Summary of Contents for Scotchman SUP-800-NF

  • Page 1 Instructions Manual...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS _ >>> 1. INTRODUCTION. 1.1. LEGISLATION APPLICABLE TO THE PLANNING AND CONSTRUCTION OF THE MACHINE. 2. GENERAL MACHINE DATA. 2.1. MACHINE IDENTIFICATION DATA. 2.2. TECHNICAL DATA. 2.3. ELECTRICAL DATA. 2.4. NOISE LEVEL. 3. INDICATIONS REGARDING TRANSPORT AND STORAGE. 4.
  • Page 3: General Information

    This instruction manual has been made in compliance with the requirements of the Legislation according to the Machine directive 2006/42/CEE and its subsequent amendments. The instruction manual represents an integral part of the machine. It must be consulted before, during and after the machine is put into service, as well as whenever it is considered necessary, thereby respecting the content in each and every one of its parts.
  • Page 4: Machine Identification Data

    2.1. Machine identification data. SUP-800 NF ..………………………………………………. Model: …………………………………… Serial number: ………………………………… Manufacturing year: ✓ NOTE In order to request spare parts, whether covered by the warranty or not, always indicate the model and serial number of the machine, as well as the name of the part and the code that appear in the last chapter of the parts exploded views.
  • Page 5: Electrical Data

    2.4. Cutting capacity. 90º 45º 22.5º 2.5. Electrical data.
  • Page 6: Noise Level

    Power supply Motor power Total consumption 220 V Three phase 7.5 kW / 10 HP 22 A 380 V Three phase 7.5 kW / 10 HP 15 A 2.6. Noise level. At a distance of 60 cm RUNNING OFF-LOAD Leq 80 Db (A) MACHINING A 70x50 PROFILE Leq 120 Db (A) ...
  • Page 7: Regulation Of Pressure Regulators

    4.1. Instructions for anchoring. Ensure that the machine has not suffered any damage during transport by making an initial visual inspection. If damage is observed, advise the manufacturer immediately. The machine must be installed on a firm and level surface in order to thus reduce vibrations during operation and so that the machine operates within the parameters established by the manufacturer.
  • Page 8 To place the machine to 22,5 º towards the left side and to fix with the automatic anchorage, there slackens the disc (4) with the bar and the fixed key sent with the machine. To do it with the bar and the fixed key sent with the machine.
  • Page 9: Lubetool Micro-Lubrication

    4.4. LUBETOOL MICRO-LUBRICATION HOW TO ADJUST THE FREQUENCY GENERATOR WITH AIR AT 6 BAR 66 IMPULSOS xMINUTO 37 IMPULSOS xMINUTO 21 IMPULSOS xMINUTO 13 IMPULSOS xMINUTO STROKES EVERY MINUTE STROKES EVERY MINUTE STROKES EVERY MINUTE STROKES EVERY MINUTE 10 IMPULSOS xMINUTO 6 IMPULSOS xMINUTO 4 IMPULSOS xMINUTO 3 IMPULSOS xMINUTO...
  • Page 10: Instructions For Use

    5. INSTRUCTIONS FOR USE. >>> 5.1. Proper and improper use. This is a semiautomatic cut-off machine especially designed for cutting aluminium profiles. The use of the machine for cutting other materials is hereby prohibited. Such use may cause damage to the machine and put the health and safety of the worker at risk. DANGER We are not responsible for any possible accident caused by the failure to comply with the aforementioned.
  • Page 11: Instructions For The Adjustment Of The Digital Degrees

    5.3. Instructions for the adjustment of the digital degrees. ➢ For placed to the zero of the book-keeper of degrees, pulsate of simultaneous form (F+Set). ➢ To change the way of reading of incremental to absolute, to touch (Inc/Abs). ➢ Change of the book-keeper parameters, contact to the manufacturer of the machine.
  • Page 12: Recomendations And Maintenance

    6. RECOMMENDATIONS AND MAINTENANCE. >>> 6.1. Type and frequency of inspections. The operator’s knowledge of the machine is one of the best ways of daily control of any possible problem. If any failure is detected, work must be stopped and qualified personnel must be informed immediately.
  • Page 13: Manufecturer Recomendations

    • All repairs shall be made exclusively by qualified personnel, thereby always using original replacement parts. If not, the machine may be damaged or the user may be injured. 6.3. Manufacturer recommendations.  In the event that the machine is broken down or the saw blades must be replaced, place a padlock on the protection switch and place the keys under the care of qualified personnel.
  • Page 14: General Schematic

    7.1. General schematic. Nº DESCRIPTION CODE Nº DESCRIPTION CODE Ø55 PNEUMATIC HOLD-DOWN CLAMP 2008005212 LEFT DOOR HORIZONTAL CLAMPS ØEXT 40 N03PTI4050 PRESSURE REGULATOR N000000030 ANGLE LOCK 2040000482 PROTECTIVE SHIELD SUPPORT ADVANCE REGULATOR PROTECTIVE SHIELD BLOW AIR DUSTER SHIELD END-OF-TRAVEL STOP E00000BD25 2- POSITION SELECTOR TURRET...
  • Page 15: Power Circuit

