Fit The Back-Up Battery; Close The Control Panel; Apply Power - EMS SmartCell Installation Manual

Fit the back-up battery

• Fit the control panel battery, observing the correct polarity.

Close the control panel

• Reassemble the control panel.
1.

Apply power

• Apply power to the control panel.
• The green power LED will
illuminate.
• All other LEDs should be
extinguished.
• The screen should also display
'System Normal'.
