Clearance Requirements

A minimum clearance of at least 6 inches (150 mm) is suggested on the top and both
sides of the product for service.
See Appendix B: Dimensions

Electrical Requirements

The product models have the following electrical requirements.
Catalog Number
533xx00, 534xx00
533xx10, 30, 40, 50, 70
534xx10, 30, 40, 50, 70
535xx00, 536xx00
535xx10, 30, 40, 50, 70
536xx10, 30, 40, 50, 70
538xx00
538xx10, 30, 40, 50, 70
1 Does not include amperage draw from device connected to the provided internal outlet(s).
2 Electrical Requirements, 'V' = VAC (Voltage with alternating current), 'A' = Amperes
A dedicated outlet with an appropriate circuit breaker should be located as close as
possible to the product, but no greater than 10 feet (3 m). Consult your local electrical
codes for properly rated circuit breakers. For safe operation the dedicated outlet must
provide a protective earthing ground connection to the product.
On 115V models, all internal electrical outlets are protected by a ground fault interrupter
circuit (GFCI). Labconco does NOT recommend connecting the product's power cord
into a GFCI outlet. GFCI outlets can nuisance trip, resulting in complete removal of
power to the product. Such a scenario would result in complete loss of product
protection.
for overall product dimensions.
Typical Operating
1
Current (Amps)
4.0 A
2.5 A
5.5 A
3.2 A
7.0 A
4.0 A
10
Electrical Circuit Requirements
115 V ±10%, 60 Hz, 12 A
230 V ±10%, 50/60 Hz, 6 A
115 V ±10%, 60 Hz, 16 A
230 V ±10%, 50/60 Hz, 8 A
115 V ±10%, 60 Hz, 16 A
230 V ±10%, 50/60 Hz, 8 A
2
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
1 Phase
