SECTION X - FAULT CODES LIST
Your KwiKool System incorporates a self-diagnostic system that sounds an audible alarm,
stops the system and displays a fault code (shown below) to indicate the nature of the prob-
lem on the display panel. See the troubleshooting guide later in this manual for further infor-
mation.
A1 Customer installed input
A2 Customer installed input
CP
Condensate pump fault
LP Low Pressure (Freon) detected
CF
Condensate bottle full
HP
High Pressure detected
FL Run time for filter elapsed. Alert only –
No system shut down
FP
Evaporator Coil Frozen
FS
Freezing detected
DC Deicer in cool
32
Temperature Sensor malfunction
60
Ambient room temperature is under 60F
99 Ambient room temperature is over 99F
Alarm Codes Table
Optional. Normally Closed.
Optional. Normally Open
Standard
Standard
Standard
Standard
Standard
Standard
Optional
Optional
Standard
Standard
Standard
