Page 1
User Manual D093-P TACHOMETER MONITOR ENGINE SPEED AND RUNNING HOURS WITH ALARM OUTPUT Signal input: pulse, Namur or coil sensor signal Signal output: one RPM and running hours alarm Options: backlight D-Series - Panel mounted indicators More info: www.fluidwell.com/dseries...
● incorrect functioning of the unit or connected instruments. A note informs you of important information. WARRANTY AND TECHNICAL SUPPORT For warranty and technical support on your Fluidwell products, visit our internet site www.fluidwell.com or contact us at support@fluidwell.com. MODEL REFERENCE Hardware version: 03.04.xx...
D093-P User Manual SAFETY PERSONAL SAFETY ● Risk of electric shock: Only open the unit if all leads are free of potential electrical energy. ● Immediately inform the person responsible for the installation if you disagree with the safety precautions or if you detect errors or danger.
Fig. 1: The D093 This manual describes the daily use, configuration and installation of the D093-P with pulse input from a tachometer and its available options. The following figure shows the D093-P used in a typical application.
● One tachometer with a passive or active pulse, NAMUR or coil signal output ● Several options are available for powering the sensor. Output ● An external device such as an alarm or a switch can be connected to the D093-P. ● Several driving options are available, depending on the ordered Type. Options ●...
Section 2: Safety [»5] INTRODUCTION This chapter describes the daily use and operation of the D093-P. For this, the D-Series is equipped with a control panel that provides the operator with various functions, information and operating modes. 4.1.1...
4.2.2 BACKLIGHT (TYPE ZB) The D093-P with Type ZB is equipped with a backlight to illuminate the display for improved readability. The backlight can be turned on or off, and its intensity can be set in the SETUP- menu. DISPLAYED INFORMATION 4.3.1...
User Manual D093-P SETTING ALARM THRESHOLDS Setting the threshold values might not be available in Operator Mode. This is set in SETUP 4.4: DISPLAY > SET ALARM The D093 can accommodate three alarms: ● Low engine speed alarm ● High engine speed alarm ●...
INTRODUCTION This chapter describes how technicians can use configuration settings to configure the D-Series for optimal functionality. Configuration of the D093-P can be done in SETUP mode, using the front keys. CONFIGURING USING SETUP MODE For an overview of Operating modes, see Section 4.1.1: Operating modes [»8]...
User Manual D093-P 5.2.3 CHANGING CONFIGURATION SETTINGS A menu item either contains a value (a number with optionally a decimal point and sign, e.g. -123.45) or a selection list (e.g. L – m - USGAL). After a menu item is selected in the SETUP menu, a new value can be programmed by performing the following steps.
255. The lower the number of pulses, the higher the power consumption of ● the D093-P will be (important for battery powered applications). For low frequency applications (below 10 Hz), do not program more ● than 10 pulses, to prevent a very slow update time. For high‑frequency applications (above 1 kHz), enter a value of 100...
D093-P User Manual ALARM RPM ZERO When the sensor signal is zero, the monitoring can be ignored or disabled. Select the desired action when the signal becomes zero: Default: the alarm output is switched, and the alarm is indicated on ●...
User Manual D093-P DISPLAY BACKLIGHT ALARM If the D093-P generates an alarm, the backlight can be set to change to red. The following settings are available: OFF: during an alarm the color is white. ● ON: during an alarm the color is red.
5.4.6 MENU 6: SENSOR SENSOR SIGNAL Selects the type of input sensor pickup / signal. The D093-P can process several types of input signal. The settings with LP are used to apply a built-in low-pass filter. TACHOMETER SELECTION CHARACTERISTICS TYPE OF SIGNAL...
Personnel must read and understand this Operating Manual before carrying out its instructions. ● The D093-P may only be operated by personnel who are authorized and trained by the operator of the facility. All instructions in this manual are to be observed.
User Manual HANDLING THE D093-P ENCLOSURE 6.2.1 IDENTIFICATION Identification label To identify your D093-P device, all enclosures have a weatherproof identification label placed at the backside of the product. Fig. 8: Example of D0-Series identification label Serial number and year of production...
The installation must comply with (inter)national requirements and local ordinances. Type PM: HIGH VOLTAGE 230V, combined with Type OR up to 400 V Be sure that all the leads to the terminals are disconnected from the D093-P when the internal plastic protection cover has been removed.
● The wire screens shall be terminated at one side to prevent wire loops. Inside of the D093-P, the different common ground terminals are connected to each other. It is advised, as illustrated, to terminate the wire screens in the vicinity of the sensor and to insulate the wire screen with a shrink tube at the D093-P side.
C22.2 No. 61010-1 / UL 61010-1 / EN-IEC 61010-1. The D093-P can be powered from an external power supply. For Type PX or PD, an optional internal power supply is also available in the form of a lithium battery (Type PB). When both external and internal power supplies are available, the internal power supply is interrupted and will act as a backup supply.
