Summary of Contents for Charder HM230M

  • Page 1 Height Measurement USER MANUAL HM230M Wall-mounted Stadiometer Please keep the instruction manual at hand and follow instruction for use.
  • Page 3: Table Of Contents

    CONTENTS Explanation of Graphic Symbols on Label/Packaging ....4 Copyright Notice ................ 6 I. Safety Notes ................7 II. Installation ................. 10 III. Using Device ..............14 IV. Product Specifications ............15 V. Declaration of Conformity ........... 16...
  • Page 4: Explanation Of Graphic Symbols On Label/Packaging

    Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
  • Page 6: Copyright Notice

    Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual.
  • Page 7: Safety Notes

    I. Safety Notes General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.
  • Page 8 (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required Residual Risk evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk to patient or user.
  • Page 9 Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.
  • Page 10: Installation

    II. Installation Parts Component Measuring rod Screws to fix heel plate Self-tapping screws for wall-mount block Flat head screws to fix measuring rod on wall-mount block Heel plate Plastic anchor Wall-mount block...
  • Page 11 Attaching height rod to wall 1. Fully extend height rod 2. Fasten wall mount block using flat head screws Screw Size: M5 x 0.8 x 10...
  • Page 12 3. Drill holes into wall, and insert 4. Fasten heel plate (continue to plastic anchor into hole. Proceed next section for details) to fasten self-tapping screw into the anchor. Screw Size: Screw Size: M4 x 30 M4 x 12...
  • Page 13 Assembling heel plate 1. Drill two holes into wall for wall-mount block 2. Insert plastic anchors into holes 3. Attach height rod to wall-mount block using plastic anchors 4. Attach rubber tub and heel plate with two self-tapping screws 5. Attach heel plate to wall-mount block with two self-tapping screws No.
  • Page 14: Using Device

    III. Using Device Buckle Subject height between 130-230 cm Height reading should be taken at point 1. Subject height under 130 cm For subjects shorter than 130 cm, press buckle down, press the buckle and push down on the headpiece. Height reading should be taken at point 3.
  • Page 15: Product Specifications

    IV. Product Specifications Device Information Model HM230M 10-230 cm Range 4-90.5 in Height 1 mm Graduation Measurement 1/16 in Accuracy ± 10 mm Overall 310(W) x 50(D) x 2300(H) mm Dimensions Device About 1.15 kg Weight +5℃~+35℃ Operation Environment 700 hPa ~1060 hPa...
  • Page 16: Declaration Of Conformity

    V. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
