Back-up 4G connection

SKIP THIS STEP IF USING SINGLE PATH COMMUNICATION ONLY VIA ETHERNET
CONNECTION.
• The approved T-bar aerial must be used
and connected to the ANT1 connection.
• Mount the aerial away
from electrical conduits
/ equipment & wireless
products (including the
control panel).
• Do not coil, crush or
shorten the aerial's
cable.
Refer to the SmartCell installation guide (TSD120) for cable entry
points.