In the D093-P terminal P0 is internally connected to Common Ground (indicated with the symbol ┴). In the D093-P Type PM and/or OR, terminal P0 is also internally connected to the metal front panel. When a Protective Earth lead is connected to terminal P0, a separate PE connection of the front panel is not needed (see Section 6.4.2: Protective earth (PE) connections [»21]...
For safety reasons, connect mains power only after all other wiring is completed. To power the D093-P a 24 V AC (Type PD) or 115-230 V AC (mains) (Type PM) power supply can be applied. See the following drawings for connecting the various AC power supplies.
TERMINALS S1-S2: TACHOMETER INPUT AND S3-S4: SENSOR POWER SUPPLY Three basic types of tachometer signals can be connected to the D093-P: pulse, active pulse or coil. The screen of the signal wire can be connected to the common ground terminal (see Section 6.4.3:...
Page 26
Terminals S1-S2 NPN signal input The D093-P is suitable for use with tachometers with a PNP output signal. Terminal S3 offers 3 V DC which has to be switched by the sensor to terminal S2 (SIGNAL). For reliable pulse detection, the pulse amplitude has to go above 1.2 V.
Page 27
D093-P User Manual Reed switch The D093-P is suitable for use with tachometers with a reed switch. To avoid pulse bounce from the switch, it is advised to activate a low pass filter by selecting REED LP (see SETUP 6.1: SENSOR >...
TERMINALS P3-P4: DC POWER SUPPLY - TYPE PX, PD AND TYPE ZB To power the D093-P an 8-30 V DC (Type PX) or 24 V DC (Type PD) power supply can be applied. With Type ZB, apply 20-30 V DC. P3 is connected to common ground, connect + to P4.
Personnel must read and understand this Operating Manual before carrying out its instructions. ● The D093-P may only be operated by personnel who are authorized and trained by the operator of the facility. All instructions in this manual are to be observed.
à plus de 100°C (212°F) ou exposer à l'eau. Primary Lithium Battery - Only replace with Fluidwell recommended battery pack! Pile primaire au lithium - Remplacer uniquement par une pile recommandé par Fluidwell! Fig. 27: Marking battery type PB: Safe area StdLiBAT-021 (SPB02) 7.3.2...
D093-P User Manual 4. Place the back side cover back on the product and secure it with the four screws. 5. Check that the battery is installed properly by checking that the screen has come on. 6. Reconnect the unplugged field connectors.
User Manual D093-P APPENDIX A - TECHNICAL SPECIFICATION GENERAL DISPLAY Type High intensity reflective numeric and alphanumeric LCD, UV-resistant Digits 7 with height 17mm (0.67”) and 11 with height 8mm (0.31”). Various symbols and measuring units. Dimensions 90 x 40 mm (3.5” x 1.6”)
D093-P User Manual DIRECTIVES AND STANDARDS EN/BS 61000-6-2 EN/BS 61000-6-3 EN/BS 61326-1 Low Voltage EN/BS 61010-1 RoHS EN/BS 50581 EN/BS IEC 63000 IP & NEMA EN/BS 60529 NEMA 250 Note See the applicable Declaration of Conformity or product certificate for specific revisions and publication dates of applicable standards.
Page 34
User Manual D093-P ALARM VALUES Digits 7 digits. Decimals According to settings for RPM Type of alarm Low and/or high engine speed alarm, and/or running hours alarm. Includes configurable delay time and alarm output. Page 34 FW_D093-P_M_v0501-02_EN...
APPENDIX B - TROUBLESHOOTING Table 1 lists and describes how to troubleshoot problems that can occur when installing or operating the D093-P. Table 2 lists internal alarm codes and conditions signaled by a blinking ALARM flag on the display ). Press the SELECT key several times to display the 4-digit error code shown in Table 2.
EU De cla tio n of Conformi Fluidwell 0 D ‒Series indicators he , February 2022 We, Fluidwell BV, declare under our s e ol respons ibility that the 0 D ‒Series indicators are de igne d and will operate conform the following applicable European...
Page 37
D093-P User Manual LIST OF CONFIGURATION SETTINGS SETTING DEFAULT DATE: DATE: HOURS CLEAR push clear DECIMALS FREQ MIN DECIMALS K-FACTOR DECIMALS K-FACTOR CALCULATION CUT-OFF ALARM ALARM enable RPM ZERO default ALARM LOW ALARM HIGH DELAY ALARM LOW DELAY ALARM HIGH...
Page 38
User Manual D093-P NOTES Page 38 FW_D093-P_M_v0501-02_EN...
Page 39
D093-P User Manual FW_D093-P_M_v0501-02_EN Page 39...
