
<99999H> Total hour the fixture has been ON
Total hours the fixture has been ON since
<99999H>
the last reset of this
Current session hours
LED PCBs hours
How many times the fixture has been pow-
ered on
How many hours elapsed from the last
<99H>
maintenance/reset
Fixture will show maintenance allert after
10 - 750
this amount of time (Default 500H)
15
