KwiKool KPHP Series Operation Manual page 13

BUTTON
Settings
Settings
FAN
FAN
1. ON/OFF button - Pressing this button on your control panel engages or shuts down
your KPHP system. All settings selected are stored in the microprocessor board even
if the power is lost including the ON/OFF selection. Refer to Section IX, Trouble-
shooting Guide in this manual if your unit indicates an alarm after selecting ON.
2. MODE button - Depressing the MODE button selects your choice of operations.
COOL, for cooling with compressor operation. Cool will flash when the compres-
•
sor is running. Cool will not flash when the room temperature is equal to or lower
than the set temperature or the system is timing out.
HEAT, for heating with compressor operation. Heat will flash when the compres-
•
sor is running. Heat will not flash when the room temperature is equal to or higher
than the set temperature or the system is timing out.
HEAT/COOL mode when conditioning is required in applications with changing
•
load requirements. The system automatically selects the mode based on the set
point and flashes the current operating function unless the set point is satisfied or
the system is timing out.
FAN, for Manual (Cool mode only) or Auto Fan function.
•
Operators of KwiKool Systems will not have control
of the Supply Air fan when in HEAT Mode. The
Supply Air is controlled by a pressure switch to op-
timize the systems operation and this switch over-
rides the microprocessor selection. It is normal for
the Supply Air fan to delay in starting and to cycle
on and off in Heat mode.
3. Up (+) and Down (-) Arrow Buttons - Raises or lowers the desired set temperature.
When changing the set point, pressing the + or – key, the word SET will appear on
the display and the current set point flashes ON and OFF. The value of the set point
is changed one degree each time the + or – is pressed. The adjusted set point flash-
es on and off 12 times after the last change and then returns to display the room
temperature.
OPERATING IN-
STRUCTIONS
Short Press
Long Press (5 seconds)
Short Press
Short Press
NOTE
13
FUNCTION
Change to F or C for Tempera-
ture Display
Enter User Settings
Auto Fan ON or OFF
Go to Previous Parameter, in
Tech and User Settings List
