- Page 1 User Manual PT-SW-HD41-48G User Manual 8K HDMI™ 4x1 Switcher with Audio De-embedding Model PT-SW-HD41-48G Designed in Germany Version V1.0 © 2024 PureLink GmbH All rights reserved.
-
Page 2: Fcc Statement
User Manual PT-SW-HD41-48G Preface Read this user manual carefully before using this product. Pictures shown in this manual are for reference only. Different model layouts and specifications are subject to the physical product. This manual is for operation instructions only, not for any maintenance usage. - Page 3 Directives 1907/2006/EU und 2011/65/EU. EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive) PureLink GmbH hereby declares that this product PureTools PT-SW-HD41-48G complies with Directives 2014/30/EU and 2014/35/EU. The full text of the EU Declaration of Conformity is available at the following Internet address:...
- Page 4 User Manual PT-SW-HD41-48G SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. ⚫ Unpack the equipment carefully and save the original box and packing material for possible future shipment.
-
Page 5: Table Of Contents
User Manual PT-SW-HD41-48G Content 1. Product Introduction....................2 1.1 Introduction......................2 1.2 Features........................2 1.3 Package List......................3 2. Panel Description.......................3 3. IR Remote........................7 3.1 IR Receiver......................7 4. Specification.......................8 5. API Commands......................10 6. System Diagram.......................13 7. Firmware Upgrade....................14 8. After-Sales Service....................16 Asking for Assistance....................17... -
Page 6: Product Introduction
User Manual PT-SW-HD41-48G 1. Product Introduction 1.1 Introduction This 8K HDMI 4×1 Switcher allows you to connect 4 HDMI sources to 1 TV to output. The video resolutions is up to 8K@60Hz 4:2:0 12bit or 4K@120Hz 4:4:4 12bit. Audio de-embedding is supported for an AV receiver or a soundbar, in audio format such as Dolby Atmos, DTS-HD. -
Page 7: Package List
User Manual PT-SW-HD41-48G 1.3 Package List ⚫ 1× 8K HDMI 4x1 Switcher with audio de-embedding ⚫ 1× 5V/2A Multinational Locking Power Supply with USB Plug ⚫ 1× EU Conversion Plug ⚫ 1× IR Remote ⚫ 1× IR Receiver Cable (1.5m) ⚫... - Page 8 User Manual PT-SW-HD41-48G Name Function Description When the device is powered on, the power LED is green; Power LED When the device is standby, the power LED is red. INPUT LED When IN 1/2/3/4 is selected as the input channel, the (1~4) corresponding green LED is on.
- Page 9 User Manual PT-SW-HD41-48G Name Function Description (Continued) [DIP]=11011: FRL10G_8K_HDR, 2.0CH [DIP]=11010: FRL10G_8K_HDR, 5.1CH [DIP]=11001: FRL10G_8K_HDR, 7.1CH [DIP]=11000: 5K60(444)_HDR, 2.0CH [DIP]=10111: 5K60(444)_HDR, 5.1CH [DIP]=10110: 5K60(444)_HDR, 7.1CH [DIP]=10101: 4K144(444), 2.0CH [DIP]=10100: 4K120(444), 2.0CH [DIP]=10011: 4K120(444), 5.1CH [DIP]=10010: 4K120(444), 7.1CH [DIP]=10001: 4K120(420)_HDR, 2.0CH [DIP]=10000: 4K120(420)_HDR, 5.1CH...
- Page 10 User Manual PT-SW-HD41-48G Name Function Description OUT2 port HDMI audio output port, connected to an audio device such (AUDIO ONLY ) as soundbar or amplifier. Optical fiber audio output port, connected to an audio OPTICAL output device such amplifier. Analog audio output port, connected to an audio output device such as speaker.
- Page 11 User Manual PT-SW-HD41-48G 1. TMDS detection • If an IN port is connected, it will switch to the port when the TMDS/FRL signal is detected, and the corresponding LED will light up. • If the current input port is disconnected or in standby mode, and no signal is detected, it will switch to the next active port automatically.
