- Page 1 Height Measurement USER MANUAL HM202P Portable MechanicalStadiometer Please keep the instruction manual at hand and follow instruction for use.
-
Page 2: Table Of Contents
CONTENTS Explanation of Graphic Symbols on Label/Packaging ....3 Copyright Notice ................ 5 I. Safety Notes ................6 II. Installation ................9 III. Using Device ..............14 IV. Product Specifications ............15 V. Declaration of Conformity ........... 16... -
Page 3: Explanation Of Graphic Symbols On Label/Packaging
Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
-
Page 5: Copyright Notice
Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. -
Page 6: Safety Notes
I. Safety Notes General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. - Page 7 (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required Residual Risk Evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk to patient or user.
- Page 8 Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.
-
Page 9: Installation
II. Installation Parts Item Quantity Wall stabilizer HeadStopper Base Platform Height rod Measuring tape kit MS6111 standard slider (red) MS6110 slider (white) User Manual 1. Wall stabilizer 2. Head stopper 3. Base Platform 4. Height Rod 5. Measuring tape kit 6. - Page 10 Assembly Wall Stabilizer Measuring Tape Kit Head Stopper Height Rod segments optional white slider Base Platform Red Slider...
- Page 11 1. Insert wall stabilizer into 2. Pull down measuring tape, and measuring tape kit attach measuring tape kit with height rod 3. Attach head stopper to measuring tape kit and rod...
- Page 12 4. Assemble height rods, 5. Hitch measuring tape to hook at measuring tape kit, and platform slider to complete assembly. together With scale: upper hook Without scale: lower hook...
- Page 13 Packing Carefully re-pack HM202P in box as seen in image above, to avoid damaging device.
-
Page 14: Using Device
Height and weight measurement (with MS6110 or MS6111) Measuring tape should be connected to upper hook. If HM202P is used with MS6110 (adjustable feet), the white slider should be used. If HM202P is used with MS6111 (without adjustable feet), the red slider should be used. -
Page 15: Product Specifications
IV. Product Specifications Device Information Model HM202P 20-205 cm Range 8-81 in Height 1 mm Graduation Measurement 1/16 in Accuracy ± 10 mm Overall 406(W) x 585(D) x 2200(H) mm Dimensions Base 406(W) x 365(D) mm Device Weight 3.8 kg / 8.4 lb (approximate) (Carry case 1.1 kg / 2.4 lb) -
Page 16: Declaration Of Conformity
V. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
