Evaluation Board User Guide
Reference Designator
R12
R16, R64, R65,
R20
R39 R49, R50,
R40
R41
R44, R45,
R66
U1
U2, U3, U10, U13
U4
U5
U6
U7
U8
U9
U11
U12
VSUPPLY
Y1 1
Y2
Do not insert.
1

RELATED LINKS

ADF4108 Product Page, PLL Frequency Synthesizer
ADP150AUJZ Product Page, Ultralow Noise, 150 mA CMOS Linear Regulator
OP184 Product Page, Single-Supply Rail-to-Rail Input/Output Operational Amplifier
ADP3334 Product Page, High Accuracy Low I
ADP7104ARDZ Product Page, 20 V, 500 mA, Low Noise, CMOS LDO
Part Description
Resistor, 0603, 49.9 Ω
Resistor, 0402, 0 Ω
Resistor, 0603, 10 Ω
Resistor, 0603, 2.2 kΩ
Resistor, 0603, 140 kΩ
Resistor, 0603, 78.7 kΩ
Resistor, 0603, 100 kΩ
Resistor, 0402, 0.33 Ω
ADF4108, PLL frequency synthesizer
ADP150AUJZ-3.0, 3.0 V linear regulator
OP184, single op amp
ADP3334, adjustable LDO regulator
USB microcontroller
64 K, I2C Serial EEPROM
ADP7104ARDZ-5.0, linear regulator
Power divider, 6 dB, 1 W, 0603 SMD
VCO, dual output and divide by 2 prescaler
Attenuator, 3 dB, 50 Ω, 0805 SMD
Red 4 mm banana socket
TX-500 temperature compensated crystal oscillator, 100.0 MHz
SMD crystal, 24.0 MHz
, 500 mA anyCAP® Adjustable Low Dropout Regulator
Q
Rev. A | Page 19 of 20
UG-160
