4 - CONNECTION TO THE MAINS SUPPLY
WARNING: For protection from electric shock, the fixture must be earthed!
The product is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz
AC power source from 100-240 Volts.
If you need to install a power plug on the power cable to allow connection to power outlets, install a
grounding-type (earthed) plug, following the plug manufacturer's instructions. If you have any doubts
about proper installation, consult a qualified electrician.
The max power consumption when connected to the SBPNEOPOWER charging accessory is 75W,
while the max power consumption when connected to the SMARTBATPNEOPACK is 570W.
Core (EU)
Brown
Blue
Yellow+green
5 - START UP
CHARGING AND POWERING THE PRODUCT
To charge and operate the product:
• Check that the product and its charging base are installed and secured as indicated in the Safety
Information, and that personal safety will not be put at risk when the fixture lights up.
• Charging Operation:
1. Connect the power connector to the charging base's input socket (100-240 VAC-50/60 Hz)
2. Place the product on its charging base to initiate charging
3. Allow the product to fully charge before first use
• Regular operation:
1. The product cannot be used while on the charging base or being charged, but can only be used
when removed from the charging base and once charged
2. When battery level is low, return the product to its charging base
3. The product is ready for operation and can be controlled through the available input signals on
board
4. To completely power down the product, use the power switch located on the unit
Note: The charging base must remain connected to power for charging functionality. The product itself
operates independently on battery power when removed from the base.
Core (US)
Black
White
Green
PROLIGHTS - Smart BatPlusNeo
Connection Plug terminal marking
Live
Neutral
Earth
L
N