-
Page 12: Ir Remote
User Manual PT-SW-HD41-48G 3. IR Remote Press this button to power on the switcher or set it to standby mode. Auto eARC eARC: Press this button to enable or disable the eARC function. Auto: Press this button to enable or disable the auto switching function. -
Page 13: Specification
User Manual PT-SW-HD41-48G 4. Specification Technical HDMI Compliance HDMI 2.1 HDCP Compliance HDCP 2.3 Video Bandwidth 48Gbps Video Resolution Up to 8K@60Hz 4:2:0 12bit, 4K@120Hz 4:4:4 12bit Color Depth 8/10/12-bit Color Space RGB, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0 HDR, HDR10, HDR10+, Dolby Vision, HLG... - Page 14 User Manual PT-SW-HD41-48G 1× SERVICE [USB type C, upgrade port] Control 1× RS-232 [3pin-3.5mm phoenix connector] Mechanical Housing Metal Enclosure Color Black Dimensions 200mm [W] × 84mm [D] × 20mm [H] Weight 430g Power Supply DC 5V/2A Power 3.15W (Max)
-
Page 15: Api Commands
5. API Commands The product also supports RS-232 command control. Connect the RS-232 port of the PT-SW-HD41-48G to the appropriate cable and your control device. Then open a Serial Command tool on PC to send ASCII commands to control the product. - Page 16 User Manual PT-SW-HD41-48G Command Function Example Feedback Default System Setting Get Firmware r fw version! r fw version! MCU FW version x.xx.xx version power on Power on/off the device, z=0~1 power z! power 1! System Initializing... (z=0 power off, Initialization Finished! z=1 power on) MCU FW version x.xx.xx...
- Page 17 User Manual PT-SW-HD41-48G Command Function Example Feedback Default Input/Output Setting r auto r auto Get auto switch feature auto switch: on switch! switch! set auto switch auto switch s auto mode(x=0~1) s auto auto switch mode: mode: TMDS mode x! 0.TMDS mode...
-
Page 18: System Diagram
User Manual PT-SW-HD41-48G 6. System Diagram Usage Precaution ⚫ Make sure all components and accessories included before installation. ⚫ System should be installed in a clean environment with proper temperature and humidity. ⚫ All of the power switches, plugs, sockets, and power cords should be insulated and safe. -
Page 19: Firmware Upgrade
User Manual PT-SW-HD41-48G 7. Firmware Upgrade Please follow the steps as below to upgrade firmware by the Service port on the front panel: 1. Prepare the PC tool (.exe) and the latest upgrade file (.bin) on PC. Rename the upgrade file as “MCU_MAIN_PT-SW-HD41-48G_Vxx.xx.xx.bin” . - Page 20 User Manual PT-SW-HD41-48G Search 5. Click "Open" to select the upgrade file MCU_Main_PT-SW-HD41-48G_ Vxx.xx.xx.bin, then click "Upgrade". 6. When the upgrade is completed, Search it will pop up "Upgrade successful!". If the firmware updating is fail, the MCU_Main_PT-SP-HD name of upgrade file (.bin) should be confirmed, and then follow the above steps to update again.
-
Page 21: After-Sales Service
User Manual PT-SW-HD41-48G 8. After-Sales Service If there appear some problems when running the product, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: This product will be free from defects in materials and workmanship for three years (The purchase invoice shall prevail). -
Page 22: Asking For Assistance
User Manual PT-SW-HD41-48G Asking for Assistance Technical Support: Phone: +49 5971 800299 - 0 Fax: +49 5971 800299 – 99 Technical Support Hours: 8:30 AM to 5:00 PM Monday thru Thursday 8:30 AM to 4:00 PM Friday Write to: PureLink GmbH Von-Liebig-Straße 10...