    7.2. Power circuit. 400V 50Hz 380V --> 14.5A 220V -->25.1A I> I> I> 50VA (380-220)V --> 24V LED TENSIÓN DELTA V1 W1 7.5 Kw III 400V 7.5 Kw III 220V 50/60 Hz 7A / 12A Nº DESCRIPTION CODE Nº DESCRIPTION CODE MAIN SWITCH 10A E000000004...
  • Page 17 Stop - Start Blade º DESCRIPTION CODE Nº DESCRIPTION CODE 2-POSITION SELECTOR E000000G71 HIGH + LOW PRESSURE NEUMATIC N000000069 SHIELD END-OF-TRAVEL STOP E00000BD25 TKC9 CONTACTOR 24V 50/60 Hz E000000034 END-OF- TRAVEL M-12 E000000015 MAGNETIC SENSOR MAGI 6,2 ECNKT50RQD SAW BLADE , ON-OFF E000000G75 RELAY BORNA 6MM + BASE 24VAC/DC E000000095...
  • Page 18: Pneumatic Schematic

    7.3. Pneumatic schematic. LINEA BLADE AUTOMATIC SHIELD CLAMPS Nº DESCRIPTION CODE Nº DESCRIPTION CODE 00 LINE -------------------- UNI DIRECTIONAL VALVE 2/2 1/8” N000000015 01 FILTER+REG+SHUT-OFF VALVE N00000A170 VERTICAL CLAMPS Ø55 2008005212 02 5/2 WAYS BIEST. ELECTROVALVE N00000AB34 BLOW AIR DUSTER N000000010 03 HIGH+LOW PRESSURE NEUMATIC N000000069...
  • Page 19: Exploded View Cast Iron Table And Disc Assembly

    7.4. Exploded view cast iron table and disc assembly. DESCRIPTION CODE DESCRIPTION CODE Nº Nº TD79910616 ------------------- DIN 7991 M6x16 SCREW POST 2180000522 N000008059 BLADE GROOVE ISO 80 CYL. YOKE 2352000171 N000008059 DEGREES TURN LEVER ISO 80 CYL. YOKE B0000000H2 TD47100I16 HANDLE TRISTAR M10 16 STOP COLLAR...
  • Page 20: Exploded View Rocker Assembly

    7.5. Exploded view rocker assembly. Nº DESCRIPTION CODE Nº DESCRIPTION CODE DIN 934 M30 NUT TD93400030 CONNECTING ROD PIN 2040000072 Ø116 BLADE WASHER 2180000042 Ø45x7 AVELL. M12 WASHER 216000A452 WIDIA BLADE Ø800xØ80x5 205DW80050 DIN 7991 M12x25 SCREW TD79911225 DIN 912 M8x12 SCREW TD91208012 CAST IRON ROCKER TL-800 2180000032...
  • Page 21: Exploded View Protective Shield

    º DESCRIPTION CODE Nº DESCRIPTION CODE TURRET SUPPLEMENT M12x70 LEVER B0000P1270 IRON TURRET P2180000026 ALUMINIUM ROD. HOR. CLAMP 204000A502 DIN 912 M12x70 SCREW TD91212070 FLAT NUT M12 FLAT NUT M12 M12x70 LEVER B0000P1270 M12x70 LEVER B0000P1270 HORIZONTAL CLAMP Ø40x450 N03PTI4050 DIN 912 M6x16 SCREW TD91206016 SUPPORT OF DRAWER.
  • Page 22 Nº DESCRIPTION CODE Nº DESCRIPTION CODE ISO-7380 M6x10 SCREW TI73800610 CONNECTING ROD PIN P. SHIELD ----------------- LEFT PROTECTIVE SHIELD ----------------- Ø40x6 AVELL. M8 WASHER 204000A401 DIN-934 M6 NUT TD93400006 DIN 7991 M8x40 SCREW TD79910840 M8 HANDLE B000000L17 PROTECTIVE SHIELD SUPPORT 1329x1005x3 METHECRYLITE 2180000142 ISO-7380 M8x10 SCREW...
  • Page 23: Exploded View Of Protective Shield Of Cylinder Set

    7.8. Exploded view of protective shield of cylinder set (x2). Nº DESCRIPCIÓN CÓDIGO Nº DESCRIPCIÓN CÓDIGO DIN 471 Ø12 RING ------------------ ISO 40x250 CYLINDER CN00040250 BOLT ISO 40 ------------------ ISO8675 M10 NUT ------------------- DIN 934 M6 NUT TD93400006 DIN 931 M12x35 SCREW TD93112035 ISO 7380 M6x20 SCREW TI73800620...
