Brush Roll and Belt Replacement
**You will need a Phillips head screwdriver for this task**
1. Place the vacuum in a suitable
workspace that allows you to access
the underside of the brush head.
Have the handle in the Normal
Cleaning Position. Never perform
this work if the vacuum is plugged in
or turned on!
2. Remove the five screws that secure the brush cover plate to the unit. Set the screws and
cover plate to the side.
20
